TV05-Series Specifications
5.00L x 3.20W x 1.50H (mm)
PDI
TV05-Series
Voltage Controled Temperature Compensated Crystal Oscillator
(VCTCXO) ensures a precise frequency under demanding circumstances. With
ultra-low phase noise, low jitter, and excellent performance in high vibration
environments this VCTCXO is available, in both standard and custom frequencies.
PDI provides fast sampling for your proto-typing needs, mass production
capability, and competitive pricing.
ex)
TV05—25000X—W—N—D—3—R—X
*
FREQUENCY
10000X-52000X
=
10.000MHz –
52.000MHz
OUTPUT
C
= TTL/CMOS
O
= LVCMOS
W
= Clipped Sine
FREQUENCY
STABILITY
K
= +/-0.5
L
= +/-1.0
M
= +/-2.0
N
= +/-2.5
S
= Special
OPERATING
TEMPERATURE
A
= 0 to +70°C
B
= -20 to +70°C
D
= -40 to +85°C
S
= Special
SUPPLY
VOLTAGE
F
= 3.0
3
= 3.3
5
= 5.0
PACKAGE
R
= Tape & Reel
* - for standard or assigned for customization.
Parameters
Frequency Range
*1
Clipped Sinewave
10.000000 to 52.000000
Per Option
±0.2
±0.2
±1
±2
10 to 90
±5 to ±15
10
100K
10.0
Per Option
-55 to +125
Per Option
5.0
Clipped Sinewave
0.8V Peak to Peak Min
N/A
N/A
N/A
10 kΩ//10pF
3.0
-110
-130
-145
-145
CMOS
10.000000 to 52.000000
Per Option
±0.2
±0.2
±1
±2
10 to 90
±5 to ±15
10
100K
10.0
Per Option
-55 to +125
Per Option
10.0
CMOS
10
90
40/60
15pF
3.0
-110
-130
-145
-145
Units
MHz
Frequency Stability
*1
Frequency Adjustment
(Positive Slope)
Temperature Range
*1
Supply Voltage
*1
Supply Current (Max)
Waveform
Output
Load
Start Up Time (Max)
Phase Noise
(Typical For 26.0 MHz)
vs Temperature (Max.)
vs Supply Voltage (Max.)
vs Load (Max.)
vs Aging (Max 1st year)
Calibration (@ +25°C)
1 Hour After Refow (Max)
Control Voltage Range
Pull Range
Linearity (Max)
Input Impedance (Min)
Modulation Bandwidth (@-3dB)
Operating
Storage
ppm
%Vcc
ppm
%
Ω
KHz
°C
V
mA
Low Level Output Voltage (Max)
High Level output Voltage (Min)
Duty Cycle (Max)
%Vcc
%Vcc
%
ms
dBc/Hz
@ 100 Hz
@ 1 kHz
@ 10 kHz
@ 100 kHz
*1 - Not all Frequency/Temperature/Voltage combinations are available.
REV:
NA
SIZE:
A
CAGE:
0S4G1
1
of
3
TV05-Series
5.00 x 3.20 x 1.50
(mm)
PA C K A G E D I M E N S I O N S
Decimal XXX = ± .008, XX = ± .02 Metric [XXX = ± .20], [XX = ± .50]
PIN
1
2
3
4
CONNECTION
Voltage Control
Ground/Case
Output
Supply Voltage
.197 ±.008
[5.00 ±.20]
.205
[5.20]
.126 ±.008
[3.20 ±.20]
4
PDI FKA
D/C
.095
[2.40]
3
Pin 1
Traceability Code
.059 Max
[1.50 Max]
.189
[4.80]
.102
[2.60]
1
2
.047
[1.20]
1
2
.134
[3.40]
Do not run traces
under device
Solder Mask
Recommended Land Pattern
(Top View)
.063
.118
[1.60] [3.00]
4
3
NOTES:
Terminals are Au.
Other options are available, please consult factory.
All product is supplied
RoHS
and
REACH
compliant.
Product can be supplied on Tape and Reel, on reels of 1,000 units.
Specifications subject to change without notice, last updated 4/1/13.
REV:
NA
SIZE:
A
CAGE:
0S4G1
2
of
3
TV05-Series
5.00 x 3.20 x 1.50
(mm)
1.
Material: Black Conductive Polystyrene or equivalent.
2.
10 Sprocket Hole pitch cumulative tolerance of ±.008.
3.
Camber in compliance with EIA 481.
4.
Empty pockets: Trailing end (Minimum) 200 mm. and Leading end (Minimum) 400 mm.
5.
Pocket position relative to sprocket hole measured as true position of pocket, not pocket hole.
.012±.002
[0.30±.05]
Ø.059
[Ø1.50]
.069
[1.75]
.079
[2.00]
.157 Typ.
[4.00 Typ.]
A
.217
[5.50]
.472 ±.012
[12.00 ±.30]
Section A-A
.315 Typ.
[8.00 Typ.]
A
.480
[12.20]
120°
Ø7.09
[Ø180.00]
3.15
[80.00]
REV:
NA
SIZE:
A
CAGE:
0S4G1
3
of
3
