Protective conductor double-level terminal block - PTTB 2,5/2P-
PE - 3210897
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Protective conductor double-level terminal block, connection method: Push-in / plug connection, cross section:
0.14 mm² - 4 mm², AWG: 26 - 12, width: 5.2 mm, color: green-yellow, mounting type: NS 35/7,5, NS 35/15
Your advantages
The Push-in connection terminal blocks are characterized by the system features of the CLIPLINE complete system and by easy and tool-free
wiring of conductors with ferrules or solid conductors
The compact design and front connection enable wiring in a confined space
In addition to the testing facility in the double function shaft, all terminal blocks provide an additional test connection
Tested for railway applications
Key Commercial Data
Packing unit
GTIN
GTIN
4046356412049
50 pc
Technical data
General
Number of levels
Number of connections
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Area of application
2
4
2.5 mm²
green-yellow
PA
V0
Railway industry
Machine building
Plant engineering
Rated surge voltage
6 kV
11/11/2018 Page 1 / 5
https://www.phoenixcontact.com/pi/products/3210897
Protective conductor double-level terminal block - PTTB 2,5/2P-
PE - 3210897
Technical data
General
Degree of pollution
Overvoltage category
Insulating material group
Connection in acc. with standard
Open side panel
Insertion/withdrawal cycles mechanical
Oscillation, broadband noise test result
Test specification, oscillation, broadband noise
Test spectrum
Test frequency
ASD level
Acceleration
Test duration per axis
Test directions
Shock test result
Test specification, shock test
Shock form
Acceleration
Shock duration
Number of shocks per direction
Test directions
Relative insulation material temperature index (Elec.; UL 746 B)
Temperature index of insulation material (DIN EN 60216-1 (VDE
0304-21))
Static insulating material application in cold
Behavior in fire for rail vehicles (DIN 5510-2)
Flame test method (DIN EN 60695-11-10)
Oxygen index (DIN EN ISO 4589-2)
NF F16-101, NF F10-102 Class I
NF F16-101, NF F10-102 Class F
Surface flammability NFPA 130 (ASTM E 162)
Specific optical density of smoke NFPA 130 (ASTM E 662)
Smoke gas toxicity NFPA 130 (SMP 800C)
Calorimetric heat release NFPA 130 (ASTM E 1354)
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
3
III
I
IEC 61984
Yes
100
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Service life test category 1, class B, body mounted
f
1
= 5 Hz to f
2
= 150 Hz
0.964 (m/s ) /Hz
0.58 g
5h
X-, Y- and Z-axis
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Half-sine
5g
30 ms
3
X-, Y- and Z-axis (pos. and neg.)
130 °C
130 °C
-60 °C
Test passed
V0
>32 %
2
2
passed
passed
passed
28 MJ/kg
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
2 2
Dimensions
11/11/2018 Page 2 / 5
https://www.phoenixcontact.com/pi/products/3210897
Protective conductor double-level terminal block - PTTB 2,5/2P-
PE - 3210897
Technical data
Dimensions
Width
Length
Height NS 35/7,5
Height NS 35/15
5.2 mm
71.5 mm
47.5 mm
55 mm
Connection data
Note
Connection method
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
Stripping length
Internal cylindrical gage
Please observe the current carrying capacity of the DIN rails.
Push-in / plug connection
0.14 mm²
4 mm²
0.14 mm²
2.5 mm²
26
12
0.14 mm²
0.14 mm²
2.5 mm²
0.5 mm²
8 mm ... 10 mm
A3
Conductor cross section flexible, with ferrule without plastic sleeve max. 2.5 mm²
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
CSA
IEC 61984
V0
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Drawings
Circuit diagram
11/11/2018 Page 3 / 5
https://www.phoenixcontact.com/pi/products/3210897
Protective conductor double-level terminal block - PTTB 2,5/2P-
PE - 3210897
Approvals
Approvals
Approvals
DNV GL / CSA / BV / LR / NK / ABS / UL Recognized / cUL Recognized / cULus Recognized
Ex Approvals
Approval details
DNV GL
http://exchange.dnv.com/tari/
TAE00000UD_01
CSA
mm²/AWG/kcmil
B
26-12
http://www.csagroup.org/services-industries/product-listing/
26-12
13631
BV
http://www.veristar.com/portal/veristarinfo/generalinfo/
approved/approvedProducts/equipmentAndMaterials
25278/B0 BV
LR
http://www.lr.org/en
10/20040
NK
http://www.classnk.or.jp/hp/en/
14ME0912
ABS
http://www.eagle.org/eagleExternalPortalWEB/
16-HG1591536-PDA
UL Recognized
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
26-12
FILE E 60425
11/11/2018 Page 4 / 5
https://www.phoenixcontact.com/pi/products/3210897
Protective conductor double-level terminal block - PTTB 2,5/2P-
PE - 3210897
Approvals
cUL Recognized
mm²/AWG/kcmil
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
26-12
FILE E 60425
26-12
cULus Recognized
