Extract from the online
catalog
STU 35/ 4X10
Order No.: 3033126
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3033126
Feed-through modular terminal block, Type of connection: Screw
connection, Screw connection, Cross section: 1.5 mm² - 50 mm²,
AWG 16 - 1/0, Width: 16.2 mm, Color: gray, Mounting type: NS
35/7.5, NS 35/15
Product notes
Commercial data
GTIN (EAN)
4
046356
094078
WEEE/RoHS-compliant since:
07/21/2008
sales group
Pack
Customs tariff
Catalog page information
A630
25 pcs.
85369010
Page 133 (CL-2009)
http://
www.download.phoenixcontact.com
Please note that the data given
here has been taken from the
online catalog. For comprehensive
information and data, please refer
to the user documentation. The
General Terms and Conditions of
Use apply to Internet downloads.
Technical data
General
Number of levels
Color
Insulating material
Inflammability class acc. to UL 94
1
gray
PA
V0
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 1 / 5
Feb 9, 2011
STU 35/ 4X10
Order No.: 3033126
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3033126
Dimensions
Width
Length
Height NS 35/7.5
Height NS 35/15
Technical data
Rated surge voltage
Pollution degree
Surge voltage category
Insulating material group
Connection in acc. with standard
Nominal current I
N
Nominal voltage U
N
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section stranded min.
Conductor cross section stranded max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded, with ferrule
without plastic sleeve min.
Conductor cross section stranded, with ferrule
without plastic sleeve max.
Conductor cross section stranded, with ferrule
with plastic sleeve min.
Conductor cross section stranded, with ferrule
with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded
min.
2 conductors with same cross section, stranded
max.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, min.
1.5 mm²
50 mm²
1.5 mm²
35 mm²
16
1/0
1.5 mm²
35 mm²
1.5 mm²
35 mm²
1.5 mm²
16 mm²
1.5 mm²
10 mm²
1.5 mm²
8 kV
3
III
I
IEC 60947-7-1
125 A
1000 V
16.2 mm
86 mm
46.8 mm
54.3 mm
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 2 / 5
Feb 9, 2011
STU 35/ 4X10
Order No.: 3033126
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3033126
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, max.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, min.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, max.
Type of connection
Stripping length
Internal cylindrical gage
Tightening torque, min
Tightening torque max
Certificates / Approvals
Certification
10 mm²
1.5 mm²
10 mm²
Screw connection
18 mm
B9
3.2 Nm
3.7 Nm
UL
Accessories
Item
Assembly
3022218
CLIPFIX 35
Snap-on end bracket, for 35 mm NS 35/7.5 or NS 35/15 DIN
rail, can be fitted with Zack strip ZB 8 and ZB 8/27, terminal strip
marker KLM 2 and KLM, width: 9.5 mm, color: gray
End clamp, for assembly on NS 32 or NS 35/7.5 DIN rail
DIN rail, material: Copper, unperforated, height 7.5 mm, width 35
mm, length: 2 m
DIN rail, material: Steel, galvanized and passivated with a thick
layer, perforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail, material: Steel, unperforated, height 7.5 mm, width 35
mm, length: 2 m
DIN rail, deep-drawn, high profile, unperforated, 1.5 mm thick,
material: Aluminum, height 15 mm, width 35 mm, length 2 m
DIN rail, material: Copper, unperforated, 1.5 mm thick, height 15
mm, width 35 mm, length: 2 m
DIN rail, material: Steel, perforated, height 15 mm, width 35 mm,
length: 2 m
DIN rail, material: Steel, unperforated, height 15 mm, width 35
mm, length: 2 m
DIN rail, material: Steel, unperforated, 2.3 mm thick, height 15
mm, width 35 mm, length: 2 m
Designation
Description
1201442
0801762
0801733
0801681
1201756
1201895
1201730
1201714
1201798
E/UK
NS 35/ 7,5 CU UNPERF
2000MM
NS 35/ 7,5 PERF 2000MM
NS 35/ 7,5 UNPERF 2000MM
NS 35/15 AL UNPERF 2000MM
NS 35/15 CU UNPERF 2000MM
NS 35/15 PERF 2000MM
NS 35/15 UNPERF 2000MM
NS 35/15-2,3 UNPERF 2000MM
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 3 / 5
Feb 9, 2011
STU 35/ 4X10
Order No.: 3033126
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3033126
Bridges
3030284
3030297
3030307
3030310
3030323
General
3047138
AGK 4-UT 35
Pick-off terminal block, Width: 8.2 mm, Height: 34.7 mm,
Color: gray
FBS 2-8
FBS 3-8
FBS 4-8
FBS 5-8
FBS 10-8
Plug-in bridge, Number of positions: 2, Color: red
Plug-in bridge, Number of positions: 3, Color: red
Plug-in bridge, Number of positions: 4, Color: red
Plug-in bridge, Number of positions: 5, Color: red
Plug-in bridge, Number of positions: 10, Color: red
Marking
0811228
0811972
X-PEN 0,35
ZB 15:UNBEDRUCKT
Marker pen without ink cartridge, for manual labeling of markers,
labeling extremely wipe-proof, line thickness 0.35 mm
Zack marker strip, unprinted: 5-section, for individual labeling with
M-PEN, ZB-T or CMS system, sufficient for 100 terminal blocks,
for a terminal width of 15 mm, color: White
Plug/Adapter
0201689
0201676
0201692
0201744
3030925
3031005
3030860
Tools
1206612
SZF 3-1,0X5,5
Actuation tool, for ST terminal blocks, also suitable for use as a
bladed screwdriver, size: 1.0 x 5.5 x 150 mm, 2-component grip,
with non-slip grip
MPS-IH BU
MPS-IH RD
MPS-IH YE
MPS-MT
PAI-4
PS-8
RB ST 6-(2,5/4)
Insulating sleeve, Color: blue
Insulating sleeve, Color: red
Insulating sleeve, Color: yellow
Test plugs
Test adapter, Color: gray
Test adapter, Color: red
Reducing bridge, Number of positions: 2, Color: red
Diagrams/Drawings
Circuit diagram
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 4 / 5
Feb 9, 2011
STU 35/ 4X10
Order No.: 3033126
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3033126
Address
PHOENIX CONTACT Deutschland GmbH
Flachsmarktstr. 8
32825 Blomberg,Germany
Phone +49 5235 3 12000
Fax +49 5235 3 41200
http://www.phoenixcontact.de
© 2011 Phoenix Contact
Technical modifications reserved;
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 5 / 5
Feb 9, 2011
