https://www.phoenixcontact.com/us/produkte/1777574
PCB terminal block - MKDS 5N HV/ 5-ZB-6,35 - 1777574
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://download.phoenixcontact.com)
PCB terminal block, Nominal current: 41 A, Nom. voltage: 1000 V, Pitch: 6.35 mm, Number of positions: 5,
Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color:
green
The illustration shows the 5-pos.
version
Product Features
Versions with anti-rotation pins (MKDSV, recommended for 2-pos. connections)
MKDS 5N HV high-voltage PCB terminal blocks with increased air and creepage distances
Unlimited 600 V UL approval thanks to compact zigzag pinning (MKDS 5N HV/...ZB-6,35 and MKDS 5 HV/...-9,52-Z)
Key commercial data
Packing unit
Catalog page
GTIN
Custom tariff number
Country of origin
85369010
GERMANY
1 PCE
Page 365 (CC-2011)
Technical data
Dimensions / positions
Length
Height
Pitch
Dimension a
Number of positions
Pin dimensions
Pin spacing
Hole diameter
15.85 mm
32 mm
6.35 mm
25.4 mm
5
0,9 x 0,9 mm
9 mm
1.3 mm
03.04.2013 Page 1 / 6
https://www.phoenixcontact.com/us/produkte/1777574
PCB terminal block - MKDS 5N HV/ 5-ZB-6,35 - 1777574
Technical data
Dimensions / positions
Screw thread
Tightening torque, min
Tightening torque max
M3
0.5 Nm
0.6 Nm
Technical data
Range of articles
Insulating material group
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
Maximum load current
Insulating material
Inflammability class according to UL 94
Stripping length
Nominal voltage, UL/CUL Use Group B
Nominal current, UL/CUL Use Group B
Nominal voltage, UL/CUL Use Group C
Nominal current, UL/CUL Use Group C
MKDS 5 N HV
I
8 kV
8 kV
8 kV
800 V
1000 V
1000 V
EN-VDE
41 A
4 mm²
41 A
PA
V0
8 mm
600 V
30 A
600 V
30 A
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section stranded min.
Conductor cross section stranded max.
Conductor cross section stranded, with ferrule without plastic sleeve min.
Conductor cross section stranded, with ferrule without plastic sleeve max.
Conductor cross section stranded, with ferrule with plastic sleeve min.
Conductor cross section stranded, with ferrule with plastic sleeve max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
0.2 mm²
6 mm²
0.2 mm²
4 mm²
0.2 mm²
4 mm²
0.25 mm²
4 mm²
24
10
0.2 mm²
1.5 mm²
03.04.2013 Page 2 / 6
https://www.phoenixcontact.com/us/produkte/1777574
PCB terminal block - MKDS 5N HV/ 5-ZB-6,35 - 1777574
Technical data
Connection data
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
0.2 mm²
1.5 mm²
0.25 mm²
0.75 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
2.5 mm²
sleeve, max.
Minimum AWG according to UL/CUL
Maximum AWG according to UL/CUL
30
10
Classifications
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC001121
EC002643
EC002643
UNSPSC
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
UNSPSC 6.01
UNSPSC 7.0901
39121432
39121432
39121432
30211801
39121432
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
27141109
27141109
27141190
27141190
27261101
27440401
Approvals
Approvals
03.04.2013 Page 3 / 6
https://www.phoenixcontact.com/us/produkte/1777574
PCB terminal block - MKDS 5N HV/ 5-ZB-6,35 - 1777574
Approvals
Approvals
UL Recognized / cUL Recognized / GOST / SEV / CCA / cULus Recognized
Ex Approvals
Approvals submitted
Approval details
UL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
30-10
30 A
600 V
C
30-10
30 A
600 V
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
B
30-10
30 A
600 V
C
30-10
30 A
600 V
GOST
SEV
mm²/AWG/kcmil
Nominal voltage UN
4
1000 V
03.04.2013 Page 4 / 6
https://www.phoenixcontact.com/us/produkte/1777574
PCB terminal block - MKDS 5N HV/ 5-ZB-6,35 - 1777574
Approvals
CCA
mm²/AWG/kcmil
Nominal voltage UN
4
1000 V
cULus Recognized
Accessories
Accessories
Tools
Screwdriver - SZS 0,6X3,5 - 1205053
Actuation tool, for ST terminal blocks, insulated, also suitable for use as a bladed screwdriver, size: 0.6 x 3.5 x 100 mm,
2-component grip, with non-slip grip
Drawings
Drilling diagram
3,18
6,35
Current strength [A]
Diagram
80
70
60
50
40
30
20
10
0
0
a
2,1
1
2
Ø1,3
+0,1
9
1
= 6 mm
20
40
60
80
100
Ambient temperature [°C]
03.04.2013 Page 5 / 6
