Jacks
163-5003, 163-5004
Jacks
163-5003 øA= .093 (2.5 mm)
163-5004 øA= .079 (2.1 mm)
.354
.315
A
B
C
øA
.040 x .118-2
holes
ø.5 mm
ø.2 mm
.295
.531
.567
.197
B
.118
A
.040 x .138
C
.236
PCB Hole Layout
.354
.248
.012
.124
.012
.433
.256
.402
.047
.142
ø.039
.098
ø.051
.098
.472
.130
.146
.236
.055
ø.051
.197
.118
ø.2 mm
.531
.138
.157
ø.067
SPECIFICATIONS
Insulation resistance:
Shunt spring:
Tip spring:
Contact resistance:
Insertion force:
1000MΩ @ 500VDC
silver plated brass
silver plated copper alloy
30mΩ max.
0.3-1.5kg
0.3-1.5kg
500V for 1 minute
1.5A @ 18VDC
±.008
PBT
nickel plated
silver plated
withstand more than 5,000 cycles insertion
and withdrawal with test plug
This product should not be washed using a chloride-based wash
Date Last Revised: 3-31-05
DIMENSIONS: In.
(except where noted)
Extraction force:
Voltage test:
Current rating:
General purpose:
Housing & back cover:
Center pin:
Break, pin, & sleeve terminals:
Life time:
163-5003, 163-5004
Available from Mouser Electronics
1-800-346-6873
www.mouser.com
KC-300385
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
