AH103A-PCB900 Overview

RF modules and development tools 900MHz eval brd 29db gain

AH103A
High Gain, High Linearity ½-Watt Amplifier
Product Features
60 – 2700 MHz
+27 dBm P1dB
+46 dBm Output IP3
29 dB Gain @ 900 MHz
Excellent ACPR
MTTF > 100 Years
Lead-free/green/RoHS-compliant
SOIC-8 Package w/ heat slug
Product Description
The AH103A is a high gain, high linearity ½-Watt
amplifier. This device is comprised of two individual
MMIC amplifiers internally and can be used with an
external interstage match for any of the mobile
infrastructure frequency bands.
The dual-stage
amplifier achieves up to +46 dBm IP3 performance
with 29 dB gain.
The device conforms to WJ Communications’ long
history of producing high reliability and quality
components. The AH103A has an associated MTTF
of a minimum of 100 years at a mounting
temperature of 85
°C
and is housed in a lead-free
/green/RoHS-compliant SOIC-8 package.
All
devices are 100% RF & DC tested.
The product is targeted for use as driver amplifiers
for wireless infrastructure where high performance
and high linearity are required.
Functional Diagram
1
AMP 2
2
3
AMP 1
7
8
6
4
5
Applications
Mobile Infrastructure
W-LAN / ISM / RFID
MDS / MMDS Infrastructure
Pin No.
1
2
3, 5, 8,
Ground
Backside copper
RF in (Amp1 in)
4
RF out (Amp2 out)
6
Bias 2
7
Function
Amp2 in
Amp1 out / Bias 1
Specifications
(1)
Parameter
Operational Bandwidth
Test Frequency
Gain
Output IP3
Output P1dB
Test Frequency
Gain
Input Return Loss
Output Return Loss
Output IP3
(2)
Output P1dB
Noise Figure
Supply Voltage (Amp1)
Supply Voltage (Amp2)
Operating Current
(3)
Typical Performance
(1)
Units
MHz
MHz
dB
dB
dBm
MHz
dB
dB
dB
dBm
dBm
dB
V
V
mA
Min
60
Typ
900
29.1
+46
+27
1900
25.4
19
11
+45
+26.7
3
+4.5
+9
275
Max
2700
Parameter
Frequency
Gain
Input Return Loss
Output Return Loss
Output IP3
Output P1dB
IS-95 Ch. Power
(4)
@ -45 dBc ACPR
Units
MHz
dB
dB
dB
dBm
dBm
dBm
(5)
Typical
900
29.1
20
19
+46
+27
+20.7
1900
25.4
19
11
+45
+26.7
+20.5
+18.5
2.5
3
2.9
+4.5 V @ 75 mA
+9 V @ 200 mA
2140
25
24
11
+45
+26.3
23.5
W-CDMA Ch. Power
@ -45 dBc ACPR / ACLR
dBm
dB
+42
+25
Noise Figure
Supply Bias Amp1
Supply Bias Amp2
225
330
4. ACPR is measured at 900 and 1900 MHz with a IS-95, 9 Channels Forward, ±885 kHz offset, 30
kHz BW, 1.23 MHz Channel BW.
5. ACLR is measured at 2140 MHz with a 3GPP W-CDMA, Test Model 1+64 DPCH, ±5 MHz
offset, 3.84 MHz Channel BW.
1. Test conditions unless otherwise noted: 25 ºC, Vdd1 = +4.5 V, Vdd2 = +9 V, in a tuned application circuit.
2. 3OIP measured with two tones at an output power of +8 dBm/tone separated by 10 MHz. The
suppression on the largest IM3 product is used to calculate the 3OIP using a 2:1 rule.
3. Amp1 and Amp2 have a typical current draw of 75 and 200 mA, respectively.
Absolute Maximum Rating
Parameter
Storage Temperature
DC Voltage (pin 2)
DC Voltage (pin 6, 7)
RF Input Power (continuous)
Junction Temperature
Thermal Resistance
Rating
-55 to +125
°C
+6 V
+11 V
4 dB above Input P1dB
+160
°C
21° C / W
Ordering Information
Part No.
AH103A-G
AH103A-PCB900
AH103A-PCB1900
AH103A-PCB2140
Description
High Gain ½-Watt Amplifier
(lead-free/green/RoHS-compliant SOIC-8 Pkg)
0.7 – 1.0 GHz Evaluation Circuit
1.8 – 2.0 GHz Evaluation Circuit
2.1 – 2.2 GHz Evaluation Circuit
Operation of this device above any of these parameters may cause permanent damage.
Standard T/R size = 500 pieces on a 7” reel.
Specifications and information are subject to change without notice
WJ Communications, Inc
Phone 1-800-WJ1-4401
FAX: 408-577-6621
e-mail: sales@wj.com
Web site: www.wj.com, www.TriQuint.com
Page 1 of 6 December 2007
