DIAMOND
Fiber Optic Components
Specifications:
STANDARD
Insertion loss (IL)
Return loss (RL)
Repeatability of IL
Service life
Operating temperature
Storage temperature
Strain relief (cable)
* Measured with high precision reflectometer
ST
™
CONNECTOR
HST-S0.66 Alb
HST-M0.66 Alb
HST-M0.76 Alb
SM
MM
MM
Multimode
typ 0.15
min 35
max 0.4
typ 40
Single Mode
typ 0.2
min 45
max 0.4
typ 50
Units
Test conditions
dB
dB
dB
°C
°C
N
IEC 61300-3-4;
λ
= 1300/1550nm
IEC 61300-3-6;
λ
= 1300/1550nm
max
±0.1
-40 / +85
-40 / +90
> 100
max
±0.1
1000 mate/demate cycles
May be further limited by cable specifications
APPLICATIONS:
Telecommunications, CATV, LAN, MAN, WAN, Test &
Measurement, Industry, Medical, Sensors
COMPATIBILITY:
With all AT&T ST™-style SM/MM connectors complying
with IEC 874-10 and CECC BFOC/2.5
DESIGN/MATERIALS:
Fiber alignment:
SM:
Active Core Alignment via
patented two-step crimping
process
MM:
Polish:
Ferrule:
Via patented crimping process
Convex (PC)
∅
2.5 mm zirconia ceramic with
extending copper-nickel alloy insert
(Pilzferrule), spring loaded (10 N),
anti-rotation keyed
Adaptor:
External parts:
Cable retention:
Floating zirconia split sleeve in Ni-
plated Zamak housing
Plastic
Coupled to ferrule on cable
∅ ≤
3.5 mm;
signal interruption at 10 N
AVAILABLE AS:
- Unterminated connector
- Terminated patch cable, patchcord or pigtail
DIAMOND SA
Via dei Patrizi 5
CH-6616 LOSONE
Tel. ++41-91/785 45 45
Fax ++41-91/785 45 00
e-mail: info@diamond-fo.com
DIAMOND GmbH
Gutenbergstraße 4
D-70771 L.-Echterdingen
Tel. ++49-711/790 89-0
Fax ++49-711/790 89-10
e-mail: info@diamond.de
ST
™
is a registered trademark of AT&T
Specifications subject to change
without notice
002-037-204P005022
CONNECTORS
SINGLE MODE
Type designation:
Ferrule material:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
9/125/900
9/125/900/2100
9/125/900/2500
9/125/900/3000
9/125/900/3500
ST
™
HST-S0.66 Alb
Zirconia/copper-nickel alloy insert (Pilzferrule)
Plastic black
Convex (PC)
Order Number
Unterminated connector
Terminated assembly
211 - xxx - 001 L xxx
211 - xxx - 002 L xxx
211 - xxx - 003 L xxx
211 - xxx - 004 L xxx
211 - xxx - 005 L xxx
1
2
3
4
CONNECTORS
MULTIMODE
Type designation:
Ferrule material:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
50/125/900
50/125/900/2100
50/125/900/2500
50/125/900/3000
50/125/900/3500
Duplex
50/125/900/3000/6500
ST
™
(BFOC/2.5)
HST-M0.76 Alb
Zirconia/copper-nickel alloy insert (Pilzferrule)
Plastic black
Convex (PC)
Order Number
Unterminated connector
Terminated assembly
213 - xxx - 001 L xxx
213 - xxx - 002 L xxx
213 - xxx - 003 L xxx
213 - xxx - 004 L xxx
213 - xxx - 005 L xxx
213 - xxx - 054 L xxx
1
2
3
4
211 - 000 - 001 L 000
211 - 000 - 002 L 000
211 - 000 - 003 L 000
211 - 000 - 004 L 000
211 - 000 - 005 L 000
213 - 000 - 001 L 000
213 - 000 - 002 L 000
213 - 000 - 003 L 000
213 - 000 - 004 L 000
213 - 000 - 005 L 000
