3-1393123-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> relay> 3-1393123-1

3-1393123-1: DescriptionPOWER/SIGNAL RELAY, 4PDT, MOMENTARY, 1200mW (COIL), 5A (CONTACT), PANEL MOUNT, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size110KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

3-1393123-1 Overview

POWER/SIGNAL RELAY, 4PDT, MOMENTARY, 1200mW (COIL), 5A (CONTACT), PANEL MOUNT, ROHS COMPLIANT

3-1393123-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
body width	21.8 mm
body height	34.9 mm
Body length or diameter	28.2 mm
Coil current (AC) maximum value	0.01 A
Coil power	1200 mW
Coil resistance	3900 Ω
Maximum coil voltage (AC)	120 V
Coil/Input Power Type	AC
Maximum contact current (AC)	5 A
Maximum contact current (DC)	5 A
Contact/Output Power Type	AC/DC
Manufacturer's serial number	1393123
Installation features	PANEL MOUNT
physical size	28.2mm X 21.8mm X 34.9mm
Guideline	CSA; UL
Relay action	MOMENTARY
Relay function	4PDT
Relay type	POWER/SIGNAL RELAY
seal	DUST PROOF
surface mount	NO
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

KHU-17A12B-120 Product Details

Product Photo

Industrial Relays (General Purpose)

C onve rte d to EU R oHS but not ELV C om plia nt

(

Sta te m e nt of

C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

KHU-17A12B-120

(3-1393123-1)

T E I nternal N umber: 3 - 1 3 9 3 1 2 3 - 1

Product Highlights:

KHU Series

C ontact Arrangement = 4 Form C , 4PDT, 4 C /O

C ontact C urrent Rating = 5 Amps.

Monostable C oil Magnetic System

Input Voltage = 120 VAC

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

KHA General Purpose Dry C ircuit to 5A Multicontact A...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type

= Solder Terminals

Electrical Characteristics:

C ontact C urrent Rating (Amps.)

= 5

Input Voltage (VAC )

= 120

C oil Resistance (?)

= 3900

Actuating System

= AC

C oil Power, Nominal (VA)

= 1.20

Body Related Features:

Series = KHU

Polarized = No

Contact Related Features:

Mounting Options

= PC Board, Socket

Enclosure

= Dust C over

FC C Part 68 Isolation = No

Relay Type = General

C ontact Base Material

= Silver C admium Oxide

Approx. Dimensions (L x W x H) (mm [in]) = 28.20 x 21.80 x 34.90

[1.111 x .858 x 1.375]

Test Button = With

Wiring Diagram = 4 Form C

Approved Standards = UL Recognized, C SA C ertified

Configuration Related Features:

C ontact Arrangement

= 4 Form C , 4PDT, 4 C /O

C oil Magnetic System

= Monostable

C oil Suppression Diode

= Without

C oil Selection C riteria

= Nominal Voltage

C oil Latching = Without

Status Indicator = None

Industry Standards:

RoHS/ELV C ompliance

= RoHS/Not ELV C ompliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = C onverted to comply with RoHS not

ELV directives

Other:

Brand = Potter & Brumfield

Additional Information:

Product Line Information

Additional Product Images:

Schematic

PC B Layout

Wiring Diagram

3-1393123-1 Related Products

	3-1393123-1	KHU-17A12B-120
Description	POWER/SIGNAL RELAY, 4PDT, MOMENTARY, 1200mW (COIL), 5A (CONTACT), PANEL MOUNT, ROHS COMPLIANT	POWER/SIGNAL RELAY, 4PDT, MOMENTARY, 1200mW (COIL), 5A (CONTACT), PANEL MOUNT, ROHS COMPLIANT
package instruction	ROHS COMPLIANT	ROHS COMPLIANT
Reach Compliance Code	unknown	unknow
ECCN code	EAR99	EAR99
body width	21.8 mm	21.8 mm
body height	34.9 mm	34.9 mm
Body length or diameter	28.2 mm	28.2 mm
Coil current (AC) maximum value	0.01 A	0.01 A
Coil power	1200 mW	1200 mW
Coil resistance	3900 Ω	3900 Ω
Maximum coil voltage (AC)	120 V	120 V
Coil/Input Power Type	AC	AC
Maximum contact current (AC)	5 A	5 A
Maximum contact current (DC)	5 A	5 A
Contact/Output Power Type	AC/DC	AC/DC
Manufacturer's serial number	1393123	KHU
Installation features	PANEL MOUNT	PANEL MOUNT
physical size	28.2mm X 21.8mm X 34.9mm	28.2mm X 21.8mm X 34.9mm
Guideline	CSA; UL	CSA; UL
Relay action	MOMENTARY	MOMENTARY
Relay function	4PDT	4PDT
Relay type	POWER/SIGNAL RELAY	POWER/SIGNAL RELAY
seal	DUST PROOF	DUST PROOF
surface mount	NO	NO
Termination type	SOLDER	SOLDER
