331561T200JS2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> 331561T200JS2

331561T200JS2: DescriptionCap,Al2O3,560uF,200VDC,10% -Tol,50% +Tol; CategoryPassive components capacitor; File Size322KB，6 Pages; ManufacturerCDE [ CORNELL DUBILIER ELECTRONICS ]; Environmental Compliance

Download Datasheet Parametric View All

331561T200JS2 Overview

Cap,Al2O3,560uF,200VDC,10% -Tol,50% +Tol

331561T200JS2 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	unknown
Base Number Matches	1

Preview

Download Datasheet

View All

Type 330

–55 °C to 105 °C Ultra-Long-Life, Switching Power Grade Radial

High Ripple and Ultra-Long Life

The Type 330 is the ultra-long-life version of the Type 300 capacitor.

With an astonishing, 50,000-hour expected life operating

continuously at full load and 65 ºC the 330 is the choice for power

supply outputs and UPS battery stiffening. The exceptionally low

ESRs enable high ripple-current capability. With series inductance

of 12 to 16 nH and ripple currents to 16 amps one of these

capacitors can save by replacing three or four of the 12.5 mm

diameter capacitors routinely at the output of switching power

supplies. Type 330 R delivers even lower ESR and higher ripple.

Type 330 has three leads for rugged, reverse-proof mounting. Two

leads are available as Types 331 and 331R.

Specifications

Operating Temperature:

Rated Voltage:

Capacitance:

Capacitance Tolerance:

Leakage Current:

Cold Impedance:

Ripple Current Multipliers:

• Expected Life > 20 years @ 45 °C

• Ripple Current to 16 amps

• ESRs to 6

mΩ

• > 90% capacitance at –40 °C

• Replaces multiple capacitors

RoHS Compliant

–55 °C to +105 °C

6.3 to 250 Vdc

270 µF to 33,000 µF

6.3 to 100 Vdc; –10 + 75%, 160 to 250 Vdc; –10 + 50%

≤ 0.5 √CV µA, 4 mA max, 5 min.

–55 °C multiple of 25 °C Z ≤ 4 for 6.3 & 7.5 V, 3 for 10 to 50 V,

2 for > 50 V

Ambient Temperature

45 °C

1.66

55 °C

1.52

65 °C

1.37

75 °C

1.20

85 °C

1.00

95 °C

0.75

105 °C

0.36

Highlights

Frequency

50 Hz 60 Hz 120 Hz

.77” Diameter

6.3 & 7.5 V

10 to 40 V

50V

63 & 75 V

100 to 250 V

.895” Diameter

6.3 & 7.5 V

10 to 40 V

50V

63 & 75 V

100 to 250 V

1.02” Diameter

6.3 & 7.5 V

10 to 40 V

50V

63 & 75 V

100 to 250 V

0.84

0.81

0.76

0.77

0.76

0.88

0.86

0.81

1.00

1.12

1.15

1.23

1.24

1.17

1.22

1.35

1.37

1.19

1.25

1.42

1.44

1.20

1.26

1.44

1.46

0.82

0.80

0.75

0.76

0.86

0.84

0.80

0.81

1.00

1.14

1.17

1.27

1.26

1.25

1.20

1.25

1.42

1.40

1.38

1.23

1.29

1.50

1.48

1.46

1.24

1.30

1.52

1.50

1.48

0.82

0.78

0.76

0.74

0.76

0.86

0.83

0.81

0.80

0.81

1.00

1.15

1.20

1.25

1.28

1.24

1.21

1.30

1.38

1.43

1.37

1.24

1.35

1.45

1.52

1.44

1.25

1.36

1.47

1.54

1.46

360 Hz 1 kHz 5 kHz 10 kHz & up

Load Life:

Shelf Life:

10,000 h at full load at 85 °C

∆ Capacitance ±20%

ESR 200% of limit

DCL 100% of limit

500 h at 105 °C, capacitance, ESR and DCL, initial requirements

CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864) 843-2277 • Fax: (864) 843-3800 • www.cde.com
