BZW06-5V8........ BZW06-376
BZW06-5V8B.... BZW06-256B
600 W Unidirectional and Bidirectional Transient Voltage Suppressor Diodes
Dimensions in mm.
DO-15
(Plastic)
Peak Pulse
Power Rating
At 1 ms. Exp.
600 W
Reverse
stand-off
Voltage
5.8 ÷ 376 V
®
6.35
± 0.2
58.5
±0.5
Mounting instructions
1. Min. distance from body to soldering point,
4 mm.
2. Max. solder temperature, 350 °C.
3. Max. soldering time, 3.5 sec.
4. Do not bend lead at a point closer than
2 mm. to the body.
•
Glass passivated junction
•
Low Capacitance AC signal protection
•
Response time typically < 1 ns.
•
Molded case
•
The plastic material carries
U/L recognition 94 V-0
•
Terminals: Axial leads
•
Polarity: Color band denotes
Cathode except bidirectional types
Maximum Ratings, according to IEC publication No. 134
P
pp
I
FSM
T
j
T
stg
P
M(AV)
Peak pulse power with 10/1000 µs
exponential pulse
Non repetitive surge peak forward
current (t = 10 ms)
(Note 1)
Operating temperature range
Storage temperature range
Steady state Power dissipation (l = 10 mm)
600 W
100 A
– 65 to + 175 °C
– 65 to + 175 °C
5W
Electrical Characteristics at Tamb = 25 °C
V
F
R
thj-l
Max. forward voltage
drop at I
F
= 50 A
(Note 1)
V
BR
220 V
V
BR
> 220 V
3.5 V
5.0 V
30 °C/W
Max. thermal resistance (1 = 10 mm.)
Note 1: Valid only for Unidirectional.
Jan - 00
