Recommended PC Board Layout
A
B
B
C
D
SPECIFICATIONS
Current rating:
Contact material:
Contact plating:
Contact resistance:
Insulation material:
Insulation resistance:
Withstanding:
Operating temperature:
Soldering Temp:
C
2 amps
Phosphor bronze
Gold flash, gold, tin (see chart)
20 milliohms max.
Polyester, Nylon 6T/9T, UL94V-0
1,000 megohms min.
500VAC for 1 min.
-40°C to +105°C
250°C 10Sec
260°C 5 Sec (HT)
D
E
F
RoHS compliant
Rev.
Description
Date
Approved
Series
Rows
Contacts
Tail length
Plating
Options
BRS
XX
XX
X
XX
XX
2mm receptacle 01=Single Single row 1-40 A=2.5mm
TN=Tin
[blank]=None
strip
02=Dual Dual row 2-80 CS=Custom tail GD=Gold flash
SM=Surface mount
GD10=10µ” gold HT=High Temp
GD15=15µ” gold
GD30=30µ” gold
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
Date
04/23/07
04/23/07
04/23/07 Part No.:
E
F
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
G
BRS-02-XX-A-XX
7
8
9
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Receptacle strip, female, double row, .079” (2.00mm)
pitch, 4.4mm profile, straight type
G
1
2
3
