M85049/79-15W03

Description
circular mil spec backshells right angle back shell
CategoryThe connector    Connector bracket
File Size171KB,1 Pages
ManufacturerGlenair
Websitehttp://www.glenair.com/
Download Datasheet Parametric View All

M85049/79-15W03 Overview

circular mil spec backshells right angle back shell

M85049/79-15W03 Parametric

Parameter NameAttribute value
MakerGlenair
Reach Compliance Codenot_compliant
Factory Lead Time8 weeks
Related Mil-Spec Back CasesMIL-DTL-38999
Connector bracket typeCONNECTOR ACCESSORY
DIN complianceNO
IEC complianceNO
MIL complianceYES
Manufacturer's serial numberM85049/79
Military connector accessories nameBACKSHELL
Housing size15
Base Number Matches1
AS85049/79
90° EMI/RFI Environmental Backshell
CONNECTOR DESIGNATOR:
Finish
X
= Aluminum, Nickel Flurocarbon Polymer
Z
= Aluminum, Zinc-Nickel, Black
H
MIL-DTL-38999, Series III and IV
EN3645
N
= Electroless Nickel
W
= 1,000 Hr. Cadmium Olive Drab
over Electroless Nickel
M85049/79
-
10
TABLE I: Shell Size,
Thread and Dimensions
Shell
Size
09
11
13
15
17
19
21
23
25
A Thread
Class 2B
M12 X 1 - 6H
M15 X 1 - 6H
M18 X 1 - 6H
M22 X 1 - 6H
M25 X 1 - 6H
M28 X 1 - 6H
M31 X 1 - 6H
M34 X 1 - 6H
M37 X 1 - 6H
B Dia
Max
.750 (19.1)
.850 (21.6)
1.000 (25.4)
1.150 (29.2)
1.250 (31.8)
1.400 (35.6)
1.550 (39.4)
1.650 (41.9)
1.850 (47.0)
Basic
Part Number
Shell Size
(Tables I & II)
W
01
Clamp Size
(Tables II & III)
TABLE II: Shell Size,
Clamp Size and Dimensions
Shell
Size
09
11
13
15
17
19
21
23
25
Clamp Size
Min Max
01
01
02
02
02
03
03
03
04
02
03
04
05
06
07
08
09
10
F
±.156 (4.0)
.532
.627
.642
.719
.774
.854
.899
1.009
1.024
(13.5)
(15.9)
(16.3)
(18.3)
(19.7)
(21.7)
(22.8)
(25.6)
(26.0)
G
±.188 (4.8)
3.267
3.387
3.407
3.477
3.567
3.737
3.737
3.847
3.847
(83.0)
(86.0)
(86.5)
(88.3)
(90.6)
(94.9)
(94.9)
(97.7)
(97.7)
Clamp
Size
01
02
03
04
05
06
07
08
09
10
CAGE Codes 06324
TABLE III: Clamp Size,
Cable Range and Dimensions
Min
.062
.125
.250
.375
.500
.625
.750
.875
1.000
1.125
Cable Range
Max
.125
.250
.375
.500
.625
.750
.875
1.000
1.125
1.250
(3.2)
(6.4)
(9.5)
(12.7)
(15.9)
(19.1)
(22.2)
(25.4)
(28.6)
(31.8)
H
Max
.800
1.000
1.100
1.200
1.250
1.400
1.500
1.650
1.750
1.900
(20.3)
(25.4)
(27.9)
(30.5)
(31.8)
(35.6)
(38.1)
(41.9)
(44.5)
(48.3)
Printed in U.S.A.
(1.6)
(3.2)
(6.4)
(9.5)
(12.7)
(15.9)
(19.1)
(22.2)
(25.4)
(28.6)
APPLICATION NOTES
1.
2.
3.
For complete dimensions
see the applicable Military
Specification.
Metric dimensions (mm) are in
parentheses.
Cable Range is defined as
the accommodation range
for the wire bundle or cable.
Dimensions shown are not
intended for inspection criteria.
© 2012 Glenair, Inc.
GLENAIR, INC.
1211 AIR WAY
GLENDALE, CA 91201-2497
818-247-6000
FAX 818-500-9912
E-Mail: sales@glenair.com
www.glenair.com
39-21
EMI/RFI Environ.
Backshells
39
