Ordering number:EN2820A
DCG015
Silicon Epitaxial Planar Type (Cathode Common)
High-Speed Switching Diode
Features
· Very small-sized package permitting DCG015-
applied sets to be made small and slim.
· Fast swicthing speed.
· Twin type, anode common.
Package Dimensions
unit:mm
1198
[DCG015]
A:Anode
C:Cathode
Specifications
Absolute Maximum Ratings
at Ta = 25˚C
Parameter
Peak Reverse Voltage
Reverse Voltage
Surge Current
Average Rectified Current
Peak Forward Current
Junction Temperature
Storage Temperature
Symbol
VRM
VR
IFSM
IO
IFM
Tj
Tstg
1µs
Unit rating
Total rating
Unit rating
Total rating
Conditions
SANYO:MCP
Ratings
75
50
4
100
150
300
450
150
–55 to +150
Unit
V
V
A
mA
mA
mA
mA
˚C
˚C
Electrical Characteristics
at Ta = 25˚C
Parameter
Forward Voltage
Symbol
VF
IF=10mA
IF=50mA
IF=100mA
Reverse Current
Interterminal Capacitance
Reverse Recovery Time
IR
C
trr
VR=50V
VR=0V, f=1MHz
IF=10mA, VR=6V, RL=50
Ω
, Irr=0.1Irp
4.0
Conditions
Ratings
min
typ
0.72
0.85
0.92
max
1.0
1.0
1.2
100
7.0
5
Unit
V
V
V
nA
pF
ns
Marking:A6
Reverse Recovery Time Test Circuit
Electrical Connection
(Top view)
Unit (resistance:Ω, capacitance:F)
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE, Tokyo Bldg., 1-10 , Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
52098HA (KT)/4059MO (KOTO) No.2820-1/2
DCG015
No products described or contained herein are intended for use in surgical implants, life-support systems,
aerospace equipment, nuclear power control systems, vehicles, disaster/crime-prevention equipment and
the like, the failure of which may directly or indirectly cause injury, death or property loss.
Anyone purchasing any products described or contained herein for an above-mentioned use shall:
Accept full responsibility and indemnify and defend SANYO ELECTRIC CO., LTD., its affiliates,
subsidiaries and distributors and all their officers and employees, jointly and severally, against any
and all claims and litigation and all damages, cost and expenses associated with such use:
Not impose any responsibilty for any fault or negligence which may be cited in any such claim or
litigation on SANYO ELECTRIC CO., LTD., its affiliates, subsidiaries and distributors or any of
their officers and employees jointly or severally.
Information (including circuit diagrams and circuit parameters) herein is for example only; it is not guarant-
eed for volume production. SANYO believes information herein is accurate and reliable, but no guarantees
are made or implied regarding its use or any infringements of intellectual property rights or other rights of
third parties.
This catalog provides information as of May, 1998. Specifications and information herein are subject to
change without notice.
PS No.2820-2/2
