MR100 Series
www.vishay.com
Vishay Mills
Wirewound Resistor, Ultra Precision,
Epoxy Molded, Axial Lead
FEATURES
• Resistance values up to 6 M
• Resistance tolerances down to ± 0.005 %
• Tighter tolerances and lower resistance values
available, please contact factory
• Temperature coefficients down to ± 2 ppm/°C,
and up to 6000 ppm/°C
• Matched resistance sets available in tolerances
down to ± 0.001 %, and in temperature
coefficients down to ± 0.5 ppm/°C, please
contact factory
• Custom design capability available, please
contact factory
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
POWER
RATING
W
(1)
RESISTANCE RANGE RESISTANCE RANGE RESISTANCE RANGE
RESISTANCE RANGE
MAXIMUM
WORKING
± 0.1 %, ± 0.25 %,
± 0.05 %, ± 0.1 %,
± 0.01 %, ± 0.05 %,
± 0.005 %, ± 0.01 %,
VOLTAGE
± 0.5 %, ± 1 %
± 0.25 %, ± 0.5 %, ± 1 %
± 0.1 %, ± 0.25 %,
± 0.05 %, ± 0.1 %,
V
(2)
± 0.5 %, ± 1 %
± 0.25 %, ± 0.5 %, ± 1 %
1 to 400K
5 to 400K
50 to 400K
1K to 400K
150
1 to 750K
5 to 750K
50 to 750K
1K to 750K
200
1 to 750K
5 to 750K
50 to 750K
1K to 750K
200
1 to 500K
5 to 500K
50 to 500K
1K to 500K
100
1 to 1.0M
5 to 1.0M
50 to 1.0M
1K to 1.0M
200
1 to 1.2M
5 to 1.2M
50 to 1.2M
1K to 1.2M
300
1 to 2.5M
5 to 2.5M
50 to 2.5M
1K to 2.5M
400
1 to 3.8M
5 to 3.8M
50 to 3.8M
1K to 3.8M
300
1 to 3.8M
5 to 3.8M
50 to 3.8M
1K to 3.8M
400
1 to 3.8M
5 to 3.8M
50 to 3.8M
1K to 3.8M
400
1 to 6.0M
5 to 6.0M
50 to 6.0M
1K to 6.0M
600
1 to 6.0M
5 to 6.0M
50 to 6.0M
1K to 6.0M
800
1 to 6.0M
5 to 6.0M
50 to 6.0M
1K to 6.0M
900
1 to 6.0M
5 to 6.0M
50 to 6.0M
1K to 6.0M
1000
MR101
0.120
MR102
0.175
MR103
0.200
MR104
0.150
MR105
0.200
MR106
0.250
MR107
0.330
MR108
0.400
MR110
0.500
MR111
0.500
MR112
0.750
MR114
1.000
MR115
1.500
MR116
2.000
Notes
(1)
Power rating is based on tolerance, please see derating chart.
(2)
The maximum working voltage is the highest voltage that can be applied to the resistor. Below this value, the maximum voltage that can
continuously be applied is given by (P x
R)
1/2
.
GLOBAL PART NUMBER INFORMATION
Global Part Numbering example: MR106250R00TAE66
(visit
www.vishay.net
SAP parts manual for all options)
M
R
1
0
6
2
VALUE
(6 digits)
5
0
R
0
0
TC
(1 digit)
T
A
E
6
6
SPECIAL
(up to 2 digits)
(dash
number)
From
1
to
99
as applicable
S
= 0.025"
terminal
GLOBAL MODEL
(5 digits)
(see Standard Electrical
Specifications Global
Model column
for options)
TOLERANCE
(1 digit)
S
= ± 0.005 %
T
= ± 0.01 %
Q
= ± 0.02 %
A
= ± 0.05 %
B
= ± 0.1 %
C
= ± 0.25 %
D
= ± 0.5 %
F
= ± 1.0 %
PACKAGING CODE
(3 digits)
E66
= lead (Pb)-free
bulk pack
R
= decimal
K
= thousand
M
= million
1R5000
= 1.5
1K5000
= 1.5 k
1M0000
= 1 M
A
= standard,
10 to 30 (W)
B
= 3900 (Q)
C
= 4500 (M)
D
= 6000 (N)
E
= 3500 (P)
Y
= 10 ( 1
)
G
= 5 ( 10
)
J
= 2 ( 100
)
250
Historical Part Number example: MR106W250R0T
MR106
HISTORICAL MODEL
W = STANDARD
TC
0.01 %
TOLERANCE
RESISTANCE VALUE
Revision: 24-May-16
Document Number: 31814
1
For technical questions, contact:
ww2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MR100 Series
www.vishay.com
DIMENSIONS
in inches [millimeters]
L
LD
Vishay Mills
D
GLOBAL MODEL
MR101
MR102
MR103
MR104
MR105
MR106
MR107
MR108
MR110
MR111
MR112
MR114
MR115
MR116
DIMENSIONS
in inches [millimeters]
L ± 0.025 [0.635]
0.250 [6.35]
0.375 [9.52]
0.450 [11.43]
0.250 [6.35]
0.375 [9.52]
0.500 [12.70]
0.750 [19.05]
0.500 [12.70]
0.750 [19.05]
0.750 [19.05]
1.000 [25.40]
1.000 [25.40]
1.500 [38.10]
2.000 [50.80]
D ± 0.005 [0.127]
0.187 [4.75]
0.187 [4.75]
0.187 [4.75]
0.250 [6.35]
0.250 [6.35]
0.250 [6.35]
0.250 [6.35]
0.375 [9.52]
0.375 [9.52]
0.375 [9.52]
0.375 [9.52]
0.500 [12.70]
0.500 [12.70]
0.500 [12.70]
LD ± 0.002 [0.051]
0.025 [0.635]
0.025 [0.635]
0.025 [0.635]
0.025 [0.635]
0.032 [0.813]
(1)
0.032 [0.813]
(1)
0.032 [0.813]
(1)
0.032 [0.813]
0.032 [0.813]
0.032 [0.813]
0.032 [0.813]
0.032 [0.813]
0.032 [0.813]
0.032 [0.813]
Note
(1)
0.025" [0.635] available, this is called out by putting an “S” in the SPECIAL section of the part number.
MATERIAL SPECIFICATIONS
Element:
nickel-chrome alloy, other materials available
depending on TC requirements
Core:
molded epoxy
Encapsulant:
epoxy
Standard Terminals:
100 % matte tinned copper
Part Marking:
Mills, model, value, tolerance, date code
Note
• Due to resistor size limitations some resistors will have minimal
information marked on parts
DERATING
RATED POWER IN %
180
160
140
120
100
80
60
40
20
0
0
20
40
60
80
100
120
140
160
1 %,
0.05 %
0.5 %
, 0.1
, 0.02 %
% To
e
Toleran
c
leran
ce
0.01 %
Toleran
c
e
e
0.005 % Toleranc
AMBIENT TEMPERATURE IN °C
TECHNICAL SPECIFICATIONS
PARAMETER
Temperature Coefficient
Terminal Strength
Dielectric Withstanding Voltage
Operating Temperature Range
UNIT
ppm/°C
lb
V
AC
°C
MR100 RESISTOR CHARACTERISTICS
± 10 for > 100
;
± 20 for 10
to 100
;
± 30 for < 10
4.5
750
-55 to +145 (see derating chart)
Revision: 24-May-16
Document Number: 31814
2
For technical questions, contact:
ww2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
