ECX-2236Q
SMD Crystal
Request a Sample
The ECX-2236Q is a miniature SMD Crystal with a 2.5 x 2.0 mm
footprint. AEC-Q200 Qualified
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
ECX-2236Q SMD CRYSTAL
PARAMETERS
Frequency
Mode of Oscillation
Frequency Tolerance*
Frequency Stability*
Shunt Capacitance
Load Capacitance
•
•
•
•
Low Profile
2.5 x 2.0 mm Footprint
RoHS Compliant
AEC-Q200 Qualified
Drive Level
Operating
Temperature*
Storage Temperature
Aging (First Year)
Fundamental
@ +25°C
-40 ~ +125°C
(ES Option)
Co
Specify in P/N
DL
Topr
(ES Option)
Tstg
@ +25°C ±3°C
8
10
-40
-40
100
+125
+125
±5
± 30
± 50
5
ppm
ppm
pF
pF
μW
°C
°C
ppm
CONDITIONS
ECX-2236Q
MIN
TYP
MAX
12.000
60.000
UNITS
MHz
DIMENSIONS (mm)
Frequency (MHz)
12.000 ~ 15.999
16.000 ~ 19.999
20.000 ~ 29.999
30.000 ~ 34.999
35.000 ~ 60.000
ESR Ω Max.
150
80
60
50
40
Figure 1)
Top, Side, and Bottom
Crystal is symmetrical, pad 1 & 3 are interchangeable.
Chamfer on the bottom pad has no electrical significance.
Pad
Connections
1
In/Out
2
Gnd
3
Out/In
4
Gnd
Figure 2)
Suggested land pattern
PART NUMBERING GUIDE: Example ECS-240-8-36Q-ES-TR
ECS - FREQUENCY ABBREVIATION
LOAD
CAPACITANCE
PACKAGE
Tolerance
Range
36Q =
ECX-2236Q
Blank = Std
A = ± 25 ppm
J = ± 20 ppm
R = ± 15 ppm
C = ± 10 ppm
AVAILABLE OPTIONS
Stability
Temp
PACKAGING
ECS
240 = 24.000 MHz
See P/N Guide
8 = 8 pF
S = Series
Blank= Std
D= ±100 ppm
E = ± 50 ppm
G = ± 30 ppm
H = ± 25 ppm
T = ± 20 ppm †
W = ±15 ppm †
K = ±10 ppm †
Blank= Std
L = -10 ~ +70°C
M = -20 ~ +70°C
Y = -30 ~ +85°C
N = -40 ~ +85°C
P = -40 ~ +105°C
S = -40 ~ +125°C
U = -55 ~ +125°C
TR = Tape
& Reel
3K/Reel
* Specify available options in P/N.
† Contact ECS for availability over extended temp range.
Rev.2020
15351 West 109
th
Street
|
Lenexa, KS 66219
|
Phone: 913.782.7787
|
Fax: 913.782.6991
|
www.ecsxtal.com
