05026
60KS200C
thru
90KS200C
SHIPBOARD/ AC POWER BUS VOLTAGE SUPPRESSOR
APPLICATIONS
✔
AC Power Protection
✔
Shipboard (Line-Line) Protection
✔
Differential AC Power Bus
✔
Aircraft AC Power Bus
IEC COMPATIBILITY
(EN61000-4)
✔
Meets the Following Military Specifications:
- DOD-STD-1399
- MIL-STD-704A
✔
60 & 90 kilowatts Peak Pulse Power per Line (tp=1.2/50µs)
✔
Each Device 100% Tested
✔
200 Volts Bidirectional
60KS200C
MECHANICAL CHARACTERISTICS
✔
Hermetically Sealed Glass to Metal Sub-Assemblies
✔
Weight 50 grams (Approximate)
✔
Flammability Rating UL 94V-0
✔
Device Marking: Logo & Part Number
✔
Screening Available Upon Request - The 60 & 90KS series can be screened upon
request for military requirements in accordance with MIL-PRF-19500 (applicable test).
Standard screening is available based on the following options:
H1 - Submodule Screening per test plans 05231 & 05232
H2 - Submodule & Module Screening per test plan 05233
H3 - Submodule & Module Screening, Module Group B & C Lot Testing
per test plans 05234 & 05235
90KS200C
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (tp = 1.2/50µs) - See Fig. 1
Operating Temperature
Storage Temperature
Steady State Power Disspiation @ 50°C
SYMBOL
P
PP
T
L
T
STG
T
A
VALUE
60 & 90
-55 to 150
-55 to 150
10.0
UNITS
kilowatts
°C
°C
Amps
05026.R6 2/07
1
www.protekdevices.com
60KS200C
thru
90KS200C
DEVICE CHARACTERISTICS
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
@ 25°C Unless Otherwise Specified
MAXIMUM
LEAKAGE
CURRENT
MAXIMUM
PEAK PULSE
CURRENT
(See Fig. 2)
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
PP
V
C
VOLTS
335
280
@1mA
V
WM
VOLTS
60KS200C
90KS200C
180
180
V(BR)
VOLTS
200
200
@V
WM
I
D
µA
10
0.5
I
PPM
AMPS
180
180
1000
FIGURE 1
PEAK PULSE POWER VS PULSE TIME
P
- Peak Pulse Power - killowatts
PP
90kW 1.2/50µs
Waveform
100
60kW 1.2/50µs
Waveform
10
1
0.1
1
10
100
td - Pulse Duration - µs
1000
10000
FIGURE 2
PULSE WAVE FORM
100
IPP - Peak Pulse Current - % of IPP
100
FIGURE 3
POWER DERATING CURVE
Peak Pulse Power
1.2/50µs
80
% Of Rated Power
tf
Peak Value IPP
TEST
WAVEFORM
PARAMETERS
tf = 1.2µs
td = 50µs
60
td = t IPP/2
50
40
20
e-t
0
0
50
100
t - Time - ms
150
0
0
25
Average Power
50
75
100
125
TL - Lead Temperature - °C
150
05026.R6 2/07
2
www.protekdevices.com
60KS200C
thru
90KS200C
PACKAGE OUTLINE & DIMENSIONS
60KS200C PACKAGE OUTLINE
60KS200C
A
C
B
D
G
H
DIMENSIONS
DIM
A
B
C
D*
E
F*
G
H
I*
J
MILLIMETERS
MIN
MAX
56.38
49.02
3.43
20.32
8.26
3.18 DIA
16.76
34.16
6.35
11.94
57.91
50.03
4.17
20.32
9.27
3.18 DIA
18.29
35.69
6.35
13.46
90KS200C
INCHES
MIN
MAX
2.22
2.28
1.93
1.97
0.165
0.135
0.800
0.800
0.325
0.365
0.125 DIA 0.125 DIA
0.660
0.720
1.405
1.345
0.250
0.250
0.470
0.530
E
F
J
I
90KS200C PACKAGE OUTLINE
A
C
B
D
G
H
DIMENSIONS
DIM
A
B
C
D
E
F
G
H
I
J
MILLIMETERS
MIN
MAX
-
47.75
6.10
24.89
-
4.90 DIA
22.66
45.34
6.48
-
63.50
48.77
6.60
25.91
10.16
5.21 DIA
23.06
46.10
7.49
13.97
INCHES
MIN
MAX
-
2.50
1.880
1.920
0.240
0.260
0.980
1.020
-
0.400
0.193 DIA 0.205 DIA
0.892
0.908
1.785
1.815
0.255
0.295
-
0.550
E
F
J
I
Outline & Dimensions: Rev 0 - 4/02, 06033
Note*:
Dimensions are nominal.
COPYRIGHT © ProTek Devices 2007
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and specifications is
the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or specifications of such
products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail: sales@protekdevices.com
Web Site: www.protekdevices.com
www.protekdevices.com
05026.R6 2/07
3
