Si106x/Si108x
U
LTRA
-L
OW
P
OWER
MCU
WITH
I
NTEGRATED
H
IGH
-P
ERFORMANCE SUB
-1 GH
Z
T
RANSCEIVER
Description
Silicon Laboratories’ Si106x and Si108x Wireless
MCUs
combine
high-performance
wireless
connectivity and ultra-low power microcontroller
processing into a small 5x6 mm form factor. Support
for all major frequency bands in the 142 to 1050 MHz
range is provided including an integrated advanced
packet handling engine and the ability to realize a
link budget of up to 146 dB. The devices have been
optimized to minimize energy consumption for
battery-backed applications by minimizing TX, RX,
active, and sleep mode current as well as supporting
fast wake-up times. The Si106x and Si108x Wireless
MCUs are available in a pin-compatible family of
devices that scales from 8 to 64 kB of flash and
provides a robust set of analog and digital
peripherals including an ADC, dual comparators,
timers, and GPIO. These Wireless MCUs are
compliant with IEEE 802.15.4g and support
worldwide regulatory standards including FCC, ETSI,
and ARIB.
Features
Ultra-low power 8051 µC Core
-
25 MHz, single-cycle 8051 compatible CPU
-
25 MIPS peak throughput with 25 MHz clock
-
Industry's lowest active and sleep currents
-
160 µA/MHz: active mode
-
50 nA sleep with brownout detectors enabled
-
600 nA sleep w/internal RTC
-
2 µs wake-up time
-
On-chip debug
Memory
-
Up to 64 kB of flash and 4 kB of RAM
Peripherals
-
10-bit analog-to-digital converter
-
Temperature sensor
-
Dual comparators
-
11 general purpose I/O
-
UART, SPI, I
2
C
-
Four general purpose 16-bit counter/timers
-
Precision internal oscillators
-
24.5 MHz with ±2% accuracy
-
Low power 20 MHz internal oscillator
-
External oscillator: crystal, RC, C, CMOS clock
-
RTC: 32.768 kHz crystal or self-oscillate
Transceiver Features
-
Data rate up to 1 Mbps
-
142–1050 MHz frequency range
-
On-chip crystal tuning
-
–126 dBm receive sensitivity @ 500 bps, GFSK
-
Modulation: OOK, (G)FSK, and 4(G)FSK
-
Up to +20 dBm output power
-
Low power consumption
-
10.7 mA RX
-
18 mA TX at +10 dBm
-
30 nA shutdown, 50 nA standby
-
Fast wake and hop times
-
Excellent selectivity performance
-
60 dB adjacent channel
-
73 dB blocking at 1 MHz
-
Antenna diversity and T/R switch control
-
Highly configurable packet handler
-
TX and RX 64 byte FIFOs
-
Auto frequency control (AFC)
-
Automatic gain control (AGC)
-
IEEE 802.15.4g compliant
System
-
Supply voltage: 1.8 to 3.6 V
-
0.9–3.6V operation with built-in dc–dc con-
verter
-
Brownout detectors cover sleep and active
modes
-
Low battery detector
-
Low BOM count
-
5x6 36-pin QFN package
Applications
-
-
-
-
-
-
-
-
-
-
-
-
Home automation
Home security
Remote control
Garage door openers
Remote keyless Entry
Home health care
Smart metering
Building Lighting control
Building HVAC control
Fire and Security monitoring
Security and Access control
Telemetry
EZRadio/EZRadioPRO
Copyright © 2013 by Silicon Laboratories
12.10.13
Si106x/Si108x
U
LTRA
-L
OW
P
OWER
MCU
WITH
I
NTEGRATED
H
IGH
-P
ERFORMANCE SUB
-1 GH
Z
T
RANSCEIVER
Power On
Reset/PMU
Wake
Reset
CIP-51 8051
Controller Core
Flash Program
Memory
Analog Peripherals
6-bit
IREF
Internal
VREF
External
VREF
A
M
U
X
VDD
VREF
Temp
Sensor
GND
CP0, CP0A
CP1, CP1A
+
-
+
-
RF
XCVR
IREF0
C2CK/RST
Debug /
Programming
Hardware
C2D
PA
SRAM
10-bit
300ksps
ADC
TX
AGC
CRC
Engine
VREG
SYSCLK
LNA
Mixer
PGA
ADC
RXp
RXn
VDD
GND
Precision
24.5 MHz
Oscillator
Low Power
20 MHz
Oscillator
P0.2/XTAL1
P0.3/XTAL2
External
Oscillator
Circuit
SmaRTClock
Oscillator
SFR
Bus
Comparators
Digital Peripherals
Transceiver Control Interface
Digital
Logic
UART
Timers 0,
1, 2, 3
PCA/
WDT
SMBus
SPI 0
Priority
Crossbar
Decoder
TX
Modulator
OSC
XIN
XOUT
XTAL3
XTAL4
System Clock
Configuration
Port I/O
Config
ANALOG &
DIGITAL I/O
Si106x/Si108x Family Selector Guide
Frequency
960–1050 MHz
142–175 MHz
283–350 MHz
425–525 MHz
850–960 MHz
Orderable
Part
Number
Sensitivity
Max
Max Data
Output
Rate
Power
Advanced
Features*
Radio
Flash
RAM
Max
40 kbps,
GFSK
Si1060
Si1061
Si1062
Si1063
Si1064
Si1065
Si1080
Si1081
Si1082
Si1083
Si1084
Si1085
EZRadioPRO
EZRadioPRO
EZRadioPRO
EZRadioPRO
EZRadio
EZRadio
64 kB
32 kB
64 kB
32 kB
64 kB
32 kB
4 kB
4 kB
4 kB
4 kB
4 kB
4 kB
768 bytes
768 bytes
768 bytes
768 bytes
768 bytes
EZRadioPRO 16 kB
EZRadioPRO 8 kB
EZRadioPRO 16 kB
EZRadioPRO 8 kB
EZRadio
EZRadio
8 kB
16 kB 768 bytes
+20 dBm
+20 dBm
+13 dBm
+13 dBm
1 Mbps
1 Mbps
1 Mbps
1 Mbps
–126 dBm
–126 dBm
–126 dBm
–126 dBm
–110 dBm
–110 dBm
–110 dBm
–110 dBm
Yes
Yes
Yes
Yes
No
No
Yes
Yes
Yes
Yes
No
No
+13 dBm 500 kBps –116 dBm –108 dBm
+13 dBm 500 kBps –116 dBm –108 dBm
+20 dBm
+20 dBm
+13 dBm
+13 dBm
1 Mbps
1 Mbps
1 Mbps
1 Mbps
–126 dBm
–126 dBm
–126 dBm
–126 dBm
–110 dBm
–110 dBm
–110 dBm
–110 dBm
+13 dBm 500 kBps –116 dBm –108 dBm
+13 dBm 500 kBps –116 dBm –108 dBm
*Note:
Advanced features include antenna diversity, narrowband support and autonomous low-duty cycle support. For a
complete list, refer to the data sheet.
Development Kits
Orderable Part Number
1060-490-DK
1062-868-DK
1060-915-DK
1064-434-DK
1064-868-DK
1064-915-DK
Flash/RAM
64 kB/4 kB
64 kB/4 kB
64 kB/4 kB
64 kB/4 kB
64 kB/4 kB
64 kB/4 kB
Frequency
490 MHz
868 MHz
915 MHz
434 MHz
868 MHz
915 MHz
Output Power
+20 dBm
+13 dBm
+20 dBm
+13 dBm
+13 dBm
+13 dBm
EZRadio/EZRadioPRO
