FKP1PCM37.50.22/10/630VDCREEL datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> FKP1PCM37.50.22/10/630VDCREEL

FKP1PCM37.50.22/10/630VDCREEL: DescriptionFilm Capacitor, Polypropylene, 630V, 10% +Tol, 10% -Tol, 0.22uF, Through Hole Mount, RADIAL LEADED; CategoryPassive components capacitor; File Size71KB，3 Pages; ManufacturerWIMA; Websitehttps://www.wima.de/; Environmental Compliance

Download Datasheet Parametric View All

FKP1PCM37.50.22/10/630VDCREEL Overview

Film Capacitor, Polypropylene, 630V, 10% +Tol, 10% -Tol, 0.22uF, Through Hole Mount, RADIAL LEADED

FKP1PCM37.50.22/10/630VDCREEL Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	2038791740
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	0
capacitance	0.22 µF
Capacitor type	FILM CAPACITOR
dielectric materials	POLYPROPYLENE
JESD-609 code	e3
Installation features	THROUGH HOLE MOUNT
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	TR
positive tolerance	10%
Rated (AC) voltage (URac)	400 V
Rated (DC) voltage (URdc)	630 V
surface mount	NO
Terminal surface	Tin (Sn)
Terminal shape	WIRE

Preview

Download Datasheet

View All

WIMA FKP 1

Impulsfeste Polypropylen-

Kondensatoren

Mit Metallfolienbelägen und innerer Reihenschal-

tung für höchste Strombelastbarkeit.

Einsatzge-

biete: Dämpfungs- und Kommutierungs-Kondensator

in Schaltznetzteilen, Umrichterschaltungen der An-

triebs- und Energietechnik sowie Ablenkschaltungen

der Fernseh- und Monitortechnik.

Polypropylene capacitors

for pulse applications

With metal foil electrode, internally series-connec-

ted for very high current ratings.

Applications:

Damping and commutation capacitors in switch

mode power supplies, static frequency changes in

drive and power electronics, deflection systems in

monitors and TV-sets.

Technische Angaben

Dielektrikum:

Polypropylen-Folie.

Beläge:

Aluminiumfolie und doppelseitig metallisierte

Kunststoff-Folie.

Umhüllung:

Flammhemmendes Kunststoffgehäuse, UL 94 V–0.

Farbe: Rot. Aufdruck: Schwarz. Epoxidharzverguß: Gelb.

Temperaturbereich:

–55) C bis +100) C.

Prüfklasse:

55/100/56 nach IEC.

Isolationswerte

bei +20) C:

C 0,1

mF:

1 10

MV (Mittelwert: 5 10

MV)

›

0,1

mF:

30 000 s (MV

mF)

(Mittelwert: 100 000 s)

Meßspannung: 100 V/1 min.

Verlustfaktoren

bei +20) C: tan

„

Technical Data

Dielectric:

Polypropylene film.

Capacitor electrodes:

Aluminium foil and double-sided

metallized plastic film.

Encapsulation:

Flame-retardent plastic case, UL 94 V–0.

Colour: Red. Marking: Black. Epoxy resin seal: Yellow.

Temperature range:

–55) C to +100) C.

Test category:

55/100/56 in accordance with IEC.

Insulation resistance

at +20) C:

C 0.1

mF:

1 x 10

MV (mean value: 5 x 10

MV)

›

0.1

mF:

30 000 sec (MV x

mF)

(mean value: 100 000 sec)

Measuring voltage: 100 V/1 min.

Dissipations factors

at +20) C: tan

at f

1 kHz

10 kHz

100 kHz

0.1

3 x 10

-4

4 x 10

-4

10 x 10

-4

0.1

‹

0.22

Gemessen bei

1 kHz

10 kHz

100 kHz

0,1

3 10

-4

4 10

-4

10 10

-4

„

0,1

‹

„

0,22

3 10

-4

6 10

-4

–

3 x 10

-4

6 x 10

-4

–

Kapazitätstoleranzen:

20 %,

10 %,

5 %,

andere Toleranzen auf Anfrage.

Impulsbelastung:

C-Wert

pF/mF

Flankensteilheit V/ms

max. Betrieb

400 V– 630 V– 1000 V– 1250 V– 1600 V– 2000 V– 4000 V– 6000 V–

–

13200

5500

3300

2200

1500

–

13200

10000

5500

4200

2200

–

13200

11200

7700

4900

3100

18000

15000

14000

12000

8000

5000

3500

18000

16000

15000

13000

8500

5000

–

16000

15000

13000

8500

–

16000

15000

13000

8500

–

Capacitance tolerances:

20 %,

10 %,

5 %

(closer tolerances are available subject to special enquiry).

Maximum pulse rise time:

Capac-

itance

pF/mF

Pulse rise time V/msec

max. operation

400 VDC 630 VDC 1000 VDC 1250 VDC 1600 VDC 2000 VDC 4000 VDC 6000 VDC

–

13200

5500

3300

2200

1500

–

13200

10000

5500

4200

2200

–

13200

11200

7700

4900

3100

18000

15000

14000

12000

8000

5000

3500

18000

16000

15000

13000

8500

5000

–

16000

15000

13000

8500

–

16000

15000

13000

8500

–

100

. . . 220

–

330

. . . 680

–

1000, . . . 2200, 13200

3300, . . . 6800, 5500

0,01 . . . 0,022 2700

0,033 . . . 0,068 1900

0,1 . . . 0,220 1200

100

. . . 220

–

330

. . . 680

–

1000. . . . 2200. 13200

3300. . . . 6800. 5500

0.01 . . . 0.022 2700

0.033 . . . 0.068 1900

0.1 . . . 0.220 1200

Prüfspannung:

2 U

, 2 s / 6 kV: 1,6 U

, 2 s.

Schwingen:

6 h bei 10 . . . 2000 Hz und 0,75 mm Auslenkung

bzw. 10 g nach IEC 60068-2-6.

Unterdruck:

1 kPa = 10 mbar nach IEC 60068-2-13.

Stoßtest:

4000 Stöße mit 390 m/s

nach IEC 60068-2-29.

Spannungsderating:

Die zulässige Spannung vermindert sich

gegenüber der Nennspannung bei Gleichspannungsbetrieb ab

+85) C, bei Wechselspannungsbetrieb ab +75) C um 1,35 %

je 1 K.

Kurven siehe Seite 12.

Test voltage:

2 Ur, 2 sec / 6000 VDC: 1.6 Ur, 2 sec.

Vibration:

6 hours at 10 . . . 2000 Hz and 0.75 mm displacement

amplitude or 10 g in accordance with IEC 60068-2-6.

Low air density:

1 kPa = 10 mbar in accordance with

IEC 60068-2-13.

Bump test:

4000 bumps at 390 m/sec

in accordance with

IEC 60068-2-29.

Voltage derating:

A voltage derating factor of 1.35 % per K

must be applied from +85) C for DC voltages and from

+75) C for AC voltages.

Graphs see page 12.
