Datasheet for 76650-0143
General Information
Part Number:
76650-0143
Manufacturer:
Title:
Molex / Waldom
Deluxe Audio Video Data Application Kit
Includes HDMI, HDMI to DVI-D, MicroCross DVI-D and DVI-I, DisplayPort,
IEEE1394-1395, USB Type A and B, USB OTG (On-the-Go) mini-B, Micro USB-B
Description:
Product Families. Pitches range: 0.05mm (.002)" - 2.0mm (.079)"
MicroCross™ DVI, HDMI^, DisplayPort*, USB, mini-B™ USB OTG, and
Product Family(s):
Micro-USB
Certificates:
(Molex Parts within this kit) - EU RoHS Compliant
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Connector Type:
Mounting
Orientation:
Pitch:
Speeds:
Current Rating:
Voltage:
Wire-to-Board
Receptacles and Plugs, Cables
Upright, Right Angle and Vertical
0.5mm (.020"), 0.65mm (.0256"), 1.00mm (.039")
(2.5 GHz), 480 Mbps, 4.95, 5, 9.9 Gbps
0.5, 1, 1.5, 1.8 and 3 Amps
30, 40, 100, 150, 750 Volts
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 6
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0143
Product Highlights
The MicroCross™ DVI (Digital Visual Interface) connector family is based on
an innovative use of "crossing" ground blades to provide high-speed electrical
performance and a high-bandwidth in a low-cost connector.
Molex's HDMI^ (High Definition Multimedia Interface) connectors and cable
assemblies provide an uncompressed digital link between consumer
electronics equipment and audio/video monitors. HDMI is a small, user-friendly
interconnect that can carry up to 5 Gbps of combined video and audio in a single
cable. This system eliminates the cost, complexity and confusion of multiple cables
used to connect current A/V systems.
^
High Definition Multimedia Interface and HDMI are trademarks of HDMI Licensing, LLC.
The DisplayPort* is designed for internal and external system solution for high
bandwidth audio and video data transfer in the notebook and PC market. It reduces
cost (by having high definition digital audio-video and graphics stream via the
interface through the same cable) and provides ease of use (through the plug-and-
play feature), making it user-friendly for consumers. It also provides
performance scalability for future developments of high quality displays, high color
depths and high refresh rates display.
*
DisplayPort is a Trademark of VESA
The USB (Universal Serial Bus) connector has been one of the most popular I/O
connectors for the PC industry due to it' s low cost and hot plugging feature. It was
developed to integrate a variety of existing PC I/O ports into a single interface with
hot-plugging, automatic configuration capabilities and increased bandwidth to
enhance serial I/O throughput.
Molex's mini-B™ USB OTG (On-The-Go) connectors and cables help enable mobile
devices to exchange data directly without the need for a host PC. All Molex USB
OTG connectors are compatible with the On-The-Go supplement (Rev. 1.0) to the
USB 2.0 specification, and operate at speeds up to 480Mbps.
The new Micro-USB connector technology has given the opportunity for portable
device and mobile phone makers to further reduce their real estate
in their applications. The Molex Micro-USB supports the current USB OTG
supplement. This allows communication between portable devices without
going through a host.
