1210N270F250LT

Description
CAPACITOR, CERAMIC, MULTILAYER, 25V, C0G, 0.000027uF, SURFACE MOUNT, 1210, CHIP, LEAD FREE
CategoryPassive components    capacitor
File Size662KB,10 Pages
ManufacturerWalsin Technology Corporation
Environmental Compliance
Download Datasheet Parametric View All

1210N270F250LT Overview

CAPACITOR, CERAMIC, MULTILAYER, 25V, C0G, 0.000027uF, SURFACE MOUNT, 1210, CHIP, LEAD FREE

1210N270F250LT Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
Objectid2131960696
package instruction, 1210
Reach Compliance Codecompliant
ECCN codeEAR99
YTEOL0
capacitance0.000027 µF
Capacitor typeCERAMIC CAPACITOR
dielectric materialsCERAMIC
high0.95 mm
JESD-609 codee3
length3.2 mm
Manufacturer's serial number1210
Installation featuresSURFACE MOUNT
multi-layerYes
negative tolerance1%
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package shapeRECTANGULAR PACKAGE
Package formSMT
method of packingTR, PLASTIC, 7 INCH
positive tolerance1%
Rated (DC) voltage (URdc)25 V
series1210(NP0,25V)
size code1210
surface mountYES
Temperature characteristic codeC0G
Temperature Coefficient30ppm/Cel ppm/°C
Terminal surfaceTin (Sn) - with Nickel (Ni) barrier
Terminal shapeWRAPAROUND
width2.5 mm
MULTILAYER CERAMIC CAPACITORS
General Purpose Capacitors
1. DESCRIPTION
MLCC consists of a conducting material and electrodes. To manufacture a chip-type SMT and achieve miniaturization,
high density and high efficiency, ceramic condensers are used.
WTC’s MLCC is made by NP0, X7R and Y5V dielectric material and which provides product with high electrical
precision, stability and reliability.
2. FEATURES
a.
b.
c.
A wide selection of sizes is available (0402 to 1812).
High capacitance in given case size.
Capacitor with lead-free termination (pure Tin).
3. APPLICATIONS
a.
b.
c.
d.
For
For
For
For
general digital circuit.
power supply bypass capacitors.
consumer electronics.
telecommunication.
4. HOW TO ORDER
1206
Size
Inch (mm)
0402
(1005)
0603
(1608)
0805
(2012)
1206
(3216)
1210
(3225)
1812
(4532)
F
Dielectric
N=NP0
(C0G)
B=X7R
F=Y5V
104
Capacitance
Two significant
digits followed by
no. of zeros. And R
is in place of
decimal point.
eg.:
0R5=0.5pF
1R0=1.0pF
104=10x10
4
=100nF
Z
Tolerance
B=±0.1pF
C=±0.25pF
D=±0.5pF
F=±1%
G=±2%
J=±5%
K=±10%
M=±20%
Z=-20/+80%
500
Rated voltage
Two significant digits
followed by no. of zeros.
And R is in place of
decimal point.
100=10
VDC
160=16
VDC
250=25
VDC
500=50
VDC
101=100
VDC
C
Termination
C=Cu/Ni/Sn
(for NP0,
X7R, Y5V dielectric)
L=Ag/Ni/Sn
(for partial
NP0 items)
T
Packaging style
T=7”
reeled
R=7”
reeled (2mm
pitch for 0603 size;
paper tape)
G=13”
reeled
* Partial NPO items are with Ag/Ni/Sn terminations, please ref to below product range of NPO dielectric for detail.
5. EXTERNAL DIMENSIONS
Size
Inch (mm)
0402 (1005)
0603 (1608)
L (mm)
1.00±0.05
1.60±0.10
1.60
+0.15/-0.10
2.00±0.15
2.00±0.20
W (mm)
0.50±0.05
0.80±0.10
0.80
+0.15/-0.10
1.25±0.10
1.25±0.20
T (mm)/Symbol
0.50±0.05
0.80±0.07
0.80
+0.15/-0.10
0.60±0.10
0.80±0.10
1.25±0.10
1.25±0.20
0.80±0.10
0.95±0.10
1.15±0.15
1.25±0.10
3.20±0.20
1.60±0.20
1.60±0.20
N
S
X
A
B
D
I
B
C
J
D
G
P
C
D
G
K
M
D
K
#
#
#
#
#
#
#
#
#
#
#
0.75±0.25
0.60±0.20
#
#
M
B
M
B
Remark
#
M
B
(mm)
0.25
+0.05/-0.10
L
T
0.40±0.15
W
0805 (2012)
0.50±0.20
Fig. 1 The outline of MLCC
3.20±0.15
1206 (3216)
1.60±0.15
3.20+0.3/-0.1 1.60+0.3/0.1 1.60+0.30/-0.10
0.95±0.10
3.20±0.30
2.50±0.20
1.25±0.10
1210 (3225)
1.60±0.20
3.20±0.40
2.50±0.30
2.00±0.20
2.50±0.30
1.25±0.10
1812 (4532)
4.50±0.40
3.20±0.30
2.00±0.20
# Reflow soldering only is recommended.
0.75±0.25
WALSIN TECHNOLOGY CORPORATION
566-1,Kao-Shi Road, 5 Lin, Yang-Mei, Tao-Yuan, Taiwan
www.passivecomponent.com
00-T-001K_DS_GP
Revision K
1/10
Mar. 09 2010
