PE5545KEW-156.25M

Description
PECL Output Clock Oscillator,
CategoryPassive components    oscillator
File Size963KB,8 Pages
ManufacturerPletronics
Environmental Compliance
Download Datasheet Parametric View All

PE5545KEW-156.25M Overview

PECL Output Clock Oscillator,

PE5545KEW-156.25M Parametric

Parameter NameAttribute value
Minimum supply voltage2.25 V
maximum symmetry55/45 %
Other featuresENABLE/DISABLE FUNCTION
maximum descent time1.1 ns
Frequency Adjustment - MechanicalNO
longest rise time1.1 ns
Maximum supply voltage2.75 V
frequency stability50%
Nominal operating frequency156.25 MHz
Oscillator typePECL
Output load50 OHM
Nominal supply voltage2.5 V
Package body materialCERAMIC
surface mountYES
Installation featuresSURFACE MOUNT
Number of terminals6
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
physical size5.0mm x 3.2mm x 1.35mm
Is it Rohs certified?Yes
Is SamacsysN
YTEOL6.25
Objectid7107080625
Reach Compliance Codecompliant
PE55K Series 2.5 V
PECL Clock Oscillators
November 2018
• Pletronics’ PE55K Series is a quartz crystal
controlled precision square wave generator with a
PECL output.
• Im proved phase noise perform ance.
• Low cost m ass produced oscillator.
• Tape and Reel or cut tape packaging is available.
• 3.2 x 5 m m LCC Ceram ic Package
• Enable/Disable Function on pad 1
• Disable function includes low standby power
m ode
• 3
rd
Overtone Crystals used
• Im proved circuit to m inim ize oscillator issues
such as m ulti-m ode output signal.
• Lowest Jitter Product
* BEST OPTION FOR LOW JITTER REQUIREMENTS
50 fS Jitter 12.0 KHz to 20.0 MHz @ 156.25 MHz
Pletronics Inc. certifies this device is in accordance with the
RoHS 6/6 (2011/65/EC) and WEEE (2002/96/EC) directives.
Pletronics Inc. guarantees the device does not contain the following:
Cadm ium , Hexavalent Chrom ium , Lead, Mercury, PBB’s, PBDE’s
W eight of the Device: 0.09 gram s
Moisture Sensitivity Level: 1 As defined in J-STD-020D.1
Second Level Interconnect code: e4
Absolute Maximum Ratings:
Parameter
V
CC
Supply Voltage
Vi
Vo
Input Voltage
Output Voltage
Unit
-0.5V to +4.6V
-0.5V to V
CC
+ 0.5V
-0.5V to V
CC
+ 0.5V
Thermal Characteristics
The m axim um die or junction tem perature is 125
o
C
The therm al resistance junction to board is 30 to 50
o
C/W att depending on the solder pads, ground plane
and construction of the PCB.
P roduct inform ation is current as of publication date. T he product conform s
to specifications per the term s of the P letronics standard warranty. Production
processsing does not necessarily include testing of all param eters.
Copyright © 2018, Pletronics Inc.