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 2 of 6
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0143
Features and Benefits
• Supports both analog and digital signals
• Plug and play interface (without shutting
down or reconfiguring)
• Excellent EMI/RFI (Fully Shielded)
• LFH™ contact design is rugged and
reliable, provides two points of contact
for optimal signal integrity
• Protruding shield, first make - last break
for ESD considerations
• Single and dual link digital signaling
allows high speed digital transmission
(4.95 Gbps and 9.9 Gbps)
• Analog coaxial lines allow high speed
transmission (2.5 GHz)
• Carries uncompressed audio / video in
a single cable (5 Gbps)
• HDMI^ to DVI cables are DVI backward
compatible
• Fully shielded ESD protection
• Triad signal layout, low impedance
mismatch
• Detent locks, strong mating between
plug and receptacle
• Metal shielding on all sides against EMI
• Small footprint, less PCB real estate
• Latches, for long cable latching
• Solder tab, secure PCB retention
Applications
• Desktop computers
• Multimedia equipment
• Flat panel displays
• Digital TVs/Plasma Displays/LCDs
• Audio/Video Receivers
• Set-Top Boxes
• DVD Players/Recorders/D-VHS Players
• High Definition Monitors
• PC (Personal Computer)
• External display interconnect
• Projector
• TV display
• DVD player
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 3 of 6
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0143
Features and Benefits continued
• Side metal shielding, against EMI/RFI
• Panel grounding pins for ESD protection
• Stand-offs for anti-solder bridging
• Kinked boardlocks, strong PCB retention
• Small footprint saves PCB real estate
• Inlet dimples, locking feature
• Operates at speeds up to 480 Mbps
• Fully compliant with USB 2.0
• Compact and Low-profile, ideal for
mobile applications
• 1/8 the size of standard USB-B
• 5,000 mating cycles, rugged durability
• Lead-in features provide blind mating
• Stainless steel shell provides high
mating durability & strength
• Latching windows with angular tabs
prevent accidental unmating of plug
• Pick & place area (3mm diameter)
enhances assembly process
• Beveled profile B style locks out A-type
Applications continued
• Desktop and Notebook PCs
• PC Peripherals: Scanner, Printer, Monitor,
Modem, Keyboard, Joystick, & Mouse
• Telephony systems: ISDN, PBXs, & Handsets
• Cell phones
• Digital still cameras
• Digital video cameras
• PDAs
• MP3 Players
• Other portable and hand-held devices
• Mobile Phones
• Portable devices
• MP3 players
• Portable digital video players
• Digital Still Cameras
• Digital Video Cameras
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 4 of 6
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0143
Bill of Materials for Part No. 76650-0143
Country
Molex Part No. of Origin
74320-9010
74320-5000
74320-1000
74320-4000
74320-3000
88768-3500
47151-0002
47151-1002
47151-1005
47272-0001
67068-8000
67068-9000
48037-1000
89485-8000
48037-0001
88732-9000
88728-3200
88732-8600
54819-0519
47491-0001
47346-0001
53462-0629
67503-1020
500075-1517
China
China
China
Description
DVI-I Receptacle Header, Right Angle Panel Mount
DVI-D Receptacle Header, Vertical Panel Mount, 30micro
inches Gold
DVI-I Receptacle Header, Right Angle
Quantity in
Kit
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
China/HK DVI-D Receptacle Header, Right Angle Panel Mount
China
China
China
China
China
China
China
China
DVI-I Receptacle Header, Vertical Panel Mount
HDMI^ to DVI-Digital Cable Assembly, 28 AWG, 1.00m (3.30')
1.00mm (.039") Pitch HDMI^ Receptacle, Rt Angle w/Screw
Flange,w/o Back Cover
1.00mm (.039") Pitch HDMI^ Receptacle, Rt Angle w/Screw
Flange, w/Back Cover
1.00mm (.039") Pitch HDMI^ Receptacle, Right Angle, Gold
0.5mm (.020") Pitch, Receptacle, Right Angle, SMT, Display
Port*
USB Type B Receptacle, Right Angle, BLACK
USB Type B Receptacle, Right Angle, WHITE
USB Plug, Type A, Right Angle, Surface Mount, 30μ" Gold
Taiwan Plating,
China
USB Type A Receptacle, Single Upright, Right Angle
Taiwan USB Plug, Type A, Right Angle, Through Hole
USB Shielded I/O Cable Assembly: A-to-B Full-Rated, 0.82m
China (2.69')
China
China
Japan
China
China
China
China
Japan
USB-A Plug to Pigtail White Cable Full-Rated 810mm
USB (OTG) Shielded I/O Cable, USB-A To mini-B™, USB
2.0, 1.0m (3.28'), White
USB (OTG) mini-B™ Receptacle, Right Angle, Through Hole
0.65mm (.0256") Pitch Micro-USB B Receptacle, Mid-Mount,
SMT, Lead Free
0.65mm (.0256") Pitch Micro-USB B Receptacle, Bottom
Mount, SMT, Lead Free
IEEE 1394-1995 Receptacle, Right Angle, SMT
USB On-The-Go (OTG) mini-B™ Receptacle, Right Angle,
SMT
USB On-The-Go (OTG) mini-B™ Receptacle, Vertical,
Through Hole
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
