SPECIFICATIONS
PARAMETERS
RATED VOLTAGE
OPERATING VOLTAGE RANGE
RATED CURRENT (MAX)
COIL RESISTANCE
MINIMUM SPL @ 10 CM
RESONANT FREQUENCY
OPERATING TEMPERATURE
STORAGE TEMPERATURE
HOUSING MATERIAL
TERMINAL MATERIAL
WEIGHT
VALUES
3.6
2.5 ~ 4.5
100
15 ± 3
85
2,700 ± 500
-40 ~ +85
-40 ~ +85
LCP
Sn PLATED BRASS
0.4
UNIT
Vp-p
Vp-p
mA
OHM
dBA
Hz
°C
°C
-
-
grams
THIS DOCUMENT CONTAINS DATA PROPRIETARY TO
PROJECTS UNLIMITED, INC. ANY USE OR
REPRODUCTION, IN ANY FORM, WITHOUT PRIOR
WRITTEN PERMISSION OF PROJECTS UNLIMITED,
INC. IS PROHIBITED.
©2003, Projects Unlimited Inc.
LTR
-
A
REVISION HISTORY
DESCRIPTION
RELEASED FROM ENGINEERING
REVISED TO INVENTOR 3-D DRAWING TEMPLATE
DATE
1/18/2006
5/4/2010
APPROVED
B.R.
POLARITY
PAD (+)
7.5
`
0.2
0.5
DUMMY
PAD
4.9
7.5
`
0.2
2.5
2.7
4.9
SOUND
EMISSION
HOLE
DUMMY
PAD
POLARITY
PAD (-)
0.15
2.5
`
0.2
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS.
2. SPECIFICATIONS SUBJECT TO CHANGE OR WITHDRAWL
WITHOUT NOTICE.
3. THIS PART IS RoHS 2002/95/EC COMPLIANT.
UNLESS OTHERWISE
SPECIFIED:
DIMENSIONS ARE IN
MILLIMETERS,
TOLERANCES
ARE ±0.5 AND
ANGLES ARE ±3°.
Designed by
Date
Checked by
Date
Approved by
Date
Drawn Date
SIZE
J.A.F.
1/18/2006
E.P.
1/18/2006
B.R.
1/18/2006
5/4/2010
A3
SMT-0827-S-R
Transducer (Electro-Mech)
Edition
Sheet
SMT-0827-S-R.idw
-
1/1
