Metallized Polypropylene
Film Capacitors
F
EATURES
•
•
•
•
•
Low dissipation factor and high insulation resistance
High stability of capacitance and DF versus temperature and
frequency
Non-inductive construction
Self-healing properties
Flame retardant epoxy resin coating
DMPP
Series
(Radial Dipped)
MERITEK
S
PECIFICATIONS
1. Operating temperature:
2.
3.
4.
5.
6.
Capacitance range:
Capacitance tolerance:
Rated voltage:
Dissipation factor:
Insulation resistance:
-55
o
C to +105
o
C
0.01μF to 3.3μF
±5%(J), ±10%(K), ±20%(M)
100VDC, 250VDC, 400VDC, 630VDC
0.1% max. at 1KHz, 25
o
C
>30000MΩ (C
≤
0.33μF)
>10000MΩ
• μF
(C > 0.33μF)
are
constructed
with
metallized
polypropylene film dielectric, tinned copper leads,
and an epoxy resin coating. They are suitable for
blocking, bypassing, coupling and decoupling,
filtering,
timing,
tuning,
and
temperature
compensation. DMPP are ideal for use in
telecommunication equipment, data processing
equipment, industrial instruments, automatic
control systems, and other devices
.
DMPP
*Voltage derated at operating temperature >85
o
C
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
103
10,000
10
0.01
104
100,000
100
0.1
105
1000
1
106
DMPP
103
J
2A
10
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
Rated Voltage
CODE
1H
50V
2A
100V
2E
250V
2G
400V
2J
630V
Tape & Reel/Tape & Ammo available for lead space < 10 mm
Please contact factory for part number.
Dimensions in millimeters (mm)
Rated
Voltage
DIM.
W
CAP(μF)
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.56
0.68
1.0
1.5
2.2
3.3
14.0
14.0
14.0
14.0
14.0
14.0
14.0
18.0
18.0
18.0
18.0
18.0
24.0
24.0
32.0
32.0
32.0
11.0
11.0
11.0
12.0
11.0
11.0
10.0
12.0
12.0
13.0
15.0
17.0
16.0
17.5
18.0
20.0
24.0
7.0
7.0
7.0
8.0
7.0
7.0
6.0
7.0
7.0
8.0
10.0
12.0
9.5
11.0
12.0
12.0
16.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
15.0
15.0
15.0
15.0
15.0
20.0
20.0
27.5
27.5
27.5
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
14.0
14.0
14.0
14.0
14.0
14.0
14.0
20.0
20.0
20.0
26.0
26.0
26.0
32.0
32.0
32.0
36.0
11.0
11.0
11.0
12.0
12.0
11.0
11.0
12.5
13.0
15.0
16.0
17.0
19.0
20.0
22.5
24.0
27.0
7.0
7.0
7.0
8.0
8.0
7.0
8.0
8.0
9.0
10.0
10.0
10.5
11.0
11.5
13.5
15.0
17.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
15.0
15.0
15.0
20.0
20.0
20.0
27.5
27.5
27.5
31.0
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
14.0
14.0
14.0
14.0
20.0
20.0
20.0
26.0
26.0
26.0
32.0
32.0
32.0
32.0
11.0
11.0
11.0
12.0
13.0
13.0
13.0
14.5
15.0
19.0
18.0
20.0
21.5
25.0
7.0
7.0
7.0
8.0
8.0
8.0
8.0
8.0
10.0
11.0
11.0
11.5
12.0
16.0
10.0
10.0
10.0
10.0
15.0
15.0
15.0
22.5
22.5
22.5
27.5
27.5
27.5
27.5
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
14.0
14.0
20.0
20.0
20.0
26.0
26.0
26.0
32.0
32.0
32.0
36.0
36.0
11.0
13.0
13.0
13.0
14.5
14.5
16.0
18.0
20.0
22.0
24.0
25.5
26.0
7.0
7.0
7.0
8.0
9.0
9.0
10.0
11.5
11.5
13.0
15.0
17.5
18.0
10.0
10.0
15.0
15.0
15.0
21.0
21.0
21.0
27.5
27.5
27.5
31.0
31.0
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
H
50VDC/100VDC
T
P± 1
dØ
W
H
250VDC
T
P± 1
dØ
W
H
400VDC
T
P± 1
dØ
W
H
630VDC
T
P± 1
dØ
Custom sizes and lead spacing available upon request
Custom values and tolerances available upon request
Specifications are
subject to change without notice.
rev.6a
