SURFBOARDS

THE BREADBOARDING MEDIUM

FOR

SURFACE MOUNT

IDS33608

REV A- 10-2011

33000

SERIES

APPLICATION SPECIFIC ADAPTERS

MODEL

33608

ACCEPTS

PARTIAL LISTING

ALPHA

OMEGA

SOT-23-8, SOT-28, TSOT-23-8

DFN 3x2A-8L-NEP-P

RJ-8, UJ-8

WMini8-F1

VSOF (1629)

8 PIN,

VSOF (2429)

8 PIN

TSMT-8, TSST-8

DCN (R-PDSO-G8) SSOP

PS-8, VS-8

1206-8

20.32

10.16

2.54

2.8

.65

2.0

3.4

1.9

2.0

2.8

3.3

1.57

IN.

.800

.400

.100

.110

.025

.079

.016

.031

.134

.075

.079

.110

.130

.062

.020

NOTE:

BOARD WIDTH

+- .5mm .020in.

BOARD HEIGHT

+-.5mm .020in.

SIP PIN SPACE

+-.20mm .008in.

PAD CENTERLINE

DEVICE LEAD PITCH

PAD LENGTH

PAD WIDTH

GAP

MAX LEAD WIDTH

TYPICAL LEAD WIDTH

ALTERNATE LEAD WIDTH

ALTERNATE PACKAGE

LENGTH FROM SHOULDER

+-.5mm .020in.

8 LEAD

.65 mm

PITCH DEVICES

DEVICE LEAD WIDTHS

ANALOG

PANASONIC

RENESAS

ROHM

TEXAS INST.

TOSHIBA

VISHAY

1.9, 2.0, 2.8, To Max 3.8 MM

ALWAYS CONSULT DEVICE DATA SHEET TO INSURE PROPER FIT

FIG.

SINGLE-IN-LINE ( SIP ) PINS

ON .100 in. CENTERS

PAD SET

EXAMPLE DEVICES (J)

MAX DEVICE WIDTH (I)

DRAWINGS

NOT TO

SCALE

MOUNTING PADS ARE OVERSIZED IN LENGTH TO

ACCEPT A WIDER RANGE OF DEVICE WIDTHS AND

TOLERANCES AND TO PERMIT HAND SOLDERING.

SEE WEBSITE FOR SOLDERING SUGGESTIONS

BOARD SPECIFICATIONS

BOARD MATERIAL:

.8mm, +-.13mm .031in+-..005 in.

Thick G-10 FR-4 Glass Epoxy or equivalent.

CIRCUITS:

1 oz. Copper with RoHS compliant Lead Free

solder coating. Patten Position on board +- .5mm .020in.

PIN SHOULDER HEGHT

PIN WIDTH

RoHS

Compliant

EC 2002/95

TOLERANCES:

If not noted are +- 20%. Nominal values are given. Controlling unit is Millimeters.

Values rounded to nearest decimal. Slight Variations due to manufacturing process can occur.

Capital Advanced Technologies, Inc.

in., and the Leaf Circuit Logo are trademarks of Capital Advanced Technologies, Inc. All other trademarks are the property of their respective owners. Specifications, availability, and price is subject to change without notice. All

information given is believed to be accurate but is not guaranteed. The user of information given or products represented by such information is responsible for determining the suitability of said information or products for a given

purpose. No inducement is intended or permission granted for infringement of any patent or unauthorized use of any intellectual property of Capital Advanced Technologies or others.

CAPITAL ADVANCED TECHNOLOGIES, INC.

CAROL STREAM, ILLINOIS. USA

PHONE 630-690-1696

FAX 630-690-2498

MADE

WWW.CapitalAdvanced.Com

USA
