DC DC
3 Watts
IR Series
•
•
•
•
•
•
•
Single & Dual Output
SIP Package
1000 VDC Isolation
Optional 3000 VDC Isolation
40 °C to +85 °C Operation
Semi regulated
3 Year Warranty
xppower.com
Specification
Input
Input Voltage Range
Input Reflected
Ripple Current
Input Reverse Voltage
Protection
• Nominal ±10%
• 20 mA pk-pk, 5 Hz to 20 MHz
• None
5 VDC
Input
Voltage
No Load
Output
Input
Voltage
Current
80 mA
70 mA
70 mA
80 mA
80 mA
70 mA
70 mA
70 mA
25 mA
25 mA
25 mA
20 mA
25 mA
25 mA
25 mA
20 mA
5.0 V
9.0 V
12.0 V
15.0 V
±5.0 V
±9.0 V
±12.0 V
±15.0 V
5.0 V
9.0 V
12.0 V
15.0 V
±5.0 V
±9.0 V
±12.0 V
±15.0 V
Max
Output
Load
Capacitive Efficiency
Current
Reg.
Load
600 mA
333 mA
250 mA
200 mA
±300 mA
±167 mA
±125 mA
±100 mA
600 mA
333 mA
250 mA
200 mA
±300 mA
±167 mA
±125 mA
±100 mA
220 µF
220 µF
100 µF
100 µF
±100 µF
±100 µF
±47 µF
±47 µF
220 µF
220 µF
100 µF
100 µF
±100 µF
±100 µF
±47 µF
±47 µF
79%
84%
84%
84%
82%
85%
85%
86%
84%
87%
88%
90%
85%
88%
89%
90%
8.0%
7.0%
6.0%
6.0%
7.0%
6.0%
6.0%
5.0%
6.0%
4.0%
4.0%
3.0%
5.0%
4.0%
3.0%
3.0%
Model
Number
IR0505SA
IR0509SA
IR0512SA
IR0515SA
IR0505S
IR0509S
IR0512S
IR0515S
IR1205SA
IR1209SA
IR1212SA
IR1215SA
IR1205S
IR1209S
IR1212S
IR1215S
Output
Output Voltage
•
Minimum Load
•
Line Regulation
•
Load Regulation
•
Setpoint Accuracy
•
Ripple & Noise
•
Temperature Coefficient
•
Maximum Capacitive
•
Load
See table
None
(1)
1.2%/1%
∆
Vin
See table
+2%, -4%
50 mV pk-pk max, 20 MHz bandwidth
(2)
0.02%/°C
See table
12 VDC
General
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
•
•
•
•
•
•
•
•
•
•
See table
1000 VDC minimum, 3000 VDC option
(3)
10
9
Ω
60 pF typical
Variable, 60 kHz -85 kHz
>1.1 MHrs to MIL-HDBK-217F at 25 °C, GB
-40 °C to +85 °C
-40 °C to +125 °C
100 °C max
Convection-cooled
0.28
(7.20)
Mechanical Details
0.76 (19.50)
0.28
(7.20)
Environmental
Operating Temperature
Storage Temperature
Case Temperature
Cooling
0.02
(0.50)
0.37
(9.50)
0.39
(10.0)
0.12 (3.05)
0.10
(2.54)
0.60 (15.24)
0.02
(0.50)
1
2
4
5
6
7
0.01
(0.25)
0.05 (1.25)
0.02 (0.50)
Notes
1. Operation at no load will not damage unit but it may not meet
all specifications.
2. Output capacitor of 1 µF required to meet quoted ripple and noise.
3. For optional 3 kV isolation, add suffix ‘-H’ to the model number.
4. All dimensions in inches (mm).
5. Pin pitch tolerance: ±0.014 (±0.35)
6. Case tolerance: ±0.02 (±0.5)
7. Weight: 0.006 lbs (2.8 g)
Pin
1
2
4
5
6
7
Single
+Vin
-Vin
-Vout
N.P
+Vout
N.P
Pin Connections
Dual
+Vin
-Vin
-Vout
Common
+Vout
N.P
Single-H
+Vin
-Vin
N.P
-Vout
N.P
+Vout
Dual-H
+Vin
-Vin
N.P
-Vout
Common
+Vout
