560KD07JI: DescriptionRESISTOR, VOLTAGE DEPENDENT, 45V, 4.4J, THROUGH HOLE MOUNT, RADIAL LEADED; CategoryPassive components The resistor; File Size114KB，6 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric View All

560KD07JI Overview

RESISTOR, VOLTAGE DEPENDENT, 45V, 4.4J, THROUGH HOLE MOUNT, RADIAL LEADED

560KD07JI Parametric

Parameter Name	Attribute value
Terminal location	RADIAL
Terminal shape	WIRE
Number of terminals	2
Package shape	DISK PACKAGE
method of packing	BULK; TR
Terminal surface	Tin/Lead (Sn/Pb)
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	15 mm
Package length	9 mm
Package width	5 mm
Is it Rohs certified?	No
YTEOL	0
Objectid	1727902388
package instruction	RADIAL LEADED
Reach Compliance Code	Compliant
ECCN code	EAR99
Is Samacsys	N
Operating Voltage	45 V
Circuit RMS maximum voltage	35 V
Maximum energy absorption capacity	4.4 J
Rated temperature	85 °C
surface mount	NO
JESD-609 code	e0
Rated power dissipation(P)	0.02 W
Resistor type	VARISTOR
Installation features	THROUGH HOLE MOUNT
Package form	Radial

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla Street Chatsworth

!"#

$ % !"#

821KD07JX

THRU

180LD07JX

11 to 510 Volts

Varistor

1.5 to 60 Joule

Features

•

High Surge, High Energy

Designed to be Operated Continuously Across AC Power Lines

No Derating Up to 85 Ambient

Available in Tape and Reel or Bulk Pack

UL Recognized File # E306895(UL1449) and E306942(UL1414)

Maximum Ratings

•

Operating Ambient Temperature Range: -55 to +85

Storage Temperature Range: -55 to +125

Temperature Coefficient ( V) of Clamping Voltage (V

) at

Specified Test Current:<0.05%/

Varistor voltage temperature coefficient:

Vb at 25 - Vb at 85

Vb at 25

x(100/

)

120

100

L: 20mm Min.

DIMENSIONS

Unit: mm

Size D max

H max

C/I/Y

19.5

D±

0.05

All

0.6

0.8

E±

1.0

All

7.5

Lead

05D

07D

-55

100

120

140

160

All

7.5

12.5

16.5

10D

14D

20D

AMBIENT TEMPERATURE (°C)

PERCENT OF RATED VALUE

CURRENT, ENERGY AND POWER DERATING

CURVE

Note :

'X' can be S, C, I or Y .

'S'

'C'

'I'

'Y'

denotes

straight lead

out crimped lead

inner crimped lead

kink lead

www.mccsemi.com

Revision: 2

1 of 6

2006/09/09
