Extract from the online
catalog
UT 35-PE
Order No.: 3044241
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3044241
Feed-through modular terminal block, Type of connection: Screw
connection, Screw connection, Cross section: 1.5 mm² - 35 mm²,
AWG 16 - 2, Width: 16 mm, Color: green-yellow, Mounting type: NS
35/7.5, NS 35/15
Product notes
Commercial data
GTIN (EAN)
sales group
Pack
Customs tariff
Weight/Piece
Catalog page information
4017918977580
A803
50 pcs.
85369010
0.08579 KG
Page 34 (CL-2009)
http://
www.download.phoenixcontact.com
Please note that the data given
here has been taken from the
online catalog. For comprehensive
information and data, please refer
to the user documentation. The
General Terms and Conditions of
Use apply to Internet downloads.
WEEE/RoHS-compliant since:
01/01/2005
Technical data
General
Number of levels
Number of connections
Color
1
2
green-yellow
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 1 / 6
Oct 27, 2010
UT 35-PE
Order No.: 3044241
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3044241
Insulating material
Inflammability class acc. to UL 94
Dimensions
Width
Length
Height NS 35/7.5
Height NS 35/15
Technical data
Maximum load current
Rated surge voltage
Pollution degree
Surge voltage category
Insulating material group
Connection in acc. with standard
Nominal current I
N
Open side panel
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section stranded min.
Conductor cross section stranded max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded, with ferrule
without plastic sleeve min.
Conductor cross section stranded, with ferrule
without plastic sleeve max.
Conductor cross section stranded, with ferrule
with plastic sleeve min.
Conductor cross section stranded, with ferrule
with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded
min.
PA
V0
16 mm
60.2 mm
65.7 mm
73.2 mm
125 A (with 35 mm conductor cross section)
8 kV
3
III
I
IEC 60947-7-2
125 A
nein
2
1.5 mm²
35 mm²
1.5 mm²
35 mm²
16
2
1.5 mm²
35 mm²
1.5 mm²
35 mm²
1.5 mm²
16 mm²
1.5 mm²
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 2 / 6
Oct 27, 2010
UT 35-PE
Order No.: 3044241
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3044241
2 conductors with same cross section, stranded
max.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, min.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, max.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, min.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, max.
Type of connection
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
Certificates / Approvals
10 mm²
1.5 mm²
10 mm²
1.5 mm²
10 mm²
Screw connection
18 mm
B9
M6
3.2 Nm
3.7 Nm
Certification
Certification Ex:
CSA
AWG/kcmil
CUL
AWG/kcmil
UL
AWG/kcmil
Accessories
Item
Assembly
0801762
NS 35/ 7,5 CU UNPERF
2000MM
Designation
CB, CSA, CUL, GL, UL, VDE-PZI
IECEx, KEMA-EX
14-0
14-2
14-2
Description
DIN rail, material: Copper, unperforated, height 7.5 mm, width 35
mm, length: 2 m
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 3 / 6
Oct 27, 2010
UT 35-PE
Order No.: 3044241
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3044241
1207640
1207653
1207666
0801733
0801681
1201756
1201895
1207679
1207682
1207695
1201730
1201714
1201798
0706647
NS 35/ 7,5 PERF 755MM
NS 35/ 7,5 PERF 955MM
NS 35/ 7,5 PERF 1155MM
NS 35/ 7,5 PERF 2000MM
NS 35/ 7,5 UNPERF 2000MM
NS 35/15 AL UNPERF 2000MM
NS 35/15 CU UNPERF 2000MM
NS 35/15 PERF 755MM
NS 35/15 PERF 955MM
NS 35/15 PERF 1155MM
NS 35/15 PERF 2000MM
NS 35/15 UNPERF 2000MM
NS 35/15-2,3 UNPERF 2000MM
TPNS-UK
NS 35 DIN rail, height 7.5 mm, length 755 mm
NS35 DIN rail, height 7.5 mm, length 955 mm
NS 35 DIN rail, height 7.5 mm, length 1155 mm
DIN rail, material: Steel, galvanized and passivated with a thick
layer, perforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail, material: Steel, unperforated, height 7.5 mm, width 35
mm, length: 2 m
DIN rail, deep-drawn, high profile, unperforated, 1.5 mm thick,
material: Aluminum, height 15 mm, width 35 mm, length 2 m
DIN rail, material: Copper, unperforated, 1.5 mm thick, height 15
mm, width 35 mm, length: 2 m
NS 35 DIN rail, perforated, height 15 mm, length 755 mm
NS 35 DIN rail, perforated, height 15 mm, length 955 mm
NS 35 DIN rail, perforated, height 15 mm, length 1155 mm
DIN rail, material: Steel, perforated, height 15 mm, width 35 mm,
length: 2 m
DIN rail, material: Steel, unperforated, height 15 mm, width 35
mm, length: 2 m
DIN rail, material: Steel, unperforated, 2.3 mm thick, height 15
mm, width 35 mm, length: 2 m
Separating plate, Length: 80 mm, Width: 2 mm, Height: 70 mm,
Color: gray
Bridges
3005963
3047277
General
3047280
Marking
3047387
0811228
0811998
0811985
0811972
WS UT 35
X-PEN 0,35
ZB 15,LGS:L1-N,PE
ZB 15:SO/CMS
ZB 15:UNBEDRUCKT
Warning sign for UT terminal blocks
Marker pen without ink cartridge, for manual labeling of markers,
labeling extremely wipe-proof, line thickness 0.35 mm
Zack marker strip, printed horizontally: 5-section, L1, L2, L3, N,
PE, color: White
Zack marker strip, 5-section, divisible, special printing, marking
according to customer requirements
Zack marker strip, unprinted: 5-section, for individual labeling with
M-PEN, ZB-T or CMS system, sufficient for 100 terminal blocks,
for a terminal width of 15 mm, color: White
RB UT 35-ST(2,5/4)
Reducing bridge, Number of positions: 2, Color: red
FBS 2-16
RB UT 35-(2,5/4)
Plug-in bridge, Number of positions: 2, Color: red
Reducing bridge, Number of positions: 2, Color: red
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 4 / 6
Oct 27, 2010
