F-218
ZSTMM–112–75–L–D–285
STMM–110–02–F–D–RA
STMM–113–02–T–D
(2.00 mm) .0787"
STMM, ZSTMM SERIES
SHROUDED IDC HEADER & STACKER
Mates with:
TCSD (except –SR)
STMM
1
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?STMM
or www.samtec.com?ZSTMM
Insulator Material:
High Temperature Nylon
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
NO. PINS
PER ROW
02
PLATING
OPTION
D
TAIL
OPTION
OTHER
OPTION
04, 05, 06, 07,
08, 10, 12, 13, 14,
15, 17, 20, 22, 25
(Standard sizes)
(0.51)
.020
(2.00) .0787 x
No. of positions + (6.17) .243
02 04
= Gold flash on post,
Matte Tin on tail
–F
Leave blank for
Through-hole
= Polarized
Position
–“XX”
–LC
= 10 µ" (0.25 µm) Gold on post,
Matte Tin on tail
–L
–T
= Right-angle
–RA
= Surface Mount
–SM
= Matte Tin
(6.00)
.237
= Locking
Clip
(-SM only)
(Manual
placement
required)
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
(2.00)
.0787
(2.97)
.117
01 03
(3.55)
.140
(2.00) .0787
(4.80)
.190
(0.38)
.015
(0.89)
.035
(0.38)
.015
(1.27)
.050
(7.79)
.307
(2.00)
.0787
(2.29)
.090
(1.52)
.060
= (7.50 mm)
.295" DIA
Film Pick &
Place Pad
(-SM only)
–K
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
(0.51) .020 SQ
T/H
–SM
–RA
–SM
–RA
= Tape & Reel
(–SM only)
–TR
ALSO AVAILABLE
(MOQ Required)
• Other sizes
• Other platings
Contact Samtec.
ZSTMM
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart.
PLATING
OPTION
D
BODY
HEIGHT
OTHER
OPTION
OTHER
SOLUTIONS
• Shrouded board-to-board
headers and stackers
to mate with SQT,
SQW, ESQ and SMM Series.
See LTMM and
ZLTMM Series.
04, 05, 06, 07,
08, 10, 12, 13, 14,
15, 17, 20, 22, 25
(Standard sizes)
(0.51)
.020
(2.00) .0787 x
No. of positions + (6.17) .243
02 04
= Gold flash on post,
Matte Tin on tail
–F
–“XXX”
= Body
Height
= Polarized
Position
–“XX”
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
–L
–T
(6.00)
.237
(2.00)
.0787
01 03
= Matte Tin
(3.55)
.140
(2.00)
.0787
(4.80)
.190
(3.18)
.125
(3.05)
.120
BODY
HEIGHT
(6.35)
B
.250
(OAL) MIN
Note:
For added mechanical
stability, Samtec recommends
mechanical board spacers be
used in applications with gold or
selective gold plated connectors.
Contact ipg@samtec.com for
more information.
Note:
This Series is
non-standard, non-returnable.
(0.38)
.015
(0.51)
.020
SQ
(2.29)
.090
MIN
LEAD
STYLE
–75
–62
–65
–73
–63
–66
–69
–74
–70
–71
–72
B
(OAL)
(9.58) 0.377
MAX BODY
HEIGHT
(7.42) 0.292
(10.08) 0.397 (7.92) 0.312
(10.49) 0.413 (8.33) 0.328
(12.09) 0.476 (9.93) 0.391
(14.10) 0.555 (11.94) 0.470
(15.09) 0.594 (12.93) 0.509
(15.60) 0.614 (13.44) 0.529
(17.09) 0.673 (14.94) 0.588
(17.60) 0.693 (15.44) 0.608
(21.08) 0.830 (18.92) 0.745
(21.62) 0.851 (19.46) 0.766
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
