DRC3114W0L

Description
transistors switching - resistor biased trans W/ blt-IN res flt LD 1.2x1.2mm
CategoryDiscrete semiconductor    The transistor
File Size236KB,4 Pages
ManufacturerPanasonic
Websitehttp://www.panasonic.co.jp/semicon/e-index.html
Environmental Compliance
Download Datasheet Parametric View All

DRC3114W0L Online Shopping

Suppliers Part Number Price MOQ In stock
DRC3114W0L - - View Buy Now

DRC3114W0L Overview

transistors switching - resistor biased trans W/ blt-IN res flt LD 1.2x1.2mm

DRC3114W0L Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerPanasonic
package instructionHALOGEN FREE AND ROHS COMPLIANT, SSSMINI3-F2-B, SC-105AA, 3 PIN
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresBUILT IN BIAS RESISTOR RATIO IS 0.47
Maximum collector current (IC)0.1 A
Collector-emitter maximum voltage50 V
ConfigurationSINGLE WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)20
JESD-30 codeR-PDSO-F3
Number of components1
Number of terminals3
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeNPN
surface mountYES
Terminal formFLAT
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Doc No.
TT4-EA-11689
Revision.
2
Product Standards
Transistors with Built-in Resistor
DRC3114W0L
DRC3114W0L
Silicon NPN epitaxial planar type
For digital circuits
DRC9114W in SSSMini3 type package
Features
Low collector-emitter saturation voltage Vce(sat)
Halogen-free / RoHS compliant
(EU RoHS / UL-94 V-0 / MSL:Level 1 compliant)
1
2
Unit: mm
1.2
0.3
3
0.13
Marking Symbol: N9
Packaging
Embossed type (Thermo-compression sealing) : 10 000 pcs / reel (standard)
0.2
(0.4) (0.4)
0.8
0.8
1.2
0.52
1. Base
2. Emitter
3. Collector
Panasonic
JEITA
Code
SSSMini3-F2-B
SC-105AA
SOT-723
Absolute Maximum Ratings Ta = 25
C
Parameter
Symbol
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Collector current
Total power dissipation
Junction temperature
Operating ambient temperature
Storage temperature
VCBO
VCEO
IC
PT
Tj
Topr
Tstg
Rating
50
50
100
100
150
-40 to +85
-55 to +150
Unit
V
V
mA
mW
°C
°C
°C
Internal Connection
B
R
1
R
2
C
E
Resistance
value
Electrical Characteristics Ta = 25
C 
3
C
Parameter
Symbol
Collector-base voltage (Emitter open)
VCBO
Collector-emitter voltage (Base open)
VCEO
Collector-base cutoff current (Emitter open)
ICBO
Collector-emitter cutoff current (Base open)
ICEO
Emitter-base cutoff current (Collector open)
IEBO
Forward current transfer ratio
hFE
Collector-emitter saturation voltage
VCE(sat)
Vi(on)
Input voltage
Vi(off)
Input resistance
R1
Resistance ratio
R1/R2
R1
R2
Typ
10
4.7
k
k
Conditions
IC = 10
μA,
IE = 0
IC = 2 mA, IB = 0
VCB = 50 V, IE = 0
VCE = 50 V, IB = 0
VEB = 6 V, IC = 0
VCE = 10 V, IC = 5 mA
IC = 10 mA, IB = 0.5 mA
VCE = 0.2 V, IC = 5 mA
VCE = 5 V, IC = 100
μA
Min
50
50
Max
0.1
0.5
1
Unit
V
V
μA
μA
mA
-
V
V
V
k
-
20
0.25
3.0
1.3
-30% 10 +30%
1.70 2.13 2.60
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 Measuring methods for transistors.
Page 1 of 3
Established : 2009-10-27
Revised
: 2014-03-20
