Table of Contents
Part Number Configurator Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
AC Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Harsh Environment Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Louvered Filter Fan Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
AC Smart Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Spot Cooling Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
DC Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Special Function Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Fan Trays - AC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Fan Trays - Smart Fan Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Fan Trays - Thermalcare AC/DC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
AC Impellers and Blowers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
DC Blowers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Airflow Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
Fan Guards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
Fan Filter Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Louvered Fan Guards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144
Fan Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
AC Power Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
Cross Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155
OEM Price List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160
Note 1: The drawings and photos featured in this catalog may
not reflect the newest frames and designs that are currently
available. Design changes and improvements may be made
without prior notification.
Note 2: Data tolerance is +/-10%.
Note 3: ORION FANS meet UL/cUL, TUV, VDE and CE Stan-
dards. Most ORION FANS are UL/cUL approved and most
carry European approvals as well. Models not currently regis-
tered with European approval agencies will be submitted (at
our discretion) upon customer request.
fa n facts...
Dual Ball bearing fans will run continuously and reliably for
up to 60,000+ hours based on L10 calculations. L10 life for
sleeve bearing fans is up to 30,000 hours and sealed sleeve
over 50,000 hours. Life will vary depending on the fan size
and operating conditions and temperature.
Life Expectancy
Note 4: Additional AC and DC voltages not covered in this cat-
alog are available by special order. Ultra High and Ultra Low
speeds are also available by special order. (Minimums may
apply.)
Note 5: We make additions to our product line frequently. If
you cannot find what you are looking for please give us a call
at 800-323-2439 or 214-340-0265 or visit our website at
www.orionfans.com.
Note 6: Product is warranted against defects in workmanship
and materials for 1 year from date of purchase.
US
AC Fans - Diecast aluminum
DC Fans - UL94V-0 glass fiber reinforced plastic is standard
for frame sizes 120mm and smaller. Aluminum frames are
standard for 127mm and larger. 120mm frames are available
in both plastic and aluminum.
Fra mes
Glass reinforced thermoplastic - UL94V-0. Optional metal im-
pellers are available for a number of models.
Impellers
ISO 9001:2008 Certified 951001232-A
UL E170149
1
ORION FANS is a registered trademark of Knight Electronics
Orion Fans Part Number Configurator Tables - AC Fans
OA 109 AP - 22 - 1 T B - 18
Special Function:
R
= Reverse Airflow
18
= Metal Impeller
SF
= Salt Fog Rated
03
= Temperature Control
55 or IP55
= IP55 Rated
Bearing Type: B
= Ball bearing
Termination: T
= Quick connect terminals
Speed Version:
1
= High Speed
2
= Medium Speed
S
= Sleeve Bearing
W
= 12" wire leads
3
= Low Speed
XC
= High Performance
56
= IP56 Rated
2
Voltage: 11
= 115VAC
12, 115
= 120VAC
22, 23, 230
= 230VAC
11/22 or 1/2
= Dual Voltage (115VAC or 230VAC depending on wire connections)
AP
= Aluminum painted
AN
= Aluminum natural finish
SAP
= Stackable aluminum painted
APL
= Aluminum painted, low profile
ANL
= Aluminum natural finish, low profile
SAPL
= Stackable aluminum painted, low profile
825
=
80 x 80 x 25
938
=
92 x 92 x 38
4715
=
120 x 120 x 38 (low cost)
162
=
172 x 172 x 55 (metal)
172
=
172 x 172 x 51
180
(ANL/APL)
=
180 x 180 x 65
205
=
205 x 72
2543
=
254 x 89 (3 blade)
80
=
80 x 80 x 38
125
=
120 x 120 x 25
119
=
127 x 127 x 38
162-5E
=
172 x 172 x 55
172
(SAP/ X C)
=
172 x 150 x 55
200
=
200 x 220 x 70
225
=
225 x 225 x 80
2547
=
254 x 89 (7 blade)
60
=
60 x 60 x 30
92
=
92 x 92 x 25
109
=
120 x 120 x 38
5920
or
172
(SAP)
=
172 x 150 x 51
172
(SAPL)
=
172 x 150 x 38
180
=
176 x 176 x 89
200EC
=
250 x 76
254
=
254 x 89
280
=
280 x 280 x 80
Special function codes may not appear on the
fan label unless specified by the customer
Frame Type:
Model:
(case size in mm)
Base Model
OA =
AC fan
Orion Fans Part Number Configurator Tables - DC Fans
OD 12 38 AP-12 H T B - 01
Special Function:
01=Tachometer
Output 5VTTL*
04=Thermistor
Speed Control (wire)
07=Temperature
Sensor
10=Tachometer*+PWM
13=Alarm*+PWM
16=Tachometer*+Alarm*+Thermistor
19=High
Temperature
55 or IP55=IP55
Rated
02=Alarm
Output 5VTTL*
05=PWM
Input
08=Tachometer*+Alarm*
11=Tachometer*+Temperature
Sensor
14=Alarm*+Temperature
Sensor
17=Extra
Long Lead Wires
20=Conformal
Coating
SF=Salt
Fog Rated
* To specify "open collector" instead of 5VTTL, add the letter "a" after the special functions code
03=Thermistor
Speed Control (hub)
06=Dual
Speed
09=Tachometer*+Thermistor
12=Alarm*+Thermistor
15=Tachometer*+Alarm*+PWM
18=Metal
Impeller
21=Customized
High Static Pressure: XC=High
Performance
Bearing Type: B
= Ball bearing
Termination: T
= Quick connect terminals
Speed Version: HH=Extra
High Speed
L=Low
Speed
Voltage: 05
= 5VDC
12
= 12VDC
24
= 24VDC
S
= Sleeve Bearing
VXC=Vane
Axial
XC,XE,XJ=Super
High Performance
SS
= Sealed Sleeve Bearing
3
{blank}
= 12" wire leads
M=Medium
Speed
H=High
Speed
LL=Extra
Low Speed
48
= 48VDC
60
= 60VDC
Other voltages available
Frame Type: {blank}
= Thermoplastic Construction
SAPL
= Stackable Diecast Aluminum Black, Low Profile
SAP
= Stackable Diecast Aluminum Black
SPOT / DIN
= Spot Cooling w/ AC Adapter & DIN mounting package
06 =
6mm
32 =
32mm
25
= 25 x 25
70
= 70 x 70
172
= 172 x 150
10 =
10mm
35 =
35mm
15 =
15mm
38 =
38mm
20 =
20mm
45 =
45mm
40
= 40 x 40
92
= 92 x 92
254
= 254 x 89
25 =
25mm
56 =
56mm
50
= 50 x 50
12
= 120 x 120
280
= 280 x 89
Additional suffixes consisting of both numbers and
letters may be applied for multiple fan modifications
AP
= Diecast Aluminum Black
APL
= Diecast Aluminum Black, Low Profile
SPOT
= Spot Cooling w/ AC Adapter
Thickness:
28 =
28mm
Frame Size (in mm):
30
= 30 x 30
80
= 80 x 80
180
= 180 x 65
52
= 52 x 52
127
= 127 x 38
60
= 60 x 60
172(SAPL) =
172 x 38
Thickness dimensions are not included in part numbers
for these frame sizes: 127, 172, 180, 254, 280
Base Model: OD =
DC fan
Special function codes may not appear on the
fan label unless specified by the customer
