AU02YA181JAG9A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> AU02YA181JAG9A

AU02YA181JAG9A: DescriptionCeramic Capacitor, Multilayer, Ceramic, 16V, 5% +Tol, 5% -Tol, C0G, -/+30ppm/Cel TC, 0.00018uF, 0402,; CategoryPassive components capacitor; File Size220KB，7 Pages; ManufacturerAVX; Environmental Compliance

Download Datasheet Parametric View All

AU02YA181JAG9A Overview

Ceramic Capacitor, Multilayer, Ceramic, 16V, 5% +Tol, 5% -Tol, C0G, -/+30ppm/Cel TC, 0.00018uF, 0402,

AU02YA181JAG9A Parametric

Parameter Name	Attribute value
dielectric materials	CERAMIC
multi-layer	Yes
negative tolerance	5%
Temperature characteristic code	C0G
capacitance	0.00018 µF
Capacitor type	CERAMIC CAPACITOR
Installation features	SURFACE MOUNT
positive tolerance	5%
Rated (DC) voltage (URdc)	16 V
size code	0402
width	0.5 mm
high	0.56 mm
length	1 mm
JESD-609 code	e4
Package form	SMT
method of packing	Bulk
surface mount	YES
Terminal surface	Gold (Au)
Terminal shape	WRAPAROUND
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Temperature Coefficient	30ppm/Cel ppm/°C
Is it Rohs certified?	Yes
Objectid	717622639
package instruction	, 0402
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
YTEOL	0

Preview

Download Datasheet

View All

MLCC Gold Termination – AU Series

General Specifications

AVX Corporation will support those customers for

commercial and military Multilayer Ceramic Capacitors with

a termination consisting of Gold. This termination is

indicated by the use of a “7” or “G” in the 12th position of

the AVX Catalog Part Number. This fulfills AVX’s

commitment to providing a full range of products to our

customers. Please contact the factory if you require

additional information on our MLCC Gold Termination.

PART NUMBER

AU03

Size

AU01 - 0201

AU02 - 0402

AU03 - 0603

AU05 - 0805

AU06 - 1206

AU10 - 1210

AU12 - 1812

AU13 - 1825

AU14 - 2225

AU16 - 0306

AU17 - 0508

AU18 - 0612

104

Capacitance

Code (In pF)

2 Sig. Digits +

Number of

Zeros

Capacitance

Tolerance

±.10 pF (<10pF)

±.25 pF (<10pF)

±.50 pF (<10pF)

±1% (≥ 10 pF)

±2% (≥ 10 pF)

±5%

±10%

±20%

Failure

Rate

A = Not

Applicable

Terminations

G* = 1.9 μ" to

7.87 μ"

7 = 100 μ"

minimum

Packaging

2 = 7" Reel

4 = 13" Reel

9 = Bulk

Special

Code

A = Std.

Product

Dielectric

Voltage

C0G (NP0) = A

6.3V = 6

X7R = C

10V = Z

X5R = D

16V = Y

25V = 3

35V = D

50V = 5

100V = 1

200V = 2

500V = 7

Contact

Factory

For

Multiples

* Contact factory for availability.
