Non-Ventilated Automation Transformers
Automation Transformers - Non-Ventilated 50 VA to 45 kVA
SolaHD encapsulated transformers are rated for Hazardous
Locations as well as harsh industrial environments. Encap-
sulation and rugged UL Listed/NEMA Type 3R enclosures
protect the transformer from dust, moisture, and provide
extra shock and vibration resistance. SolaHD transformers
fully comply with the latest addition of the National Electrical
Code for Class I, Division 2, Group A, B, C and D locations
when installed in compliance with NEC 501.100 (B).
Features
Single Phase: .05 - .250 kVA
• UL Listed/NEMA Type 3R non encapsulated enclosure
for indoor and outdoor service
• Low temperature rise, UL Class 130
o
C insulation
system, 80
o
C temperature rise under full load
• Conduit knockouts for side entry into wiring
compartment
• Copper lead wire terminations
Single Phase: 0.500 - 25 kVA
Three Phase: 3 - 45 kVA
E25872
E77014
Accessories and Optional Design Styles
• Stainless Steel Enclosures
• Copper Wound designs
•
UL Listed/NEMA
Type 4, 4X or 12 Encapsulated
Enclosures
• Low temperature designs available
• UL Listed/NEMA Type 3R encapsulated enclosure for
indoor and outdoor service
• Electrostatically shielded for quality power on sizes
1 kVA and larger
• UL Class 200
o
C insulation system, 115°C
temperature rise under full load
• Conduit knockouts for side entry into wiring
compartment
• Copper lead wire terminations
• .500 - 45 kVA units are encapsulated with electrical
grade silica and epoxy for industrial applications
Related Products
• Some SolaHD DC power supplies are available with
Class I, Division 2 ratings or encapsulation.
• Surge Protective Devices
Certifications and Compliances
•
Listed: E25872, E77014
- UL 1561 or UL 506
-
CSA C22.2 No. 47 or No. 66
Note: Weights and dimensions may change and should not be used for construction purposes.
224
Contact
Technical Services
at
(800) 377-4384
with any questions.
Visit our website at www.solahd.com.
Non-Ventilated Automation Transformers
Selection Table: Single Phase
Group 1: 240 x 480 Primary, 120/240 Secondary, 60 Hz
kVA
Catalog Number Catalog Number
Group I
Group II
Rolled Steel
Stainless Steel
HS1B50
HS1B75
HS1B100
HS1B150
HS1B250
HS1F500B
HS1F750B
HS1F1BS
HS1F1.5AS
HS1F2AS
HS5F3AS
HS5F5AS
HS5F7.5AS
HS5F10AS
HS5F15AS
HS5F25AS
HSS1F500B
HSS1F750B
HSS1F1BS
HSS1F1.5AS
HSS1F2AS
HSS5F3AS
HSS5F5AS
HSS5F7.5AS
HSS5F10AS
HSS5F15AS
HSS5F25AS
N/A
Height
in (mm)
Width
in (mm)
Depth
in (mm)
Non-Encapsulated
.050
.075
.100
.150
.250
0.5
0.75
1
1.5
2
3
5
7.5
10
15
25
6.00 (152.4)
6.00 (152.4)
6.00 (152.4)
8.00 (203.2)
8.00 (203.2)
10.00 (254.0)
10.00 (254.0)
10.00 (254.0)
12.00 (304.8)
12.00 (304.8)
12.00 (304.8)
17.00 (431.8)
17.00 (431.8)
17.00 (431.8)
30.00 (762.0)
30.00 (762.0)
4.00 (101.6)
