Extract from the online
catalog
UK 3-MVSTB-5,08-F
Order No.: 3002335
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3002335
Feed-through modular terminal block, Nominal current: 12 A, Nominal
voltage: 250 V, Cross-section: 0.2 mm² - 4 mm², AWG: 24 - 12,
Mounting type: NS 35/7.5, NS 35/15, NS 32, Pitch: 5.08 mm,
Width: 5.08, Color: gray
Product notes
Commercial data
GTIN (EAN)
4
017918
090241
WEEE/RoHS-compliant since:
01/01/2003
sales group
Pack
Customs tariff
Catalog page information
A007
50 pcs.
85369010
Page 323 (CL-2005)
http://
www.download.phoenixcontact.com
Please note that the data given
here has been taken from the
online catalog. For comprehensive
information and data, please refer
to the user documentation. The
General Terms and Conditions of
Use apply to Internet downloads.
Technical data
General
Number of levels
Number of connections
Color
1
2
gray
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 1 / 5
Feb 25, 2011
UK 3-MVSTB-5,08-F
Order No.: 3002335
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3002335
Insulating material
Inflammability class acc. to UL 94
Technical data
Maximum load current
Rated surge voltage
Pollution degree
Surge voltage category
Insulating material group
Connection in acc. with standard
Nominal current I
N
Nominal voltage U
N
Connection data
Connection labeling
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section stranded min.
Conductor cross section stranded max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded, with ferrule
without plastic sleeve min.
Conductor cross section stranded, with ferrule
without plastic sleeve max.
Conductor cross section stranded, with ferrule
with plastic sleeve min.
Conductor cross section stranded, with ferrule
with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded
min.
2 conductors with same cross section, stranded
max.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, min.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, max.
PA
V2
12 A (with 4 mm² conductor cross section)
4 kV
3
III
I
IEC / EN
12 A
250 V
1st level connection left
0.2 mm²
4 mm²
0.2 mm²
2.5 mm²
24
12
0.25 mm²
2.5 mm²
0.25 mm²
1.5 mm²
0.2 mm²
1.5 mm²
0.2 mm²
1 mm²
0.25 mm²
0.5 mm²
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 2 / 5
Feb 25, 2011
UK 3-MVSTB-5,08-F
Order No.: 3002335
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3002335
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, min.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, max.
Type of connection
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
Certificates / Approvals
0.5 mm²
1 mm²
Special and hybrid connection
8 mm
A3
M3
0.5 Nm
0.6 Nm
Certification
GOST
Accessories
Item
Assembly
3022218
CLIPFIX 35
Snap-on end bracket, for 35 mm NS 35/7.5 or NS 35/15 DIN
rail, can be fitted with Zack strip ZB 8 and ZB 8/27, terminal strip
marker KLM 2 and KLM, width: 9.5 mm, color: gray
End cover, Length: 48 mm, Width: 2.5 mm, Height: 47 mm,
Color: gray
Spacer plate, Length: 47.7 mm, Width: 2.4 mm, Color: gray
End clamp, for assembly on NS 32 or NS 35/7.5 DIN rail
G rail 32 mm (NS 32)
G-profile DIN rail, deep-drawn, material: Copper, unperforated,
height 15 mm, width 32 mm, length 2 m
G-profile DIN rail, material: Copper, unperforated, height 15 mm,
width 32 mm, length 2 m
G-profile DIN rail, material: Steel, perforated, height 15 mm, width
32 mm, length 2 m
G-profile DIN rail, material: Steel, unperforated, height 15 mm,
width 32 mm, length 2 m
Designation
Description
3002089
3002445
1201442
1201028
1201280
1201358
1201002
1201015
D-UK 3-MVSTB
DP-UK 3-MVSTB
E/UK
NS 32 AL UNPERF 2000MM
NS 32 CU/120QMM UNPERF
2000MM
NS 32 CU/35QMM UNPERF
2000MM
NS 32 PERF 2000MM
NS 32 UNPERF 2000MM
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 3 / 5
Feb 25, 2011
UK 3-MVSTB-5,08-F
Order No.: 3002335
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3002335
0801762
0801733
0801681
1201756
1201895
1201730
1201714
1201798
1705126
2770215
Bridges
2303145
2303158
2770642
3000434
3000476
3000515
3006823
Marking
1007219
0809793
NS 35/ 7,5 CU UNPERF
2000MM
NS 35/ 7,5 PERF 2000MM
NS 35/ 7,5 UNPERF 2000MM
NS 35/15 AL UNPERF 2000MM
NS 35/15 CU UNPERF 2000MM
NS 35/15 PERF 2000MM
NS 35/15 UNPERF 2000MM
NS 35/15-2,3 UNPERF 2000MM
RS-KDS 2,5-LA
TS-KK 3
DIN rail, material: Copper, unperforated, height 7.5 mm, width 35
mm, length: 2 m
DIN rail, material: Steel, galvanized and passivated with a thick
layer, perforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail, material: Steel, unperforated, height 7.5 mm, width 35
mm, length: 2 m
DIN rail, deep-drawn, high profile, unperforated, 1.5 mm thick,
material: Aluminum, height 15 mm, width 35 mm, length 2 m
DIN rail, material: Copper, unperforated, 1.5 mm thick, height 15
mm, width 35 mm, length: 2 m
DIN rail, material: Steel, perforated, height 15 mm, width 35 mm,
length: 2 m
DIN rail, material: Steel, unperforated, height 15 mm, width 35
mm, length: 2 m
DIN rail, material: Steel, unperforated, 2.3 mm thick, height 15
mm, width 35 mm, length: 2 m
Common return busbar, brass, tin-plated, up to 10 A, length: 0.5 m
Separating plate, Length: 14 mm, Height: 16 mm, Color: gray
EBL 2- 5
EBL 3- 5
FBRI 10-5 N
FBRI 12-5 N
FBRI 16-5 N
FBRI 20-5 N
FBRI 40-5 N
Insertion bridge, Number of positions: 2, Color: gray
Insertion bridge, Number of positions: 3, Color: gray
Fixed bridge, Number of positions: 10, Color: silver
Fixed bridge, Number of positions: 12, Color: aluminum
Fixed bridge, Number of positions: 16, Color: aluminum
Fixed bridge, Number of positions: 20, Color: aluminum
Fixed bridge, Number of positions: 40, Color: aluminum
SBS 5:UNBEDRUCKT
ZB 5,08:UNBEDRUCKT
Marker cards for modular terminal blocks, color: white
Zack strip, unprinted: 10-section, for individual labeling with M-
PEN, ZB-T or CMS system, sufficient for 100 terminal blocks per
pack
Tools
1205053
SZS 0,6X3,5
Actuation tool, for ST terminal blocks, insulated, also suitable
for use as a bladed screwdriver, size: 0.6 x 3.5 x 100 mm, 2-
component grip, with non-slip grip
PHOENIX CONTACT Deutschland GmbH
http://www.phoenixcontact.de
Page 4 / 5
Feb 25, 2011
UK 3-MVSTB-5,08-F
Order No.: 3002335
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3002335
Address
PHOENIX CONTACT Deutschland GmbH
Flachsmarktstr. 8
32825 Blomberg,Germany
Phone +49 5235 3 12000
Fax +49 5235 3 41200
http://www.phoenixcontact.de
© 2011 Phoenix Contact
Technical modifications reserved;
PHOENIX CONTACT Deutschland GmbH
