3057SL005: DescriptionWire And Cable, 26 Conductor(s), 16AWG, 300V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT; CategoryThe connector Connector bracket; File Size241KB，3 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric View All

3057SL005 Overview

Wire And Cable, 26 Conductor(s), 16AWG, 300V, Flexible Cord And Fixture Wire, ROHS AND REACH COMPLIANT

3057SL005 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Alpha Wire
package instruction	ROHS AND REACH COMPLIANT
Reach Compliance Code	compliant
Certification	CSA; UL
conductor material	TINNED COPPER
Connector bracket type	WIRE AND CABLE
structure	STRANDED
diameter	2.34 mm
insulator material	POLYVINYL CHLORIDE
length	30.48 mm
Number of conductors	26
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Rated voltage	300 V
resistance	0.014 Ω
shield	NO
stay	26X30
Wire gauge	16 AWG
Wire and Cable Names	FLEXIBLE CORD AND FIXTURE WIRE
Base Number Matches	1

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 3057

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

1 X 1 HOOKUP

16 (26/30) AWG TC

0.016" Wall, Nom. PVC

0.060

0.092+/- 0.002

ALPHA WIRE E163869-* RU AWM STYLES 1569 105C

OR 1007 80C VW-1 300V 16 AWG ---- LXXXX CSA

(1) Print

TR-64 90C FT1 ROHS

{0} * = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN

ORANGE, SLATE, VIOLET, WHITE/BLACK, WHITE/RED

WHITE/GREEN, WHITE/YELLOW, WHITE/BLUE

WHITE/BROWN, WHITE/ORANGE, WHITE/SLATE

WHITE/VIOLET, GREEN/YELLOW, YELLOW/GREEN, PINK

(2) Color(s)

Applicable Specifications

1) UL

AWM/STYLE 1007

AWM/STYLE 1569

VW-1

2) CSA International

TR-64

FT1

90°C

80°C / 300 VRMS

105°C / 300 VRMS

Environmental

1) EU Directive 2011/65/EU(RoHS2):

All materials used in the manufacture of this part are in compliance with European Directive

2011/65/EU regarding the restriction of use of certain hazardous substances in electrical and

electronic equipment. Consult Alpha Wire's web site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Inductance

3) Conductor DCR

-40 to 105°C

10X Cable Diameter

20.4 Lbs, Maximum

(For Engineering purposes only)

300 VRMS

0.04 µH/ft, Nominal

4.4 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 5000 FT

b) 1000 FT

c) 100 FT

Flange x Traverse x Barrel (inches)

12 x 10 x 5 Continuous length

6.5 x 6 x 1.9 Continuous length

3.5 x 3 x 1.125 Continuous length

[Spool dimensions may vary slightly]

Notes:

a) Certain colors and put-up combinations may only be available by special order, minimums may apply.

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall
