Switching Spark Gap
SSG5X-1OG
Ordering code:
B88069X9770T502
Nominal breakdown voltage V
N
Initial values
2)
Static breakdown voltage V
S 1)
First ignition value V
S, FTE
after 24 hours in darkness
Following ignition values V
S, FIV
Electrical life time
3)
Breakdown voltage V
B
First ignition value V
B, FTE
after 24 hours in darkness
Following ignition values V
B, FIV
Switching operations
at -10 ... +100 °C
Test circuit parameters
Open circuit voltage V
0
Loading resistance R
Discharge capacitance C
Inductance L
Discharge peak current I
P
General technical data
Insulation resistance at 100 V
Early ignition values below 3750 V
Breakdown time
Maximum switching frequency
Weight
Storage temperature range
Marking, red
5000
V
£
6500
4000 ... 6000
V
V
£
7000
3750 ... 6250
100 000
7000
4000
1
20
30
> 100
£
5
£
50
100
~2
-20 ... +110
5000
YY
O
D
V
V
Ignitions
V
kW
nF
µH
A
MW
%
ns
Hz
g
°C
- Nominal voltage
- Year of production
- Non radioactive
- w/o Humidity Protection Film
5000 YY O
D
1)
2)
3)
At delivery AQL 0,65 level II, DIN ISO 2859
Page 2, Fig. 1 and 2
Page 2, Fig. 3 and 4
KB AB E / KB AB PM
Page 1 of 2
Issue 05, 16.06.2004
Switching Spark Gap
SSG5X-1OG
Ordering code:
B88069X9770T502
Fig. 1:
QC- test circuit (100% outgoing inspection)
I = const
51kW
Fig. 2:
Explanation of measurands
V
S, FTE
V
S
V
S, FIV
0,22mF
DUT
V
S
V
N
t
ICU
DUT device under test
ICU ignition control unit (sensitivity 10 .. 30
mA)
Discharge current 10 – 20 mA
Fig. 3:
QC- test circuit (sampling inspection at 25 °C)
R
L
V
B
V
N
V
O
C
DUT
V
B
- V
N
dV
S
/dt ~ dV
N
/dt
Fig. 4:
Explanation of measurands
V
B, FTE
Range of V
B, FIV
Early ignition
V
B, FTE
t
t
I
1s
10 s
Not to scale
Dimensions in mm
Non controlled document
Ó
EPCOS AG 2002. Reproduction, publication and dissemination of this data sheet, enclosures hereto and the information
contained therein without EPCOS' prior express consent is prohibited.
Purchase orders are subject to the General Conditions for the Supply of Products and Services of the Electrical and
Electronics Industry recommended by the ZVEI (German Electrical and Electronic Manufacturers' Association), unless
otherwise agreed.
KB AB E / KB AB PM
Page 2 of 2
Issue 05, 16.06.2004
