MAX1470EUI+T Overview

RF receiver 315mhz low-power 3V superheterodyne rcvr

MAX1470EUI+T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Maxim
Parts packaging code	SSOP
package instruction	TSSOP,
Contacts	28
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	9 weeks
JESD-30 code	R-PDSO-G28
JESD-609 code	e3
length	9.7 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	28
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.1 mm
Nominal supply voltage	3.3 V
surface mount	YES
technology	CMOS
Telecom integrated circuit types	TELECOM CIRCUIT
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	4.4 mm

Preview

Download Datasheet

View All

MAX1470

315MHz Low-Power, +3V Superheterodyne

Receiver

General Description

The MAX1470 is a fully integrated low-power CMOS

superheterodyne receiver for use with amplitude-shift-

keyed (ASK) data in the 315MHz band. With few required

external components, and a low-current power-down

mode, it is ideal for cost- and power-sensitive applica-

tions in the consumer markets. The chip consists of a

315MHz low-noise amplifier (LNA), an image rejection

mixer, a fully integrated 315MHz phase-lock-loop (PLL), a

10.7MHz IF limiting amplifier stage with received-signal-

strength indicator (RSSI) and an ASK demodulator, and

analog baseband data-recovery circuitry.

The MAX1470 is available in a 28-pin TSSOP package.

Features

●

Applications

●

Remote Keyless Entry

Garage Door Openers

Remote Controls

Wireless Sensors

Wireless Computer Peripherals

Security Systems

Toys

Video Game Controllers

Medical Systems

Operates from a Single +3.0V to +3.6V Supply

Built-In 53dB RF Image Rejection

-115dBm Receive Sensitivity*

250μs Startup Time

Low 5.5mA Operating Supply Current

1.25μA Low-Current Power-Down Mode for Efficient

Power Cycling

250MHz to 500MHz Operating Band

(Image Rejection Optimized at 315MHz)

Integrated PLL with On-Board Voltage-Controlled

Oscillator (VCO) and Loop Filter

Selectable IF Bandwidth Through External Filter

Complete Receive System from RF to Digital Data Out

*See

Note 2, AC Electrical Characteristics.

Ordering Information

PART

MAX1470EUI

TEMP RANGE

-40°C to +85°C

PIN-PACKAGE

28 TSSOP

Typical Application Circuit

and

Pin Configuration

appear at

end of data sheet.

Functional Diagram

LNAOUT

MIXIN1

MIXIN2

MIXOUT IFIN1

IFIN2

LIMITING

AMPS

LNAIN

LNA

0°

LNASRC

MAX1470

90°

RSSI

DATA

FILTER

LOOP

FILTER

DF2

100kΩ

DF1

100kΩ

DIVIDE

BY 64

VCO

2,7

PHASE

DETECTOR

5,10

CRYSTAL

DRIVER

XTAL1

XTAL2

SHUTDOWN

DGND

AGND

DATA

SLICER

PEAK

DETECTOR

DSN

DSP

PDOUT

OPP

PWRDN

DATAOUT

19-2135; Rev 1; 9/14