213 - 000 - 004 L 000
Connectors for other fiber and cable dimensions available upon request
Connectors for other fiber and cable dimensions available upon request
MULTIMODE
Type designation:
Ferrule material:
External parts:
Polish geometry:
Dimensions
Fiber/Cable
50/125/900
50/125/900/2100
50/125/900/2500
50/125/900/3000
50/125/900/3500
Duplex
50/125/900/3000/6500
Dimensions
Fiber/Cable
Order Number
Unterminated connector
213 - 000 - 001 L 000
213 - 000 - 002 L 000
213 - 000 - 003 L 000
213 - 000 - 004 L 000
213 - 000 - 005 L 000
213 - 000 - 004 L 000
Terminated assembly
213 - xxx - 011 L xxx
213 - xxx - 012 L xxx
213 - xxx - 013 L xxx
213 - xxx - 014 L xxx
213 - xxx - 015 L xxx
213 - xxx - 064 L xxx
1
2
3
4
HST-M0.66 Alb
Zirconia/copper-nickel alloy insert (Pilzferrule)
Plastic black
Convex (PC)
Order Number
Unterminated connector
212 - 000 - 001 L 000
212 - 000 - 002 L 000
212 - 000 - 003 L 000
212 - 000 - 004 L 000
212 - 000 - 005 L 000
212 - 000 - 004 L 000
Terminated assembly
212 - xxx - 001 L xxx
212 - xxx - 002 L xxx
212 - xxx - 003 L xxx
212 - xxx - 004 L xxx
212 - xxx - 005 L xxx
212 - xxx - 054 L xxx
1
2
3
4
62.5/125/900
62.5/125/900/2100
62.5/125/900/2500
62.5/125/900/3000
62.5/125/900/3500
Duplex
62.5/125/900/3000/6500
Connectors for other fiber and cable dimensions available upon request
Connectors for other fiber and cable dimensions available upon request
Dimensions
Fiber/Cable
62.5/125/900
62.5/125/900/2100
62.5/125/900/2500
62.5/125/900/3000
62.5/125/900/3500
Duplex
62.5/125/900/3000/6500
Order Number
Unterminated connector
212 - 000 - 001 L 000
212 - 000 - 002 L 000
212 - 000 - 003 L 000
212 - 000 - 004 L 000
212 - 000 - 005 L 000
212 - 000 - 004 L 000
Terminated assembly
212 - xxx - 011 L xxx
212 - xxx - 012 L xxx
212 - xxx - 013 L xxx
212 - xxx - 014 L xxx
212 - xxx - 015 L xxx
212 - xxx - 064 L xxx
1
2
3
4
Material
Mating sleeve
Zirconia
External parts
Plastic
Bestellnummern
16.1
9.6
121 - 301 - 901 V 001
29.5
Type designation:
Material
Mating sleeve
Zirconia
MST-M0.25
External parts
Plastic
Bestellnummern
12.7
Connectors for other fiber and cable dimensions available upon request
7.6
7.8
+0.1
0
Mating sleeve
Zirconia
External parts
Ni-plated Zamak
120 - 301 - 901 V 002
16.1
9.6
29.5
Type designation:
Material
Mating sleeve
Order Number Codes
1
Connector code
2
Connector code for termination on other end of assembly
- For pigtails:
insert 000
- For patch assemblies: insert connector code for other connector
3
Code for fiber or cable
4
Length in meters
See ordering information for additional details
Zirconia
MST-M0.2
External parts
Ni-plated Zamak
Bestellnummern
12
max panel thickness:
3.5 mm
120 - 301 - 904 V 002
Ø 9.7
±0.1
7.8
+0.1
0
3/8"x24 UNF-2A
7.6
Ø 10.9
Material
Bestellnummern
Ø 2.5
1.3
Type designation:
MST-S0.2
Ø 9.7
±0.1
121 - 301 - 902 V 001
10.6
Type designation:
MST-S0.25
Ø 2.5
MATING ADAPTER
3/8"x24 UNF-2A
1.3
