Feed-through terminal block - PT 6-QUATTRO/2P-PE - 3061842
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in
the user's documentation. Our General Terms of Use for Downloads are valid
(http://download.phoenixcontact.com)
Feed-through terminal block, Connection method: Push-in / plug connection, Cross section: 0.5
mm² - 10 mm², AWG: 20 - 8, Width: 8.2 mm, Color: green-yellow
Key commercial data
Packing unit
Minimum order quantity
GTIN
Custom tariff number
Country of origin
85369010
POLAND
0
1
Technical data
General
Number of levels
Number of connections
Color
Insulating material
Inflammability class according to UL 94
1
4
green-yellow
PA
V0
Dimensions
Width
Length
Height NS 35/7,5
Height NS 35/15
8.2 mm
99.8 mm
43.5 mm
51 mm
Technical data
Rated surge voltage
Pollution degree
Surge voltage category
Insulating material group
Connection in acc. with standard
Open side panel
8 kV
3
III
I
IEC 61984
ja
17.01.2013 Page 1 / 20
https://www.phoenixcontact.com/us/produkte/3061842
Feed-through terminal block - PT 6-QUATTRO/2P-PE - 3061842
Technical data
Technical data
Insertion/withdrawal cycles mechanical
Test specification, oscillation, broadband noise
Test spectrum
Test frequency
ASD level
Acceleration
Test duration per axis
Test directions
Oscillation, broadband noise test result
Test specification, shock test
Shock form
Acceleration
Shock duration
Number of shocks per direction
Test directions
Shock test result
Temperature index, insulating material (DIN EN 60216-1 (VDE
0304-21))
Static insulating material application in cold
100
DIN EN 50155 (VDE 0115-200):2008-03
Service life test category 1, class B, on vehicle body
f
1
= 5 Hz to f
2
= 150 Hz
0.964 (m/s ) /Hz
0.58 g
5h
X-, Y- and Z-axis
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Half-sine
5g
30 ms
3
X-, Y- and Z-axis (pos. and neg.)
Test passed
130 °C
-60 °C
2 2
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded min.
Conductor cross section stranded max.
Min. AWG conductor cross section, stranded
Max. AWG conductor cross section, stranded
Conductor cross section stranded, with ferrule without plastic
sleeve min.
Conductor cross section stranded, with ferrule without plastic
sleeve max.
Conductor cross section stranded, with ferrule with plastic sleeve
min.
Conductor cross section stranded, with ferrule with plastic sleeve
max.
2 conductors with same cross section, stranded, TWIN ferrules
with plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules
with plastic sleeve, max.
Connection method
Stripping length
Internal cylindrical gage
0.5 mm²
10 mm²
20
8
0.5 mm²
6 mm²
20
10
0.5 mm²
6 mm²
0.5 mm²
6 mm²
0.5 mm²
1.5 mm²
Push-in / plug connection
12 mm
A5
17.01.2013 Page 2 / 20
https://www.phoenixcontact.com/us/produkte/3061842
Feed-through terminal block - PT 6-QUATTRO/2P-PE - 3061842
Classifications
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC000901
EC000901
EC000901
UNSPSC
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
UNSPSC 6.01
UNSPSC 7.0901
39121410
39121410
39121410
30211811
39121410
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
27141118
27141118
27141118
27141125
27141125
27141125
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / cULus Recognized
Ex Approvals
Approvals submitted
Approval details
UL Recognized
mm²/AWG/kcmil
B
20-8
C
20-8
17.01.2013 Page 3 / 20
https://www.phoenixcontact.com/us/produkte/3061842
Feed-through terminal block - PT 6-QUATTRO/2P-PE - 3061842
Approvals
cUL Recognized
mm²/AWG/kcmil
B
20-8
C
20-8
cULus Recognized
Accessories
Accessories
Assembly
Partition plate - ATP-QTTCB - 3206238
Partition plate, Length: 102 mm, Width: 2 mm, Height: 54 mm, Color: gray
DIN rail perforated - NS 35/ 7,5 PERF 2000MM - 0801733
DIN rail, material: steel galvanized and passivated with a thick layer, perforated, height 7.5 mm, width 35
mm, length: 2000 mm
DIN rail - NS 35/ 7,5 UNPERF 2000MM - 0801681
DIN rail, material: Steel, unperforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail - NS 35/ 7,5 WH PERF 2000MM - 1204119
DIN rail 35 mm (NS 35)
17.01.2013 Page 4 / 20
https://www.phoenixcontact.com/us/produkte/3061842
Feed-through terminal block - PT 6-QUATTRO/2P-PE - 3061842
Accessories
DIN rail - NS 35/ 7,5 WH UNPERF 2000MM - 1204122
DIN rail 35 mm (NS 35)
DIN rail - NS 35/ 7,5 AL UNPERF 2000MM - 0801704
DIN rail, material: Aluminum, unperforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail - NS 35/ 7,5 ZN PERF 2000MM - 1206421
DIN rail, material: Galvanized, perforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail - NS 35/ 7,5 ZN UNPERF 2000MM - 1206434
DIN rail, material: Galvanized, unperforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail - NS 35/ 7,5 CU UNPERF 2000MM - 0801762
DIN rail, material: Copper, unperforated, height 7.5 mm, width 35 mm, length: 2 m
End cap - NS 35/ 7,5 CAP - 1206560
DIN rail end piece, for DIN rail NS 35/7.5
DIN rail perforated - NS 35/15 PERF 2000MM - 1201730
DIN rail, material: steel galvanized and passivated with a thick layer, perforated, height 15 mm, width 35
mm, length: 2000 mm
17.01.2013 Page 5 / 20
