Tri-State Enable/Disable 5.0V Oscillator
Model: F5C-2ElF
RoHS Compliant / Pb Free
Rev. 10/24/2011
http://www.foxonline.com/need_a_sample.htm
FEATURES
•
•
•
•
5.0V Operationg
HCMOS/TTL Output
Tri-State Enable/Disable
14-Pin DIP
OPTiOnS
• 8-Pin DIP Available (H5C-2ELF)
• PART nUMbER SElECTiOn
Learn More - Internet Required
Part Number
147LF-Freq-xxxxx
326LF-Freq-xxxxx
180LF-Freq-xxxxx
Model
Number
F5C-2ELF
F5C-2ERLF
F6C-2ELF
Frequency
Operating
Stability
1
Temperature (ºC)
±100PPM
0 ~ +70
±100PPM
-40 ~ +85
±50PPM
0 ~ +70
Frequency
Range (MHz)
1.500 ~ 59.000
1.500 ~ 59.000
1.500 ~ 59.000
• ElECTRiCAl CHARACTERiSTiCS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.500 ~ 40.000 MHz
40.000+ ~ 59.000 MHz
Output Symmetry (50% V
dd
)
1.500 ~ 50.000 MHz
50.000+ ~ 59.000 MHz
Rise Time (10% ~ 90% V
dd
) (T
r
)
1.500 ~ 59.000 MHz
Fall Time (90% ~ 10% V
dd
) (T
f
)
1.500 ~ 59.000 MHz
Output Voltage
(V
ol
)
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
TTL
HCMOS
Start-up Time
(T
s
)
Output Enable/Disable Time
2
1
45% ~ 55%
40% ~ 60%
T
R
EC
O
M
M
O
EN
10 nS
10% V
dd
90% V
dd
Min
16mA Min
-16mA Min
10TTL
50pF
10mS
100nS
D
ED
10 nS
FO
40mA
60mA
R
N
1.500 ~ 59.000 MHz
-55ºC ~ +125ºC
5.0V ± 10%
EW
All dimensions are in millimeters.
PARAMETERS
MAX
(unless otherwise noted)
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
2
An internal pullup resistor from pin 1 to V
DD
allows active output if pin 1 is left open.
All specifications subject to change without notice.
N
• EnAblE / DiSAblE FUnCTiOn
INH (Pin 1)
OUTPUT (Pin 8)
OPEN
2
ACTIVE
'1' Level V
ih
≥
2.2 V
ACTIVE
'0' Level V
il
≤
0.8 V
High Z
