HS-1840ARH
Data Sheet
August 1999
File Number
4355.1
Rad-Hard 16 Channel CMOS Analog
Multiplexer with High-Z Analog Input
Protection
The HS-1840ARH is a radiation hardened, monolithic 16
channel multiplexer constructed with the Intersil Rad-Hard
Silicon Gate, bonded wafer, Dielectric Isolation process. It is
designed to provide a high input impedance to the analog
source if device power fails (open), or the analog signal
voltage inadvertently exceeds the supply by up to
±35V,
regardless of whether the device is powered on or off.
Excellent for use in redundant applications, since the
secondary device can be operated in a standby unpowered
mode affording no additional power drain. More significantly,
a very high impedance exists between the active and
inactive devices preventing any interaction. One of sixteen
channel selection is controlled by a 4-bit binary address plus
an Enable-Inhibit input which conveniently controls the
ON/OFF operation of several multiplexers in a system. All
inputs have electrostatic discharge protection.
The HS-1840ARH is processed and screened in full compliance
with MIL-PRF-38535 and QML standards. The device is
available in a 28 lead SBDIP and a 28 lead Ceramic Flatpack.
Specifications for Rad Hard QML devices are controlled
by the Defense Supply Center in Columbus (DSCC). The
SMD numbers listed here must be used when ordering.
Detailed Electrical Specifications for these devices are
contained in SMD 5962-95630. A “hot-link” is provided
on our homepage for downloading.
http://www.intersil.com/spacedefense/space.htm
Features
• Electrically Screened to SMD # 5962-95630
• QML Qualified per MIL-PRF-38535 Requirements
• Pin-to-Pin for Intersil’s HS-1840RH and HS-1840/883S
• Improved Radiation Performance
- Gamma Dose (γ) 3 x 10
5
RAD(Si)
• Improved r
DS(ON)
Linearity
• Improved Access Time 1.5µs (Max) Over Temp and Post
Rad
• High Analog Input Impedance 500MΩ During Power Loss
(Open)
•
±35V
Input Over Voltage Protection (Power On or Off)
• Dielectrically Isolated Device Islands
• Excellent in Hi-Rel Redundant Systems
• Break-Before-Make Switching
• No Latch-Up
Ordering Information
ORDERING NUMBER
5962F9563002QXC
5962F9563002QYC
5962F9563002V9A
5962F9563002VXC
5962F9563002VYC
INTERNAL
MKT. NUMBER
HS1-1840ARH-8
HS9-1840ARH-8
HS0-1840ARH-Q
HS1-1840ARH-Q
HS9-1840ARH-Q
TEMP. RANGE
(
o
C)
-55 to 125
-55 to 125
25
-55 to 125
-55 to 125
-55 to 125
-55 to 125
HS1-1840ARH/PROTO HS1-1840ARH/PROTO
HS9-1840ARH/PROTO HS9-1840ARH/PROTO
Pinouts
HS1-1840ARH (SBDIP) CDIP2-T28
TOP VIEW
+V
S
1
NC 2
NC 3
IN 16 4
IN 15 5
IN 14 6
IN 13 7
IN 12 8
IN 11 9
IN 10 10
IN 9 11
GND 12
(+5V
S
) V
REF
13
ADDR A3 14
28 OUT
27 -V
S
26 IN 8
25 IN 7
24 IN 6
23 IN 5
22 IN 4
21 IN 3
20 IN 2
19 IN 1
18 ENABLE
17 ADDR A0
16 ADDR A1
15 ADDR A2
+V
S
NC
NC
IN 16
IN 15
IN 14
IN 13
IN 12
IN 11
IN 10
IN 9
GND
(+5V
S
) V
REF
ADDR A3
HS9-1840ARH (FLATPACK) CDFP3-F28
TOP VIEW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
OUT
-V
S
IN 8
IN 7
IN 6
IN 5
IN 4
IN 3
IN 2
IN 1
ENABLE
ADDR A0
ADDR A1
ADDR A2
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright © Intersil Americas Inc. 2002. All Rights Reserved
HS-1840ARH
Burn-In/Life Test Circuits
R
+V
S
R
1
2
3
4
5
6
7
8
9
10
GND
F4
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
F3
F1
F2
F5
GND
V
R
R
-V
S
+V
S
R
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
R
-V
S
R
R
NOTES:
V
S
+ = +15.5V
±0.5V,
V
S
- = -15.5V
±0.5V.
R = 1kΩ
±5%.
C
1
= C
2
= 0.01µF
±10%,
1 each per socket, minimum.
D
1
= D
2
= 1N4002, 1 each per board, minimum.
Input Signals: square wave, 50% duty cycle, 0V to 15V peak
±10%.
F1 = 100kHz; F2 = F1/2; F3 = F1/4; F4 = F1/8; F5 = F1/16.
FIGURE 1. DYNAMIC BURN-IN AND LIFE TEST CIRCUIT
NOTES:
1. The above test circuits are utilized for all package types.
2. The Dynamic Test Circuit is utilized for all life testing.
NOTES:
R = 1kΩ
±5%,
1
/
4
W.
C
1
= C
2
= 0.01µF minimum, 1 each per socket, minimum.
V
S
+ = 15.5V
±0.5V,
V
S
- = -15.5V
±0.5V,
V
R
= 15.5
±0.5V.
FIGURE 2. STATIC BURN-IN TEST CIRCUIT
Irradiation Circuit
HS-1840ARH
+15V
NC
NC
+1V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
-15V
1kΩ
+5V
NOTE:
3. All irradiation testing is performed in the 28 lead CERDIP package.
3
