Type AVGA
–40 °C to +105 °C
High Capacitance SMT Aluminum Electrolytic Capacitors
For Filtering, Bypassing and Power Supply Decoupling with High Capacitance Requirements
Type AVGA Capacitors are rated for 2000 hours at 105 ºC and up to
63 Vdc. They are ideal for high density PC board packaging. The
Type AVGA offers a low in-place-cost for a high quality performer.
The vertical cylindrical cases facilitate automatic mounting and reflow
soldering into the same footprint of like-rated tantalum capacitors
except without the need for voltage derating. Type AVGA is RoHS
compliant.
Highlights
•
+105
°C,
Up to 2000 Hours Load Life
•
Capacitance Range: 0.1 µF to 4700 µF
•
Voltage Range: 6.3 Vdc to 63 Vdc
–40 °C to +105 °C
6.3, 10, 16, 25, 35, 50, 63 Vdc
0.1µF to 4700
µF
±20% @ 120 Hz and +20 °C
6.3 – 63 V
4 – 10 Ø
Specifications
12.5 ~ 16 Ø
M
EN
Dissipation Factor:
(Tan
d
at 120 Hz, 20 ºC)
4 ~ 10 Ø
D
Rated Voltage
12.5 ~ 16 Ø
ED
I = leakage current
FO
Leakage Current (at 20 ºC):
I = 0.01 CV or 3 µA, whichever is greater, after 2 minutes at +20 ºC
I = 0.03 CV or 4 µA, whichever is greater, after 2 minutes at +20 ºC
V = rated DC Working voltage in V
C = rated capacitance in µF
6.3
0.4
10
16
0.28
0.34
R
Operating Temperature:
Rated Voltage:
Capacitance:
Capacitance Tolerance:
25
0.18
0.26
N
0.45
0.35
0.38
When the capacitance exceeds 1000 µF, .02 shall be added for every 1000 µF increase
Low Temperature
Characteristic (at 120 Hz):
Rated Voltage
Z(–25 ºC)
4 ~ 10 Ø
6.3
4
10
3
4
8
EW
35
0.16
0.22
50
0.14
0.18
16
2
3
6
25
2
2
4
35
2
2
3
M
O
Impedance
/Z(+20 ºC) 12.5 ~ 16 Ø 5
Ratio
Z(–40 ºC) 4 ~ 10 Ø 12
EC
/Z(+20 ºC) 12.5 ~ 16 Ø 10 8
6
4
3
3
3
Impedance ratio shall not exceed the values given in the table above.
Test Time
Capacitance Change
Dissipation Factor
Leakage Current
8 ~ 16 Ø
2,000 Hours
4 ~ 6.3 Ø : Within ±25 % of initial value
: Within ±20 % of initial value
Within specified value
< 200% of specified value
O
T
R
Load Life Test:
N
* The above specifications shall be satisfied when the capacitors are
restored to 20 ºC after the rated voltage is applied for 2,000 hrs at 105 ºC
Shelf LifeTest:
Test time: 1000 hours; other items are the same as those for life test.
Complies with the EU Directive 2002/95/EC requirement
restricting the use of Lead (Pb), Mercury (Hg), Cadmium
(Cd), Hexavalent chromium (Cr(VI)), PolyBrominated
Biphenyls (PBB) and PolyBrominated Diphenyl Ethers
(PBDE).
