D0Z18G20 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Circuit protection> Circuit protection> D0Z18G20

Preview

D0Z18G20: DescriptionFAST BLOW ELECTRIC FUSE, 20A, 380VAC, 250VDC, 50000A (IR), INLINE/HOLDER; CategoryCircuit protection Circuit protection; File Size153KB，2 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com

Download Datasheet Parametric View All

D0Z18G20 Overview

FAST BLOW ELECTRIC FUSE, 20A, 380VAC, 250VDC, 50000A (IR), INLINE/HOLDER

D0Z18G20 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
Other features	RATED BREAKING CAPACITY AT 250 VDC: 50000 A
Fusing characteristics	FAST
body height	36 mm
Body length or diameter	15 mm
Built-in features	INDICATOR
Circuit protection type	ELECTRIC FUSE
Manufacturer's serial number	D0Z1
Installation features	INLINE/HOLDER
physical size	15mm x 36mm
Rated breaking capacity	50000 A
Rated current	20 A
Rated voltage (AC)	380 V
Rated voltage (DC)	250 V
Guideline	DIN; IEC; VDE
surface mount	NO
Terminal shape	END CAP
Base Number Matches	1

Preview

Download Datasheet

View All

International Products

Diazed/Neozed Fuses

380-500 Volts AC • 2 – 63 Amperes

Littelfuse fast acting (gL-gG) fuses are used for the protection of cables

against short-circuits. Time-lag (aM) fuses are used for protection of

motors. Ratings are available in standard Diazed and compact Neozed

styles.

Specifications

Standards:

DIN 49.522-DIN 49.525, IEC 269-3

Approvals:

VDE

Example part number: DZ27F4

Base Size

14

18

16

27

33

Type

D01

D02

DI

DII

DIII

Current Range Voltage AC/DC

2-16A

20-63A

2-25A

35-63A

380V/250V

500V

Interrupting

Rating

50kA

80kA

All Diazed and Neozed fuses incorporate a blown fuse indicator.

Neozed Fuses

11

15

13.2

Diazed Fuses

21.5

27

36

50

A

D01

All dimensions are in “mm”

International Products

D02

DI

DII

DIII

Diazed Fuses

Amperage

Color

2

Pink

4

Brown

6

Green

10

Red

16

Grey

20

Blue

25

Yellow

35

Black

50

White

63

Copper

Base Size

(mm)

DI

DZ16F2

DZ16F4

DZ16F6

DZ16F10

DZ16F16

DZ16F20

DZ16F25

—

16

gL-gG

DII

DZ27F2

DZ27F4

DZ27F6

DZ27F10

DZ27F16

DZ27F20

DZ27F25

—

27

DIII

—

DZ33F35

DZ33F50

DZ33F63

33

DI

DZ16T2

DZ16T4

DZ16T6

DZ16T10

DZ16T16

DZ16T20

DZ16T25

—

16

aM

DII

DZ27T2

DZ27T4

DZ27T6

DZ27T10

DZ27T16

DZ27T20

DZ27T25

—

27

DIII

—

DZ33T35

DZ33T50

DZ33T63

33

DIM.

A (mm)

6

8

10

12

14

16

18

20

—

Neozed Fuses

gL-gG

D01

D0Z14G2

D0Z14G4

D0Z14G6

D0Z14G10

D0Z14G16

—

14

D02

—

D0Z18G20

D0Z18G25

D0Z18G35

D0Z18G50

D0Z18G63

18

DIM.

A (mm)

7.3

8.5

9.7

10.9

12.1

13.3

14.5

15.9

—

166

www.littelfuse.com

•

POWR-GARD

™

Products Catalog
