Extract from the online
catalog
USEN 18 N
Order No.: 3048360
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3048360
Fuse terminal blocks for NEOZED fuse inserts
Product notes
Commercial data
GTIN (EAN)
4
017918
976279
WEEE/RoHS-compliant since:
12/01/2005
sales group
Pack
Customs tariff
Catalog page information
A041
10 pcs.
85363030
Page 378 (CL-2009)
http://
www.download.phoenixcontact.com
Please note that the data given
here has been taken from the
online catalog. For comprehensive
information and data, please refer
to the user documentation. The
General Terms and Conditions of
Use apply to Internet downloads.
Technical data
General
Number of levels
Number of connections
Color
Insulating material
Inflammability class acc. to UL 94
1
2
light gray
Duroplast
V0
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 1 / 5
Feb 25, 2011
USEN 18 N
Order No.: 3048360
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3048360
Dimensions
Width
Length
Height NS 35/7.5
Height NS 35/15
Technical data
Fuse
Fuse type
Rated surge voltage
Pollution degree
Surge voltage category
Insulating material group
Nominal current I
N
Nominal voltage U
N
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section stranded min.
Conductor cross section stranded max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded, with ferrule
without plastic sleeve min.
Conductor cross section stranded, with ferrule
without plastic sleeve max.
Conductor cross section stranded, with ferrule
with plastic sleeve min.
Conductor cross section stranded, with ferrule
with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded
min.
2 conductors with same cross section, stranded
max.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, min.
1.5 mm²
35 mm²
1.5 mm²
35 mm²
16
2
1.5 mm²
25 mm²
1.5 mm²
25 mm²
1.5 mm²
10 mm²
1.5 mm²
10 mm²
1.5 mm²
D 02 / E 18
Screw cartridge
6 kV
2
III
IIIa
63 A (the current is determined by the fuse used)
400 V (the voltage is determined by the fuse used)
27 mm
84 mm
75 mm
82.5 mm
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 2 / 5
Feb 25, 2011
USEN 18 N
Order No.: 3048360
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3048360
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, max.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, min.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, max.
Cross-section with insertion bridge, solid max.
Cross-section with insertion bridge, stranded max.
Type of connection
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
Certificates / Approvals
10 mm²
1.5 mm²
10 mm²
25 mm²
25 mm²
Screw connection
19 mm
B8
M6
3.5 Nm
4 Nm
Certification
GL
Accessories
Item
Assembly
0913210
0913223
0913236
0913249
0913252
0913155
0913168
0913171
0913184
0913317
HS 2 A
HS 4 A
HS 6 A
HS 10 A
HS 16 A
HS 20 A
HS 25 A
HS 35 A
HS 50 A
SH-SE 14/18
Adapter sleeve, Nominal current: 2 A, Color: Pink
Adapter sleeve, Nominal current: 4 A, Color: brown
Adapter sleeve, Nominal current: 6 A, Color: green
Adapter sleeve, Nominal current: 10 A, Color: red
Adapter sleeve, Nominal current: 16 A, Color: gray
Adapter sleeve, Nominal current: 20 A, Color: blue
Adapter sleeve, Nominal current: 25 A, Color: yellow
Adapter sleeve, Nominal current: 35 A, Color: black
Adapter sleeve, Nominal current: 50 A, Color: white
NEOZED special spring, for using fuse inserts D 01, in threaded
caps D 02, for 2 A ... 16 A
Designation
Description
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 3 / 5
Feb 25, 2011
USEN 18 N
Order No.: 3048360
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3048360
Bridges
3009341
3009354
Fuse
0913016
0913029
0913032
0913045
0913058
0913061
0913074
0913087
0913090
0913100
General
0814270
Tools
1206612
SZF 3-1,0X5,5
Actuation tool, for ST terminal blocks, also suitable for use as a
bladed screwdriver, size: 1.0 x 5.5 x 150 mm, 2-component grip,
with non-slip grip
MA 20X 8 BK
Marker carrier, for SS-ZB contactor marking Zack marker strip
S 2 A/380 V
S 4 A/380 V
S 6 A/380 V
S 10 A/380 V
S 16 A/380 V
S 20 A/380 V
S 25 A/380 V
S 35 A/380 V
S 50 A/380 V
S 63 A/380 V
Fuse insert, Nominal current: 2 A, Color: Pink
Fuse insert, Nominal current: 4 A, Color: brown
Fuse insert, Nominal current: 6 A, Color: green
Fuse insert, Nominal current: 10 A, Color: red
Fuse insert, Nominal current: 16 A, Color: gray
Fuse insert, Nominal current: 20 A, Color: blue
Fuse insert, Nominal current: 25 A, Color: yellow
Fuse insert, Nominal current: 35 A, Color: black
Fuse insert, Nominal current: 50 A, Color: white
Fuse insert, Nominal current: 63 A, Color: copper
EB 36-27
EB 36-27/L1-L2-L3
Insertion bridge, Number of positions: 36, Color: gray
Insertion bridge, Number of positions: 36, Color: gray
Diagrams/Drawings
Circuit diagram
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 4 / 5
Feb 25, 2011
USEN 18 N
Order No.: 3048360
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3048360
Address
PHOENIX CONTACT Deutschland GmbH
Flachsmarktstr. 8
32825 Blomberg,Germany
Phone +49 5235 3 12000
Fax +49 5235 3 41200
http://www.phoenixcontact.de
© 2011 Phoenix Contact
Technical modifications reserved;
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 5 / 5
Feb 25, 2011
