8
VICOR CONFIDENTIAL
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
7
6
5
4
3
2
REVISIONS
REV
1
DESCRIPTION
RELEASED PER E050348
REVISED PER E091652
REDRAWN PER E100871
DATE
1
APPROVED
ECF
REJH
KUK
F
PEI
JS
11/15/05
09/11/09
#30 DRILL THRU
( .1285 )
(6) PL.
SEE NOTE 6
2
3
F
DCS
6/29/10
E
E
2.22
2.000
D
D
.11
.50
1.800
.100
TYP
SEE NOTE 5
.910
3.600
4.600
C
C
.90
-A-
.005
B
.190
.100
.010
MATL TO BE
REMOVED
B
DRAWN
DATE
05/97
A
NOTES:
1.
MATERIAL; EXTRUSION SEE SHEET 2 OF 2.
2.
REMOVE ALL BURRS AND SHARP EDGES.
3.
CLEAR FINISH, RoHS COMPLIANT PER CST-0001 LATEST REVISION.
4.
" " DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.'
5.
DIMENSIONS APPLIES AT SURFACE -A- (2) PL.
6.
MACHINED SURFACE TO BE .010 MAX BELOW SURFACE -A- (60 PL.
7.
DIMENSIONS ARE INCHES ONLY.
8
7
6
5
4
D.P. KELLY
MATERIAL
SEE NOTES
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE INCH [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HS CFG "A", .90H, X-FLOW,
LOW FLOW, THRU HOLE
SIZE
CAGE CODE
DWG NO
REV
A
FINISH
SEE NOTES
C
DO NOT SCALE DRAWING
67131
30723
SHEET 1 OF 2
3
1
SCALE 2 : 1
3
2
8
VICOR CONFIDENTIAL
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
7
6
5
4
3
2
REVISIONS
REV
#1
DESCRIPTION
DRAWN FOR DEVELOPMENT
DATE
1
APPROVED
XXX
F
XXX
MM/YY
F
E
3°
1.5 EACH
SIDE OF VERT
SEE DETAIL A
A
1.756
R.018
(2) PL.
E
.910
R.035
.024
.034
D
.200
.215
.035
.040
R.030
(32) PL.
.080
(14) PL.
.748
D
.110
* .086
(10) PL.
* 1.408
(2) PL.
* .217
(3) PL.
R.035
(30) PL.
* .212
(12) PL.
* .084
(6) PL.
R.010
(2) PL.
C
+.020
4.600
- .000
.017
(2) PL.
.187
C
L
C
* .086
DETAIL A
SCALE 4 : 1
B
PROFILE COMMON
FOR
30196
30723
B
NOTES:
1.
2.
3.
4.
5.
6.
MATL; ALUMINUM 6063-T5
* DENOTES DIMENSION TO THEORETICAL SHARP CORNER.
ALL DIMENSIONS ARE CRITICAL CHARACTERISTICS.
RoHS COMPLIANT PER CST-0001 LATEST REVISION.
WORKMANSHIP STANDARDS WS-0004, WS-0006, AND WS-0007 APPLY TO THIS PART.
DIMENSIONS ARE INCHES ONLY.
DRAWN
JSARIPELLA
MATERIAL
SEE NOTES
DATE
09/11/09
VICOR
SWD
A
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE INCH [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HS CFG "A", .90H, X-FLOW, LOW
FLOW, THRU HOLE, EXTRUSION
SIZE
CAGE CODE
DWG NO
REV
A
FINISH
SEE NOTES
C
DO NOT SCALE DRAWING
67131
30723
SHEET 2 OF 2
3
1
SCALE 2 : 1
8
7
6
5
4
3
2
