MLC
▪
CHIP
▪
CAPACITOR
Pan Overseas
Y5V DIELECTRIC
–
GENERAL SPECIFICATION
INTRODUCTION：
The Y5V has high K value. Its electrical properties vary considerably under changing voltage, temperature, and
time. It’s suitable for general purposes applications where high capacitance values are required, and are ideal for
room temperature applications with low DC bias.
FEATURES：
■
Small size with high capacitance values
■
Consistent dimensions and finish surface
■
Engineered for automatic handling and insertion
GENERAL SPECIFICATIONS：
Capacitance Range
Capacitance Tolerance
Operating Temperature Range
Temperature Coefficient (△C Max.)
Voltage Rating
Dissipation Factor (tan
δ)
Insulation Resistance (IR) @25℃
Aging Rate
Dielectric Strength
Testing Parameters
1000pF to 10µF
±20%,
+80 - 20%
-30℃~ 85℃
+22% ~ - 82%
6.3, 10,16, 25, 50 VDC
7% Max. (12.5% max for 10V)
Lesser of 10GΩ or 1000MΩµF
-7% per Decade hour
2.5 times the rated WVDC
1KHz
±
50Hz, 1.0Vrms
±
0.2Vrms
@ 25℃, 0 Volts Bias
6
MLC
▪
CHIP
▪
CAPACITOR
Pan Overseas
Y5V DIELECTRIC
Typical Characteristic Curves and Capacitance Chart
Typical Characteristic Curves：
Capacitance Chart(Y5V)：
Case
Size
0402
Rated
Voltage
B=16V
T=25V
U=50V
N=10V
B=16V
T=25V
U=50V
N=10V
B=16V
T=25V
U=50V
N=10V
B=16V
T=25V
U=50V
Temp.
Chart.
Capacitance
Range (pF)
Tolerance
33000 ~ 100000
22000
1000 ~ 15000
47000 ~ 1000000
47000 ~ 330000
33000 ~ 100000
1000 ~ 100000
M, Z
220000 ~ 2200000
220000 ~ 100000
1000 ~ 330000
1000 ~ 220000
220000 ~ 10000000
220000 ~ 4700000
68000 ~ 1000000
1000 ~ 470000
L
1.0±0.05
Dimension (mm)
W
T (max)
0.5±0.05
0.5±0.05
MB (min)
0.10
G (min)
0.30
0603
1.6±0.10
0.8±0.10
0.8±0.10
0.20
0.40
+22%
-82%
0805
2.0±0.20
1.25±0.1
1.40
0.25
0.70
1206
3.2±0.20
1.6±0.20
1.52
0.25
1.40
●
When Ordering, please use the Pan Overseas
Part number as indicated on page no. 1.
7
