Tantalum Surface Mount Capacitors
Fused
tantalum Fused
One world. One KEMET.
Electronic Components
Tantalum Surface Mount Capacitors
Fused
Table of Contents
Page
Why Choose KEMET ........................................................................................................................................................ 3
T496 Fused MnO
2
Series .................................................................................................................................................. 5
T496 Hi-Rel Fused COTS MnO
2
Series and DLA (DSCC) Drawing 04053 ...................................................................17
Packaging Information ................................................................................................................................................... 31
KEMET Corporation Sales Offices
............................................................................................................................... 36
Other KEMET Resources ............................................................................................................................................... 37
One world. One KEMET
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
TC106_FUSED • 10/17/2013
2
One world. One source. One KEMET.
When you partner with KEMET, our entire global organization provides you with the
coordinated service you need. No bouncing from supplier to supplier. No endless phone
calls and web browsing. We’re your single, integrated source for electronic component
solutions worldwide.
Less hassles. More solutions.
Our commitment to product quality and on-time delivery has helped customers
succeed for over 90 years. There’s a reason KEMET components can be found in
defense and aerospace equipment. Our reputation is built on a history of consistency,
reliability and service.
The “Easy-to-Buy-From” company.
KEMET offers a level of responsiveness that far surpasses any other supplier. Our
passion for customer service is evident throughout our global sales organization, which
offers localized support bolstered by our worldwide logistics capabilities. Whether you
need rush samples, technical assistance, in-person consultation, accelerated custom
design, design collaboration or prototype services, we have a solution.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
One World. One KEMET
TC106_FUSED • 10/17/2013
One world. One KEMET
3
Made for you.
When you need custom products delivered on a tight schedule, you can trust KEMET.
Get direct design consultation from global experts, who help you get the job done on
time and within budget.
Working for a better world.
KEMET is dedicated to economically, environmentally and socially sustainable
development. We’ve adopted the Electronic Industry Code of Conduct (EICC) to
address all aspects of corporate responsibility. Our manufacturing facilities have won
numerous environmental excellence awards and recognitions, and our supply chain is
certified. We believe doing the right thing is in everyone’s interest.
About KEMET.
KEMET Corporation is a leading global supplier of electronic components. We offer
our customers the broadest selection of capacitor technologies in the industry across
multiple dielectrics, along with an expanding range of electromechanical devices, and
electromagnetic compatibility solutions. Our vision is to be the preferred supplier of
electronic component solutions for customers demanding the highest standards of
quality, delivery and service.
One world. One KEMET
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
TC106_FUSED
One KEMET
4
One World.
• 10/17/2013
Fused MnO
2
Tantalum Surface Mount Capacitors
T496 Fused MnO
2
Series
Overview
Applications
Typical applications include decoupling and filtering in computing
and telecommunications end applications, such as high-end
servers requiring built-in fuse capability.
The T496 Series of tantalum chip capacitors offers a “fail safe”
design. The built-in fuse element offers excellent protection from
damaging short circuit conditions in applications where damaging
high fault currents exist. Protection from costly circuit damage
due to reversed installation is offered with this device.
Benefits
•
•
•
•
•
•
•
•
•
•
•
Meets or exceeds EIA Standard 535BAAC
Approved to DSCC drawing 04053
Patented fuse assembly
Optional gold-plated terminations
Built-in fuse protects against short circuit mode
100% surge current test on C, D, and X sizes
Halogen-free epoxy
Capacitance values of 0.15 μF to 330 μF
Tolerances of ±10% and ±20%
Voltage rating of 4 – 50 VDC
Fuse activation, 25˚C: within 1 second at fault currents
of 4 amps and higher
• Continuous current capability: 0.75 amps
• Post actuation resistance, 25˚C: 10 MΩ, minimum
• Test tabs on side of case bypass the capacitor element to allow
direct testing of the fuse assembly
• RoHS Compliant and lead-free terminations
• Operating temperature range of -55˚C to +125˚C
Environmental Compliance
RoHS Compliant (6/6) according to Directive 2002/95/EC when ordered with 100% Sn solder.
SPICE
For a detailed analysis of specific part numbers, please visit www.kemet.com for a free download of KEMET's SPICE software.
The KEMET SPICE program is freeware intended to aid design engineers in analyzing the performance of these capacitors over
frequency, temperature, ripple, and DC bias conditions.
One world. One KEMET
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
TC106_FUSED • 10/17/2013
T2010_T496
