BL226M0333J--

Description
CAPACITOR, METALLIZED FILM, POLYPROPYLENE, 1600 V, 0.033 uF, THROUGH HOLE MOUNT, RADIAL LEADED
CategoryPassive components    capacitor
File Size96KB,6 Pages
ManufacturerAVX
Environmental Compliance
Download Datasheet Parametric View All

BL226M0333J-- Overview

CAPACITOR, METALLIZED FILM, POLYPROPYLENE, 1600 V, 0.033 uF, THROUGH HOLE MOUNT, RADIAL LEADED

BL226M0333J-- Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid2014977959
package instructionRADIAL LEADED
Reach Compliance Codecompliant
ECCN codeEAR99
YTEOL0
Other featuresRATED AC VOLTAGE (V): 400
capacitance0.033 µF
Capacitor typeFILM CAPACITOR
dielectric materialsPOLYPROPYLENE
high19.6 mm
JESD-609 codee3
length26.7 mm
Manufacturer's serial numberBL22
Installation featuresTHROUGH HOLE MOUNT
negative tolerance5%
Maximum operating temperature100 °C
Minimum operating temperature-55 °C
Package shapeRECTANGULAR PACKAGE
Package formRadial
method of packingBULK
positive tolerance5%
Rated (AC) voltage (URac)400 V
Rated (DC) voltage (URdc)1600 V
seriesBL226(L,M)
surface mountNO
Terminal surfaceMATTE TIN
Terminal pitch22.5 mm
Terminal shapeWIRE
width10.2 mm
BL 07/10/15/22/27
PPM6 (BB/PBS)
APPLICATIONS
• Commodity Product:
• Decoupling with AC or pulse components
• High current uses (TV deflection coils)
• Capacitive dividers
• Energy saving lamps, etc.
TECHNOLOGY
Dielectric: Polypropylene film
Wound capacitor
Leads: Radial tinned wire
Protection: Plastic case (UL94: V-O) / Polyurethane resin
Marking: Logo
Type
Nominal Capacitance
Tolerance (EIA)
DC Nominal Voltage
Example:
T BL 100n J 250
• Delivery Mode: Bulk
Taped (reel) for pitch = 7.5-10 & 15mm
Schematic Cross Section
Schoop
Metallized Film
PERFORMANCE CHARACTERISTICS
Climatic Category:
Capacitance Range:
Tolerances on C
R
:
Nominal Voltages:
Category Voltage:
Test Voltage:
Total Self Inductance (L):
Pitch (mm)
L (nH)
7.5
8
STANDARDIZATION
CEI 384-16 & CEI 384-17
Performance Class 1-1
55/100/56
C
R
1 nF to 6.8 µF (E24)
±5%, ±10%
V
r
160/250/400/630/1000/1600/2000 V
V
r
~
100/160/200/250/350/400/500 V
V
c
= 0.7 V
R
at 100°C
V
e
= 1.6 V
R
/ 2s at 25°C
For lead length = 2mm
10
9
15
10
22.5
18
27.5
18
Tangent of Loss Angle:
Insulation Resistance:
Condition of Measurement:
dv/dt:
V
R
-
160 250
(dv/dt)
R
max
pitch: 7.5mm
(dv/dt)
R
max
pitch: 10mm
(dv/dt)
R
max
pitch: 15mm
(dv/dt)
R
max
pitch: 22.5mm
(dv/dt)
R
max
pitch: 27.5mm
1200
850
107
85
56
1310
1000
154
120
65
D.F.
10 * 10
-4
at 1 kHz 25°C
IR > 100 G for C
≤0.33µF
IR > 30000s for C >0.33µF
100V (±15) at 25°C
400
1620
1250
247
130
80
630
2750
2500
280
150
90
1000 1600 2000
400
280
144
460
390
203
690
485
253
Thermal Resistance:
Pitch (mm)
Case
Rth
7.5mm
2
120
10mm
4
5
94
82
R
th
hot spot/ambient (°C/W)
6
127
15mm
8
9
103 94
10
82
11
71
12
58
22.5mm
13
23
53
49
24
39
16
47
27.5mm
P0
18
45
37
19
33
31