4.00 (101.6)
4.00 (101.6)
4.00 (101.6)
4.00 (101.6)
6.00 (152.4)
6.00 (152.4)
6.00 (152.4)
10.00 (254.0)
10.00 (254.0)
10.00 (254.0)
14.00 (355.6)
14.00 (355.6)
14.00 (355.6)
3.00 (76.2)
3.00 (76.2)
3.00 (76.2)
4.00 (101.6)
4.00 (101.6)
Encapsulated
5.00 (127.0)
5.00 (127.0)
5.00 (127.0)
7.00 (177.8)
7.00 (177.8)
7.00 (177.8)
9.00 (228.6)
9.00 (228.6)
9.00 (228.6)
22.0 (9.98)
27.0 (12.25)
28.0 (12.70)
38.0 (17.24)
45.0 (20.42)
55.0 (24.95)
131.0 (59.42)
156.0 (70.76)
156.0 (70.76)
3
3
3
4
4
4
4
4
4
4
4
15
15
16
16
16
17
17
18
18
18
18
2.08/1.04
3.13/1.56
4.17/2.08
6.25/3.13
8.33/4.17
12.5/6.25
20.8/10.4
31.3/15.6
41.7/20.8
62.5/31.2
104.0/52.0
3.00 (1.36)
3.00 (1.36)
4.00 (1.81)
5.00 (2.27)
8.00 (3.63)
2
2
2
2
2
15
15
15
15
15
.208/.104
.312/.156
.417/.208
.625/.313
1.04/.512
Approx. Ship
Weight lbs (kg)
Design
Style *
Elec
Conn *
Primary
Amps
5
Secondary
Amps
0.416/0.208
0.625/0.312
0.833/0.417
1.25/.625
2.08/1.04
4.16/2.08
6.25/3.13
8.33/4.17
12.5/6.25
16.7/8.33
25.0/12.5
41.6/20.8
62.5/31.3
83.3./41.7
125.0/62.5
208.0/104.0
29.00 (736.6)
12.00 (304.8) 549.0 (249.02)
29.00 (736.6)
12.00 (304.8) 637.0 (288.94)
Group 2: 600 Volt Primary, 120/240 Secondary, 60 Hz
kVA
Catalog Number
Group 1
Rolled Steel
Catalog Number
Group 2
Stainless Steel
Height
in (mm)
Width
in (mm)
Depth
in (mm)
Approx. Ship
Weight lbs (kg)
Design
Style *
Elec
Conn *
Primary
Amps
Secondary
Amps
Non-Encapsulated
.100
.150
.250
.500
.750
1
1.5
2
3
5
7.5
10
HS10B100
HS10B150
HS10B250
HS10F500B
HS10F750B
HS10F1BS
HS10F1.5AS
HS10F2AS
HS10F3AS
HS10F5AS
HS10F7.5AS
HS10F10AS
HSS10F500B
HSS10F750B
HSS10F1BS
HSS10F1.5AS
HSS10F2AS
HSS10F3AS
HSS10F5AS
HSS10F7.5AS
HSS10F10AS
N/A
6.00 (152.4)
8.00 (203.2)
8.00 (203.2)
10.00 (254.0)
10.00 (254.0)
10.00 (254.0)
4.00 (101.6)
3.00 (76.2)
4.00 (1.81)
5.00 (2.27)
8.00 (3.63)
22.0 (9.98)
23.0 (10.43)
28.0 (12.70)
38.0 (17.24)
60.0 (27.22)
66.0 (29.94)
2
2
2
3
3
3
4
4
4
4
4
4
21
21
21
21
21
21
21
21
22
22
22
22
0.167
0.25
0.417
0.833
1.25
1.67
2.5
3.33
5.0
8.3
12.5
16.7
.833/.417
1.25/.625
2.08/1.04
4.16/2.08
6.25/3.13
8.33/4.17
12.5/6.25
16.7/8.33
25.0/12.5
41.6/20.8
62.5/31.3
83.3/41.7
4.00 (101.6) 4.00 (101.6)
4.00 (101.6) 4.00 (101.6)
Encapsulated
6.00 (152.4)
5.00 (127.0)
6.00 (152.4)
5.00 (127.0)
6.00 (152.4)
5.00 (127.0)
12.00 (304.8) 10.00 (254.0)
7.00 (177.8)
12.00 (304.8) 10.00 (254.0)
7.00 (177.8)
12.00 (304.8) 10.00 (254.0)
7.00 (177.8)
17.00 (431.8) 14.00 (355.6)
9.00 (228.6)
100.0 (45.36)
17.00 (431.8) 14.00 (355.6)
9.00 (228.6) 135.0 (61.23)
17.00 (431.8) 14.00 (355.6)
9.00 (228.6)
150.0 (68.04)
* Note: Design Styles and Electrical Connections can be found
at the end of the Non-Ventilated Distribution Transformers section.
Contact
Technical Services
at
(800) 377-4384
with any questions.
Visit our website at www.solahd.com.
