Last Update:
2-26-07
Dimensions: mm (in.)
Ref. #:
MS-101174
4.20
(.165)
Common Terminal
C
A
1.95
(.077)
1.20
(.047)
.70
(.028)
1.20
(.047)
C
2.20
(.087)
D
B
3
(.118)
P.C.B. Layout
A
3.60
(.142)
3.05
(.120)
4.20
(.165)
C
A
3.60
(.148)
4.30
(.169)
D
B
D
B
Seperate Terminal
1.14±.30
(.045±.012)
1.55±.35
(.061±.014)
.58
(.023)
On Angular
Dimension
.55
(.022)
Circuit Diagram
Release Position
On Start
Position
15˚
3.05±.30
(.12±.012)
Recommended Operation Area
Pivot Center
1.65±.15
(.065±.006)
1
(.039)
3
(.118)
.50
(.02)
.55
(.022)
.50
(.02)
60˚
Action
Direction
Contact resistance
& Operating force
measurement position
2.65±.30
(.104±.012)
.90
(.035)
.60
(.024)
1.20±.20
(.047±.008)
1.65
(.065)
.60
(.024)
Electrical Specifications:
•
Rating: 1mA/5V DC
•
Contact Resistance: 1Ω Max.
•
Insulation Resistance: 100MΩ Min.
•
Dielectric Strength: 100 VAC (50Hz or 60Hz) shall
•
be applied across terminals and cover for 1 minute
Electrical Life: 50,000 cycles
Mechanical Specifications:
•
Operating Temperature: -10° C to +60° C
•
Operating Force: 40gf Max.
•
Storage Temperature: -20° C to +70° C
Note:
•
RoHS Compliant
Detector Switch
104-TUL14-EV
Available from Mouser Electronics
www.mouser.com
1-800-346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
