Lift |
Spacing 5.0 mm
AK700/..-5.0-H-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.2 mm²
4.0 mm²
0.2 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
10.60
15.60
20.60
25.60
30.60
35.60
40.60
45.60
50.60
55.60
60.60
Article Designation
AK700/2-5.0-H-GREEN
AK700/3-5.0-H-GREEN
AK700/4-5.0-H-GREEN
AK700/5-5.0-H-GREEN
AK700/6-5.0-H-GREEN
AK700/7-5.0-H-GREEN
AK700/8-5.0-H-GREEN
AK700/9-5.0-H-GREEN
AK700/10-5.0-H-GREEN
AK700/11-5.0-H-GREEN
AK700/12-5.0-H-GREEN
Article Number
50700020261F
50700030261F
50700040261F
50700050261F
50700060261E
50700070261E
50700080261E
50700090261E
50700100261D
50700110261D
50700120261D
PU
200
200
200
200
100
100
100
100
50
50
50
Stranded with Ferrule 0.25 mm²
min
Stranded with Ferrule 2.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Clamp
Screw
Solder Tag
Brass
Steel
Copper Alloy
8.0 mm
1.3 mm
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Colours
RAL6018
RAL7016
RAL7032
RAL5015
similar RAL 6018
GREEN, RAL6018
GREY , RAL7016
PEBBLE GREY, RAL7032
BLUE, RAL5015
LIGHT GREEN, similar RAL 6018
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
Bridge, 2-pole, BR/2-5.0/5.08-L7.0
50000000008
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Screw cover SC-AK700-YELLOW
50700000004
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
B
300 V
15 A
AWG 30-12
AWG 30-12
0.45 Nm
M3
1.6 kV
C
-
-
-
-
-
-
-
D
300 V
10 A
AWG 30-12
AWG 30-12
0.45 Nm
M3
1.6 kV
min
0.5 mm²
0.5 mm²
250 V
24 A
max
4.0 mm²
2.5 mm²
0.50 Nm
M3
2.0 kV
www.ptr.eu
