PL313-98.0M datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> oscillator> PL313-98.0M

PL313-98.0M: DescriptionLVPECL Output Clock Oscillator, 98MHz Nom, ROHS COMPLIANT,HERMETIC SEALED, CERAMIC PACKAGE-6; CategoryPassive components oscillator; File Size255KB，2 Pages; ManufacturerConnor-Winfield; Websitehttp://www.conwin.com/; Environmental Compliance

Download Datasheet Parametric View All

PL313-98.0M Overview

LVPECL Output Clock Oscillator, 98MHz Nom, ROHS COMPLIANT,HERMETIC SEALED, CERAMIC PACKAGE-6

PL313-98.0M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Connor-Winfield
package instruction	ROHS COMPLIANT,HERMETIC SEALED, CERAMIC PACKAGE-6
Reach Compliance Code	unknown
Other features	TRI-STATE; ENABLE/DISABLE FUNCTION; TAPE AND REEL
maximum descent time	1 ns
Frequency Adjustment - Mechanical	NO
frequency stability	25%
Installation features	SURFACE MOUNT
Nominal operating frequency	98 MHz
Maximum operating temperature	85 °C
Minimum operating temperature
Oscillator type	LVPECL
Output load	50 OHM
physical size	7.0mm x 5.0mm x 1.75mm
longest rise time	1 ns
Maximum supply voltage	3.465 V
Minimum supply voltage	3.135 V
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	55/45 %
Base Number Matches	1

Preview

Download Datasheet

View All

Surface Mount

LVPECL

Clock Oscillator

Description:

2111 Comprehensive Drive

Aurora, Illinois 60505

Phone: 630- 851- 4722

Fax: 630- 851- 5040

www.conwin.com

US Headquarters:

630-851-4722

European Headquarters:

+353-61-472221

The Connor Winfield PLxxx - Series are

5 x 7mm Surface Mount, LVPECL, Fixed

Frequency Crystal Controlled Oscillator (XO)

designed for applications requiring tight

frequency stability, wide temperature range

and low jitter. Operating at 3.3V supply

voltage, the PLxxx - Series provides an

LVPECL Differential Outputs with enable /

disable function. The surface mount package

is designed for high-density mounting and is

optimum for mass production.

Features:

Model PLxxx - Series

5 x 7mm Surface Mount Package

3.3V Operation

LVPECL Differential Outputs

Frequency Stabilities Available:

+/-20 ppm,+/-25 ppm, +/-50 ppm, +/-100 ppm

Temperature Ranges Available:

0 to 70°C, -40 to 85°C, 0 to 85°C, -20 to 70°C

Low Jitter <0.6ps RMS

Tri-State Enable/Disable on Pad 1

Tape and Reel Packaging

RoHS Compliant / Lead Free

1032

PL14

496 M 3

Absolute Maximum Ratings

Storage Temperature

Supply Voltage (Vcc)

Input Voltage (Vc)

Parameter

Minimum

-55

-0.5

Nominal

Maximum

125

4.6

Vcc + 0.5

Units

°C

Vdc

Notes

Operating Specifications

Output Frequency (Fo)

800

Total Frequency Tolerance

(See Ordering Information for full part number)

Model PLx43

-20

Model PLx13

-25

Model PLx23

-50

Model PLx33

-100

100

Operating Temperature Range

Model PL1x3

Model PL2x3

-40

Model PL3x3

Model PL4x3

-20

Supply Voltage (Vcc)

3.135

3.3

3.465

Supply Current (Icc)

Jitter:

Period Jitter

3.0

5.0

Integrated Phase Jitter

0.6

1.0

SSB Phase Noise for Fo=496 MHz

@ 100 Hz offset

-90

@ 1 KHz offset

-105

@ 10 KHz offset

-110

@ 100 KHz offset

-115

@ 1 MHz offset

-125

@ 10 MHz offset

-145

Start-Up Time

Parameter

Minimum

Nominal

Maximum

Units

MHz

ppm

°C

Vdc

ps RMS

dBc/Hz

Notes

Input Characteristics

Enable Input Voltage - (High) -(Vih)

Disable Input Voltage - (Low) - (Vil)

Parameter

Minimum

70%Vcc

Nominal

Maximum

30%Vcc

Units

Vdc

Notes

LVPECL Output Characteristics

Load

Voltage (High) (Vcc = 3.3 V) (Voh)

(Low) (Vcc = 3.3 V) (Vol)

Duty Cycle at 50% Level

Rise / Fall Time: 20% to 80%

Parameter

Minimum

2.275

Nominal

0.5

Maximum

1.680

1.0

Units

Ohm

Notes

Ordering Information

Type

LVPECL

Clock Series

5x7 mm

Temperature

Range

1 = 0 to 70°C

2 = -40 to 85°C

3 = 0 to 85°C

4 = -20 to 70°C

Frequency

Stability

4 = ±20 ppm

1 = ±25 ppm

2 = ±50 ppm

3 = ±100 ppm

Supply Voltage

- 496.0M

Output Frequency

Bulletin

Page

Revision

Date

Ec268

1 of 2

13 Oct 2011

Frequency Format

-xxx.xM Min

-xxx.xxxxxxM Max

3 = 3.3 Vdc, E/D Pad 1

*Amount of numbers

after the decimal

point. M = MHz

Example: Part Number

PL143-496.0M = LVPECL Output,

0 to 70, +/-20ppm, 3.3Vdc, E/D Pad 1, Output Frequency 496 MHz
