STANDARD TIMER HOUSING
| Parameter Name | Attribute value |
| Connector System | line to line |
| Sealable | no |
| Connectors and terminals terminate to | Wires and cables |
| Glow Wire Ratings | Standard Parts - Non-Glow Wire |
| stress relief | Without |
| Connector type | jacket |
| Connector type | female end |
| Number of Positions | 11 |
| Rows | 1 |
| Key rib number (between or at) | 2&3 |
| color | Khaki |
| Cable termination method | crimp |
| PCB installation and fixation | Without |
| Mating connector latch type | latch, latch |
| Panel mount features | Without |
| Engage connector latch | with |
| joint fixation | with |
| Joint fixation type | lock, lock |
| Connector mounting type | Cable installation |
| joint alignment | with |
| Lock type | latch |
| Number of cavities between lock pins | 5&6 |
| Joint alignment type | keying |
| Polarization rib position | 1b,11b |
| Lock type | interior |
| Centerline (Pitch) | 5 mm [ .197 in ] |
| Shell material | PA 6.6 |
| Shell color | nature |
| length | 55 mm [ 2.16 in ] |
| high | 12.2 mm [ .48 in ] |
| Working group temperature range | -55 – 105 °C [ -67 – 221 °F ] |
| Circuit Application | Power and Signal |
| UL flammability rating | UL 94V-2 |
| RAST version | none |
| Encapsulation method | bag/box |
| Package quantity | 800 |
| 1-928343-1 | 3-928343-8 | |
|---|---|---|
| Description | STANDARD TIMER HOUSING | STD-TIMER GEH 8P |
| Connector System | line to line | line to line |
| Sealable | no | no |
| Connectors and terminals terminate to | Wires and cables | Wires and cables |
| Glow Wire Ratings | Standard Parts - Non-Glow Wire | Standard Parts - Non-Glow Wire |
| stress relief | Without | Without |
| Number of Positions | 11 | 8 |
| Rows | 1 | 1 |
| Key rib number (between or at) | 2&3 | 1&2,3&4,7&8 |
| color | Khaki | grey |
| Cable termination method | crimp | crimp |
| PCB installation and fixation | Without | Without |
| Mating connector latch type | latch, latch | latch, latch |
| Panel mount features | Without | Without |
| Engage connector latch | with | with |
| joint fixation | with | with |
| Joint fixation type | lock, lock | lock, lock |
| Connector mounting type | Cable installation | Cable installation |
| joint alignment | with | with |
| Number of cavities between lock pins | 5&6 | 2&3, 7&8 |
| Joint alignment type | keying | keying |
| Polarization rib position | 1b,11b | 8b |
| Centerline (Pitch) | 5 mm [ .197 in ] | 5 mm [ .197 in ] |
| Shell material | PA 6.6 | PA 6.6 |
| Shell color | nature | grey |
| length | 55 mm [ 2.16 in ] | 40 mm [ 1.574 in ] |
| high | 12.2 mm [ .48 in ] | 12.2 mm [ .48 in ] |
| Working group temperature range | -55 – 105 °C [ -67 – 221 °F ] | -55 – 105 °C [ -67 – 221 °F ] |
| Circuit Application | Power and Signal | Power and Signal |
| UL flammability rating | UL 94V-2 | UL 94V-2 |
| RAST version | none | none |
| Encapsulation method | bag/box | Package |
| Package quantity | 800 | 1000 |
| Connector type | female end | female end |
| Lock type | interior | interior |
